IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE
4 DRAWER NARROW CHEST SILVER OAK.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT use this chest if any parts are missing , damaged or worn.
DO NOT use this chest unless all fixings are secured.
Always use on a level, even surface.
WARNING: If this item is placed on a non-carpeted floor you must place some protection under all legs to stop
the chest from moving. If this is not adhered to there is no guarantee if the chest collapses.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the chest as this will damage the legs.
Always lift the chest with two people to reposition.
Keep any sharp objects away from the chest.
ASSEMBLY INSTRUCTIONS
CONRAD 4 DRAWER NARROW CHEST SILVER OAK
www.birlea.com
ASSEMBLING OR USING YOUR CONRAD
Vendor: S000369
Page 1 of 11
