Outdoor Grilling System
3 - Y E A R W A R R A N T Y
8 5 - 1 1 3 4 ( P R O P A N E ) ( G 4 1 5 0 1 )
Read and save this manual for future reference.
If pre-assembled, leave this manual with
unit for consumer's future reference.
For product inquiries, parts, warranty
and troubleshooting support, please call
1-877-707-5463
W A R N I N G
Always cook with the lid open.
Lid should only be used for storage once
the unit has cooled down.
S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L
F O R Y O U R S A F E T Y
If You Smell Gas
1. Immediately turn off the flow
of gas to the unit.
2. Extinguish any open flame.
3. Open the lid of the unit.
4. If the odour does not stop quickly,
immediately call your gas supplier
or Fire Department for assistance.
F O R Y O U R S A F E T Y
1. Do not store or use gasoline or other
flammable vapours and liquids in the
vicinity of this or other appliance.
2. An LP Gas cylinder not connected for
use shall not be stored in the vicinity
of this or other appliance.
W A R N I N G
Failure to follow all of the manufacturer's
instructions could result in hazardous
fires, explosions, property damage,
or serious personal injury or even death.
W A R N I N G
Follow all leak check procedures carefully prior
to operation of barbecue, even if barbecue
was stored assembled. Do not try to light
this barbecue without reading the Lighting
Instructions section of this man ual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y
Advertisement
Table of Contents
Related Manuals for Centro 85-1134
Summary of Contents for Centro 85-1134
- Page 1 SERIAL #: Outdoor Grilling System S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L F O R Y O U R S A F E T Y If You Smell Gas 1.
-
Page 2: Table Of Contents
Warranty ....ii This Centro Barbecue carries a three year limited warranty against defects in manu- Installation Information ..1 facturing workmanship. -
Page 3: Installation Information
I N S T A L L A T I O N The installation of this appliance must be in accordance with all local codes, or in the absence of local codes: I N F O R M A T I O N Canadian installation must conform to the current national standards, which at this time •... -
Page 4: Transportation And
The Cylinder must also be equipped with: A shut-off valve with a correct cylinder valve outlet as specified in current standards. • Canada: CAN / CGA 1.6g-M97 Outdoor Gas Grilles. • a) A safety relief valve with direct connection to the vapour space of the cylinder. b) A collar to protect the tank shut-off valve. -
Page 5: Prior To Using The Grill
P R I O R T O U S I N G Do not use your barbecue until you have carefully read and fully understand all the information in this manual. Please ensure the following: Your barbecue is properly assembled. •... -
Page 6: Safety Hose And Regulator
S A F E T Y H O S E Propane Gas Models: Your barbecue is designed to operate on L.P. (Propane) gas at a pressure of 2.74 Kpa (11˝ water column). A regulator preset to this pressure is supplied A N D R E G U L A T O R with the barbecue and must be used. -
Page 7: Safety Leak Testing
To Reset The Gas Regulator Safety Device 1. Close the LP (propane) tank valve. 2. Turn all burner control knobs to the OFF position. 3. Disconnect the regulator from the LP tank. 4. Open the grill lid. 5. Open all of the control knobs to the high position. 6. -
Page 8: Lighting The Main Burners
L I G H T I N G Make Sure you have followed all the safety checks, procedures and instructions indicated in the previous section, before attempting to light the grill. T H E G R I L L Lighting The Main Burners 1. - Page 9 6. Confirm that the burner is properly lit. If the flame pattern is other than normal, consult the Troubleshooting Guide for corrective action. 7. Always preheat the Barbecue before starting to cook. Light all burners and adjust them to the HIGH position for 5-10 minutes. Before placing any food on the Barbecue, clean the cooking grids with a Porcelain cleaning brush.
-
Page 10: Parts List And
P A R T S L I S T I N G F O R Item No. Quantity Specification Part No. Burner Box Assembly 8 5 - 1 1 3 4 ( P R O P A N E ) Lid Assembly G415-2100-01 ( G 4 1 5 0 1 ) - Page 11 8 5 - 1 1 3 4 ( P R O P A N E ) ( G 4 1 5 0 1 )
- Page 12 A S S E M B L Y I N S T R U C T I O N S Hardware Pack List Description Part Number Quantity Tools Needed for Assembly 1/4” x 38 mm Screw 20120-13038-250 Ø7 Lock Washer 41400-07000-250 #2 Phillips ®...
- Page 13 Fig. 1 Attach two front casters (CP) and two back casters with lock (CO) to the bottom shelf (CK) by using the provided wrench 9. Fig. 2 Assemble the left and right cart side panel (CA & CB) to the bottom shelf (CK) as shown by using hardware 1, 2, 3, and 4 ( X6).
- Page 14 Fig. 4 Affix the Burner Box assembly (A) to the Cart assembly as shown by using hardware 5, 6, and 7 ( X4). Tighten the burner box assembly to the cart assembly from the rear using hardware 5, 6, and 7 ( X2). Fig.
- Page 15 Fig. 7 Unscrew the igniter cap and place AA batteries provided into igniter (BH) with positive end (+) facing outward. Screw igniter cap into ignit- er as shown. Assemble the cart handle (CQ) to the burner box frame (BB) by using hardware 1, 2, and 3 (X4).
- Page 16 D I S T R I B U T O R Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8...
