INSTALLATION
2.2
Fitting the thermal insulation
Place the insulation mat (1, Fig. 03) around the UltraGas
fasteners (1b, Fig. 03).
- Tension springs (1c, Fig. 03) serve for additional fixing
- Do not overtighten the straps (reduced insulating value).
1c
Fig. 03
10
boiler and attach with plastic straps (1a, Fig. 03) and strap
®
1b
1
1a
4 217 215 / 00
