Summary of Contents for RunCam Swift Mini 2
- Page 2 Connection To VBAT+ 3.5-5.5V in Model: Swift Mini 2 RunCam TX200 5-36v in ENTER DOWN Video out RunCam VBAT+ 1x OSD Key-press Board...
- Page 3 Dimensions & Installation 22.30 M2 Screws 27.00 22.00 14.20 10.00 6.00 6.00 19.00 2.00 6.00 6.00 6.00 12.00 6.00 18.00 28.00 24.70 3.00...
- Page 4 flashes, press UP/DOWN button to adjust it · · Long press DOWN button for ten seconds to reset OSD settings to default · · Loog press RIGHT button for three seconds to 01:08 16.8V RUNCAM switch between the camera presets...
- Page 5 OSD Menu · · CLR: clear the ID character; 1 2 3 4 5 6 7 8 9 0 A B C D E F G H I J K L M N O P Q · · ALARM: low voltage warning value, smartly judge R S T U V W X Y Z = / &...
- Page 6 Camera Menu · · MAIN MENU · · EXPOSURE PERSONAL MENU EXPOSURE SHUTTER AUTO EXPOSURE BRIGHTNESS BACKLIGHT WHITE BAL ATW1 DWDR COLOR DAY＆NIGHT RETURN IMAGE ADJ LANGUAGE ENGLISH RESET EXIT · · SHUTTER (AUTO / 50-100000 / FLK) · · LANGUAGE (English/中文) ·...
- Page 7 Camera Menu · · IMAGE ADJ IMAGE ADJ USER ADJ. LENS SHAD GAMMA 0.50 2DNR PED LEVEL MIRROR COLOR GAIN FONT COLOR RETURN CONTRAST SHARPNESS DISPLAY USER NEG IMAGE RETURN · · LENS SHAD (OFF/ ON:22 0-255) · · GAMMA (0.5 / 0.05-1.0) ·...
- Page 8 Camera Menu · · BACKLIGHT (BLC / HLC / OFF) AREA SEL AREA1 LEVEL AREA STATE MODE ALL DAY GAIN RETURN HEIGHT WIDTH LEFT/RIGHT TOP/BOTTOM RETURN · · AREA SEL (AREA1/AREA2) · · LEVEL (200 / 0-255) · · GAIN (042 / 0-255 ) ·...
- Page 9 Camera Menu · · DAY ＆ NIGHT（AUTO / COLOR / B&W / EXT) D＆N AUTO D＆N B＆W N LEVEL BURST N DELAY IR SMART D LEVEL IR LEVEL HIGH D DELAY RETURN RETURN · · DAY NIGHT LEVEL (80 / 0-176) ·...
- Page 10 Parameters Model RunCam Swift Mini 2 Image Sensor 1/3" SONY Super HAD II CCD Horizontal Resolution 600TVL Lens 2.1mm (M12) FOV165° / 2.3mm(M12) FOV 150° Signal System PAL/NTSC Integrated OSD One Key Scene Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight S/N Ratio >60dB (AGC OFF)
