Table 28: Analog Audio Outputs - Tektronix WVR7200 Technical Reference

Table 28: Analog audio outputs

Characteristic
Audio Modes
Audio Sources
Number of Channels
Output Connections
Maximum Output Levels
Input to Output Gain
Digital Input to Analog Output Gain
Accuracy over Frequency
Analog Input to Analog Output
Gain Accuracy over Frequency
Output Impedance
Digital Input to Analog Output
Distortion (THD + N)
Analog Input to Analog Output
Distortion (THD + N)
Digital Input to Analog Output
Crosstalk, Typical
WVR7200 Specifications and Performance Verification
Performance requirement
+24 dBu ±0.5 dBu
± 0.5 dB, 20 Hz to 20 kHz, 0 to –40 dBFS,
20 or 24 bit input
± 0.8 dB, 20 Hz to 20 kHz, 24 dBu to –16 dBu
Reference information
Balanced: provides a full-scale output of
24 dBu and is designed for professional
balanced applications
Unbalanced: Designed to drive the
unbalanced inputs of consumer amplifiers, in
which case the negative output pin must be
grounded
The channels routed to the line outputs may
include: Embedded audio source, AES audio
source, Analog audio source, and Decoded
Dolby
Provides up to eight channels
Balanced, unterminated via rear panel
connector
62 pin, 3 row, DSUB connector, but only 2
rows of 42 pins are connected
Ground negative output to support
unbalanced mode
When one output is grounded to achieve
unbalanced mode, the other output will be
driven to a larger amplitude. You can reduce
the level by adding attenuation in the Audio
Settings menu. Do not exceed the maximum
rated output power in either mode
0 dB to –120 dB in 0.5 dB steps
50 Ω
Intended to drive ≥600 Ω load. Drivers
are capable of driving a minimum load
impedance of 300 Ω but may overheat. DO
NOT exceed maximum rated output power
≤0.01% from full scale to –20 dBFS, 20 Hz to
20 kHz
≤0.02% from full scale to –20 dBFS, 20 Hz to
20 kHz
<–90 dB, 20 Hz to 20 kHz, 24 dBu or 0 dBFS
input
<–100 dB, 20 Hz to 2 kHz, 24 dBu or 0 dBFS
input
Defined as cross talk within a pair
Specifications
25
