Summary of Contents for RunCam Micro Eagle
- Page 2 Connection * Unplug the 5D-OSD menu cable after OSD setting. Model: Micro Eagle RunCam TX200 ENTER 3.5-5.5v in 5-36v in DOWN RunCam Video out 1x OSD Key-press Board...
- Page 3 Dimensions 19mm 19mm Model: Micro Eagle 19mm 19mm M2 Screws 13mm 19mm 22mm...
- Page 4 Camera Menu MAINMENU IMAGE IMAGE MAX GAIN Color DAY &NIGHT PAL-50HZ IMAGE ENHANCE VIDEO STANDARD MIRROR SCREEN FORMAT ENGLISH FLIP LANGUAGE BRIGHTNESS LOAD DEFAULT ZOOM IN SOFT VERSION RETURN SAVE &EXIT EXIT · DAY&NIGHT (Color/B&W/Auto/External) · MAX GAIN (7 / 1-9) ·...
- Page 5 Camera Menu IMAGE ENHANCE IMAGE ENHANCE SHARPNESS DETAIL MANUAL SATURATION VALUE RETURN EDGE MANUAL VALUE RETURN · SHARPNESS (DETAIL / EDGE) · DETAIL (MANUAL: 0-15 / AUTO) · SATURATION (AUTO/MANUAL: 0-15) · EDGE (MANUAL: 0-15 / AUTO)
- Page 6 Parameters Model RunCam Micro Eagle Image Sensor 1/1.8" CMOS Sensor Horizontal Resolution 800TVL FOV 170 @ 16:9 FOV 140 @ 4:3 Screen Format 16:9 / 4:3 Switchable on OSD menu Signal System NTSC / PAL Switchable on OSD menu Mirror/Flip S/N Ratio >50dB...
- Page 7 www.runcam.com...
