Configuring the modem interface

Configuring the modem interface
50A

Connecting a modem to the FortiGate-50A

FortiGate-50A/50B, FortiWiFi-50B and FortiGate-100 FortiOS 3.0 MR4 Install Guide
01-30004-0265-20070831
The modem interface is only available on the FortiGate-50A.
The following sections will cover how to configure the FortiGate-50A modem
using the CLI.
The FortiGate-50A supports a redundant or stand alone 56K modem interface in
NAT/Route mode.
• In redundant mode, the modem interface automatically takes over from a
selected Ethernet interface when that Ethernet interface is unavailable.
• In stand alone mode, the modem interface is the connection from the FortiGate
unit to the Internet.
When connecting to an ISP in either configuration, the modem can automatically
dial up to three dial-up accounts until the modem connects to an ISP.
This section includes the following topics:
• Connecting a modem to the FortiGate-50A
• Selecting a modem mode
• Configuring the modem for the FortiGate-50A
• Adding a Ping Server
• Adding firewall policies for modem connections
The FortiGate-50A can operate with most standard external serial interface
modems that support standard Hayes AT commands. To connect, install a
USB-to-serial converter between one of the two USB ports on the FortiGate unit
and the serial port on the modem. The FortiGate unit does not support a direct
USB connection between the two devices.
Connecting a modem to the FortiGate-50A
