Summary of Contents for RunCam NIGHTEAGLE 2 PRO
- Page 2 Connection * Unplug the 5D-OSD menu cable after OSD setting. Transmitter 2 pin extension cord Power in Model: Night Eagle 2 Pro 5-36v in To VBAT+ Video out ENTER Audio out DOWN RunCam VBAT+ 1x OSD Key-press Board...
-
Page 3: Dimensions & Installation
Dimensions & Installation Nylon Gaskets M2*4 Screws M3*5 Screws M3 Non-slip Nuts 28mm Model: Night Eagle 2 Pro... - Page 4 Voltage: · · Reduce (LEFT button) or increase (RIGHT button) 0.1V each press. Maximumadjustment range: ± 1v 16.8v RunCam 01:08 · · After adjustment, press the CENTER button to select the voltage, then press it again to save and · · Quick settings: exit.
- Page 5 OSD Menu OSD Setting: Press and hold the UP button for 2 seconds to enter OSD setup menu. · · PILOT: ON/OFF RunCam · · TIMER: ON/OFF 1234567890ABCDEFG · · VOLTAGE: ON/OFF HIJKLMNOPQRSTUVWX · · BASELINE: OFF/1-9 YZa b c d e f g h i j k l m n o ·...
-
Page 6: Camera Menu
Camera Menu MAINMENU IMAGE IMAGE MAX GAIN PAL-50HZ VIDEO STANDARD ENGLISH LANGUAGE IMAGE ENHANCE LOAD DEFAULT MIRROR SOFT VERSION BRIGHTNESS SAVE &EXIT ZOOM IN EXIT RETURN · · VIDEO STANDARD (PAL-50Hz/NTSC-60Hz) · MAX GAIN (9 / 1-9) · WDR (ON/OFF) ·... -
Page 7: Image Enhance
Camera Menu IMAGE ENHANCE SHARPNESS SATURATION RETURN · · SHARPNESS (AUTO/MANUAL: 0-15) · SATURATION (AUTO/MANUAL: 0-15) - Page 8 Model RunCam Night Eagle 2 PRO Image Sensor 1/1.8" CMOS Sensor Horizontal Resolution 800TVL Lens FOV 140 2.5mm Screen Format Signal System NTSC/PAL Switchable on OSD menu Integrated OSD Integrated MIC S/N Ratio >50dB Electronic Shutter Speed Auto Max Gain Min.
- Page 9 www.runcam.com...
