CBS-6000 Series Coffee Brewers
Models:
CBS-61H
CBS-62H
Contact Information ................................................ 2
Product Description/Features ................................. 2
Technical Data........................................................ 2
Brewing Specification.......................................... 2
Weights and Capacities ...................................... 2
Dimensions & Utility Connections........................... 4
Installation............................................................... 5
Operating Procedures ............................................ 7
Service .................................................................... 8
FETCO® and LUXUS® are trademarks or trade names of Food Equipment Technologies Company.
© 2006 Food Equipment Technologies Company
User's Guide
Table of Contents
Warranty.............................................................. 8
Principles of Operation........................................ 8
Adjustments ...................................................... 11
Dispenser Parts .................................................... 14
LUXUS TPD- 3.0............................................... 14
Brewer Parts ......................................................... 15
CBS 61H & 62H Parts List ................................ 15
Parts Drawing: CBS 61H & 62H ....................... 17
Troubleshooting.................................................... 18
Part # P005
Revised January 9, 2006
Advertisement
Table of Contents
Related Manuals for Fetco CBS-61H
Summary of Contents for Fetco CBS-61H
-
Page 1: Table Of Contents
Dimensions & Utility Connections... 4 Installation... 5 Operating Procedures ... 7 Service ... 8 FETCO® and LUXUS® are trademarks or trade names of Food Equipment Technologies Company. © 2006 Food Equipment Technologies Company User’s Guide Table of Contents Warranty... 8 Principles of Operation... -
Page 2: Contact Information
Half Batch 2.5 – 2.75 min. (Allow an extra 2-4 minutes for coffee to finish dripping) Coffee Filter Size: 20” X 8” – standard FETCO # F004 18” X 7½” - optional half batch FETCO # F005 Weights and Capacities... -
Page 3: Electrical Configuration And Brewing Efficiency
Electrical Configuration and Brewing Efficiency CBS-61H Electrical Heater Code Configuration C61016 2 X 3000 watt C61026 2 X 4000 watt C61036 3 X 3000 watt C61046 3 X 4000 watt C61146 3 X 4000 W Steam Heated Version Electrical Maximum... -
Page 4: Dimensions & Utility Connections
Dimensions & Utility Connections CBS-61H CBS-62H... -
Page 5: Installation
The water line must be flushed thoroughly prior to connecting it to the brewer to prevent debris from contaminating the machine. Verify that the water line will provide at least 1 gallon per minute for the CBS-61H, and 2 gallons per minute for the CBS-62H before connecting it to the brewer. - Page 6 Electrical Connections 1. Verify that the actual voltage at the electrical service connection is compatible with the specifications on the brewer’s serial number label. Make sure the electrical service includes neutral. 2. The temperature and water tank fill level are pre-set at the factory. There is no need to turn off the heaters during the installation process.
-
Page 7: Operating Procedures
2. Pre-heat the dispensers. This step is very important to the overall success of the brewing operation. FETCO avoids the damaging affects of heat on fresh brewed coffee by using highly insulated dispensers. The dispenser must be pre- heated with hot water from the brewer. This preheating process ensures that the coffee in the first brew starts out hot. -
Page 8: Service
Warranty All FETCO brewers come with a limited warranty. All warranty service must be pre-authorized by calling the FETCO Service Department at (800) 338-2699. Principles of Operation... - Page 9 Opening this connection cuts the timed output in half. Dispense System: The dispense system is completely mechanical. It is one of the areas that makes FETCO's brewer truly unique. (See the illustration in this section.) When you rotate the brew lever down to brew, the end of the dispense tube is submerged in the hot water tank.
- Page 10 A bypass valve and tube are connected to the sprayhead. This valve directs brew water around the outside edge of the filter paper. The by-pass valve is shipped in the closed position from the factory. Each time the valve is adjusted, the brew volume is affected.
-
Page 11: Adjustments
Adjustments Thermostat Adjustment: For equipment manufactured before April 1, 2004 The brewer’s water tank temperature is factory set at 205°F (slightly lower for high altitudes, to prevent boiling). This setting will deliver water at 195°F ± 5° to the coffee grounds. Measure the temperature by holding a thermometer in the stream of water flowing out of the hot water faucet. -
Page 12: Timer Adjustment
Timer Adjustment: For equipment manufactured before April 1, 2004 The timers control the amount of water that is used for brewing. The dual sided brewer, model # CBS-62H, has separate timers to control each side independently. All timers are factory set to deliver the correct amount of water. There are three possible types of timers used: •... -
Page 13: Bypass Adjustment
Effective April 1, 2004: A new digital water level control board was introduced as a direct replacement for the old style liquid level control board. The new board features a jumper to adjust its’ sensitivity to reverse osmosis or other types of ultra-pure water. -
Page 14: Dispenser Parts
102020 sight gauge cap and vent assy. 21035 sight gauge tube 12-1/2" (plastic) 71033 sight gauge tube 12-1/2" (glass) 82015 faucet shank screw-2 required 101038 twist lock cover assembly 101051 brew funnel assembly 41011 LUXUS label For current parts pricing, visit www.fetco.com. Dispenser Parts... -
Page 15: Brewer Parts
CBS 61H & 62H Parts List Part # Description 25004 Thermostat Temp probe Lead Cover (tubing) 82019 Heater Screw, 10-32 x 1/4" ss (heater connection) 83004 Heater Gasket 3/4" o.d. (also used behind faucet on 30's) 83006 Heater Washer, 1"o.d. x 1/2" I.d. 84004 Heater Locknut, 1/2-20 53031... - Page 16 Dispense Latch, Solenoid assy. 120vac 102039 Dispense Latch, Solenoid assy. 220vac (export) 108034 Liquid Level Control Brd. 100-120VAC, 50-100K ohm 108035 Liquid Level Control Brd. 200-240VAC, 50-100K ohm (EXPORT) 58024 Switch, full/half batch selector, w/harness (optional) For current parts pricing, visit www.fetco.com.
-
Page 17: Parts Drawing: Cbs 61H & 62H
Parts Drawing: CBS 61H & 62H DWG. 701-015... -
Page 18: Troubleshooting
Timer/s are set too high -Adjust timers down to appropriate level Thermal server not empty -Empty the server and try again -Call FETCO Service Dept. to discuss. Spray head missing -Attach spray head assembly. Improper dose -Measure and confirm correct dose... - Page 19 Brewing Problem Spray head / brew basket drips either side or both MAJOR Brewer won’t stop brewing (not same as high brew levels) Coffee tastes too strong Temperature Problem (brewer only) See also LUXUS problems Brew water is cold / not hot enough, ready light is OFF.
- Page 20 LUXUS TPD-1.5 Problem LUXUS leaking from the base LUXUS leaking from sight gauge Coffee not hot enough Drip from faucet Coffee won’t dispense Possible Cause Solution Overflow of coffee, or water from -Remove the plastic base (it slips on and off) wipe the cleaning running down the side and interior and plastic base dry and reassemble.
