RunCam Micro Sparrow User Manual

Download this manual

Table of Contents

Need help?

Do you have a question about the Micro Sparrow and is the answer not in the manual?

Page 2 Connection Model: Micro Sparrow RunCam TX25 3.5-5.5v in 5-36v in 5D-OSD menu cable Video out...
Page 3: Dimensions & Installation
Dimensions & Installation 19mm 12mm 17mm 19mm 10mm M2 Screws...
Page 4: Camera Menu
Camera Menu · · STD · · EXPOSURE EXPOSURE BRIGHTNESS MIDDLE SHUTTER MODE AUTO ATW1 IMAGE ADJ PREV NEXT SAVE EXIT RETURN BRIGHTNESS ( LOW / MIDDLE / HIGH) · · EXPOSURE ( STD / BLC ) · · · SHUTTER MODE / MANUAL 1/25-100000 AUTO...
Page 5: Image Adj
Camera Menu · · AGC · · IMAGE ADJ IMAGE ADJ MODE SHARPNESS 60/100 INTENSITY MIDDLE HDNR 65/100 CONTRAST 65/100 SATURATION 60/100 R GAIN 45/100 RETURN NEXT RETURN · · MODE ( ON / OFF ) · · SHARPNESS ( 60 / 0-100 ) INTENSITY ( LOW / MIDDLE / HIGH ) ·...
Page 6 Camera Menu · · · · DAYNIGHT IMAGE ADJ IMAGE ADJ G GAIN 45/100 DAYNIGHT B GAIN 45/100 SYSTEM BAD PIXEL PRIVACY MASK NEXT RETURN PREV NEXT SAVE EXIT · · G GAIN ( 45 / 0-100 ) · · DAYNIGHD ( EXT /COLOR/BW/AUTO GEN ) ·...
Page 7 Camera Menu · · SYSTEM · · SYSTEM TV GAMMA MIDDLE MIDDLE TV BRIGHT MIDDLE TV SYSTEM LANG RELOAD FTY NEXT RETURN PREV NEXT SAVE EXIT · · TV GAMMA ( LOW / MIDDLE / HIGH ) · · WDR ( LOW / MIDDLE / HIGH ) ·...
Page 8 Parameters Model RunCam Micro Sparrow Image Sensor 1/3" CMOS Sensor Horizontal Resolution 700TVL Lens 2.1mm (M8) FOV145° / 16:9 Signal System NTSC/PAL Switchable on OSD menu Integrated OSD S/N Ratio >50dB (AGC OFF) Electronic Shutter Speed PAL: 1/25~100,000; NTSC: 1/30~100,000...
