Table 6: Jitter display (Option PHY3) (cont.)
Characteristic
Jitter Minimum is
Measurement a function
Noise Floor of bandwidth
selection:
10 Hz,
3 Gb/s
and
1.5 Gb/s
100 Hz,
1 kHz,
10 kHz,
100 kHz,
3 Gb/s
and
1.5 Gb/s
All HPF
settings,
270 Mb/s
Digital
Readout Type
Digital
Readout
Accuracy,
Typical
10 Hz,
3 Gb/s
and
1.5 Gb/s
100 Hz,
1 kHz,
10 kHz,
100 kHz,
3 Gb/s
and
1.5 Gb/s
All HPF
settings,
270 Mb/s
Resolution
WVR7200 Specifications and Performance Verification
Performance requirement Reference information
Applies to jitter waveform
200 ps typical
40 ps typical
250 ps typical
Displays peak to peak value of jitter detected
over the measurement period, as defined by
selected high-pass filter setting. Indicates
timing jitter or alignment jitter if appropriate
For jitter frequencies from 5 times bandwidth
selection to 4 MHz
<0.3 UI + 10% of reading
<0.05 UI + 10% of reading
<0.05 UI + 10% of reading
0.01 UI
