Summary of Contents for RunCam Micro Sparrow 2
- Page 2 Connection To VBAT+ Model: Micro Sparrow 2 5-36v in RunCam TX200 ENTER 3.5-5.5v in DOWN Video out RunCam VBAT+ 1x OSD Key-press Board...
-
Page 3: Dimensions & Installation
Dimensions & Installation 19mm 12mm 17mm 19mm 10mm M2 Screws 12mm... -
Page 4: Quick Settings
flashes, press UP/DOWN button to adjust it · · Long press DOWN button for ten seconds to reset OSD settings to default · · Long press RIGHT button for three seconds to 01:08 16.8V RUNCAM switch between the camera presets... - Page 5 OSD Menu · · CLR: clear the ID character; 1 2 3 4 5 6 7 8 9 0 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z & : = . / ·...
-
Page 6: Camera Menu
Camera Menu · · SETUP MENU SETUP MENU PICT ADJUST PICT ADJUST FLIP WHITE BAL BRIGHTNESS LANGUAGE ENGLISH CONTRAST CAMERA RESET SHARPNESS COLOR GAIN EXIT RETURN · · LANGUAGE ( ENGLISH / DEUTSCH / FRANCAIS / · · FLIP ( OFF / H-FLIP / V-FLIP / HV-FLIP ) PYCCKNN / PORTUGUES / ESPANOL / 中文... - Page 7 Parameters Model RunCam Micro Sparrow 2 Image Sensor Super WDR CMOS Sensor Horizontal Resolution 700TVL Lens 2.1mm (M8) FOV150° 2.3mm(M8) FOV 140° Screen Format Signal System NTSC / PAL Mirror/Flip Available Integrated OSD One Touch Scene Setting Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight S/N Ratio >50dB...
