Threading the Machine

Raise the take–up lever to its highest position by turning the
handwheel toward you.
Raise the presser foot.
Place a spool on the spool pin as shown, with thread coming
from back of the spool.
z
Draw the thread into thread guide using both hands.
x
While holding the thread near spool, draw thread down
into the tension area and then around the check spring
holder.
c
Firmly draw the thread up and through the take–up
lever from right to left.
v
Then draw the thread down and slip it into the lower
thread guide.
b Draw the thread down and slip it into needle bar thread
guide on the left.
n
Thread the needle eye from front to back.
Note:
You may want to cut the end of thread with sharp scissors
for easier needle threading.
18
2206 Owners Manual/ User Guide
