Package Contents

Warnings

18
Figure 4: FortiGate-100 package contents
Front
Internal, External, DMZ
Back
DMZ External
DC +12V 5A Console
Power RS-232 Serial
DMZ, External, Internal
Connection Connection Interfaces
Table 4: Technical Specifications
Dimensions 10.25 x 6.13 x 1.75 in. (26 x 15.6 x 345 cm)
Weight 1.75 lb. (0.8 kg)
Power Requirements DC input voltage: 12V
DC input current: 5A
Environmental Operating temperature: 32 to 104 F (0 to 40 C)
Specifications Storage temperature: -13 to 158 F (-25 to 70 C)
Humidity: 5 to 95% non-condensing
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The equipment compliance with FCC radiation exposure limit set forth for
uncontrolled Environment.
FortiGate-50A/50B, FortiWiFi-50B and FortiGate-100 FortiOS 3.0 MR4 Install Guide
POWER
INTERNAL EXTERNAL DMZ
STATUS
Status Power
Interfaces LED LED
Internal
Installing the FortiGate unit
Ethernet Cables:
Orange - Crossover
Grey - Straight-through
Null-Modem Cable
(RS-232)
Power Cable Power Supply
Q u i c k S t a r t G u i d e
INTERNAL EXTERNAL DMZ POWER
STATUS
FortiGate-100
