Outdoor Grilling System
3 Y E A R L I M I T E D W A R R A N T Y
8 5 - 1 1 3 4 - 4 ( P R O P A N E ) ( G 4 1 5 0 3 )
Read and save this manual for future reference.
If pre-assembled, leave this manual with
unit for consumer's future reference.
For product inquiries, parts, warranty
and troubleshooting support, please call
1-877-707-5463
W A R N I N G
Always cook with the lid open.
Lid should only be used for storage once
the unit has cooled down.
S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L
D A N G E R
If You Smell Gas
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
W A R N I N G
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
W A R N I N G
Failure to follow all of the manufacturer's
instructions could result in hazardous
fires, explosions, property damage,
or serious personal injury or even death.
W A R N I N G
Follow all leak check procedures carefully
prior to operation of barbecue,
even if barbecue was store assembled.
Do not try to light this barbecue
without reading the Lighting Instructions
section of this manual.
T H I S B A R B E C U E I S F O R
O U T D O O R U S E O N L Y
Advertisement
Table of Contents
Related Manuals for Centro 85-1134-4
Summary of Contents for Centro 85-1134-4
- Page 1 SERIAL #: Outdoor Grilling System S A F E U S E , C A R E A N D A S S E M B L Y M A N U A L D A N G E R If You Smell Gas 1.
-
