Summary of Contents for RunCam Sparrow
- Page 2 Connection Unplug the 5D-OSD menu cable after OSD setting. Transmitter 2 pin extension cord Power in 5-36V in Video out To VBAT+ Audio out DOWN DOWN VBAT+ 5D-OSD menu cable...
-
Page 3: Dimensions & Installation
Dimensions & Installation 28mm Nylon Gaskets M2 Screws M3 Screws M3 Non-slip Nuts... - Page 4 Voltage: · · Reduce (LEFT button) or increase (RIGHT button) 0.1V each press. Maximumadjustment range: ± 1v 16.8v RunCam 01:08 · · After adjustment, press the CENTER button to select the voltage, then press it again to save and · · Quick settings: exit.
- Page 5 OSD Menu OSD Setting: Press and hold the UP button for 2 seconds to enter OSD setup menu. · · PILOT: ON/OFF RunCam · · TIMER: ON/OFF 1234567890ABCDEFG · · VOLTAGE: ON/OFF HIJKLMNOPQRSTUVWX · · BASELINE: OFF/1-9 YZa b c d e f g h i j k l m n o ·...
-
Page 6: Camera Menu
Camera Menu · · STD · · EXPOSURE EXPOSURE BRIGHTNESS MIDDLE SHUTTER MODE AUTO ATW1 IMAGE ADJ PREV NEXT SAVE EXIT RETURN BRIGHTNESS ( LOW / MIDDLE / HIGH) · · EXPOSURE ( STD / BLC ) · · · SHUTTER MODE / MANUAL 1/25-100000 AUTO... -
Page 7: Image Adj
Camera Menu · · AGC IMAGE ADJ · · IMAGE ADJ MODE SHARPNESS 60/100 INTENSITY MIDDLE HDNR 65/100 CONTRAST 65/100 SATURATION 60/100 R GAIN 45/100 RETURN NEXT RETURN MODE ( ON / OFF ) · · · · SHARPNESS ( 60 / 0-100 ) ·... - Page 8 Camera Menu IMAGE ADJ · · DAYNIGHT · · IMAGE ADJ G GAIN 45/100 DAYNIGHT B GAIN 45/100 SYSTEM BAD PIXEL PRIVACY MASK NEXT RETURN PREV NEXT SAVE EXIT · · G GAIN ( 45 / 0-100 ) · · DAYNIGHD ( EXT /COLOR/BW/AUTO GEN ) ·...
- Page 9 Camera Menu SYSTEM · · · · SYSTEM TV GAMMA MIDDLE MIDDLE TV BRIGHT MIDDLE TV SYSTEM LANG RELOAD FTY NEXT RETURN PREV NEXT SAVE EXIT · · TV GAMMA ( LOW / MIDDLE / HIGH ) · · WDR ( LOW / MIDDLE / HIGH ) ·...
- Page 10 Parameters Model RunCam Sparrow Image Sensor 1/3" CMOS Sensor Horizontal Resolution 700TVL Lens 2.1mm FOV150° / 16:9 Signal System NTSC/PAL Switchable on OSD menu Integrated OSD Integrated MIC Camera Menu S/N Ratio >50dB (AGC OFF) Electronic Shutter Speed PAL: 1/25~100,000; NTSC: 1/30~100,000...
