Mischa Console Table
Assembly Instructions
9
Drawer x 2
E
3 7
I
E
O
3 11
Attach panels [7], [9] and [12] as shown using 4x screws (B). Tighten
with a screwdriver. Attach slide rail (I) and slide rail (H) to the underside
of the side panels as shown. Secure with 4x small screws (E) and tighten
with a screwdriver. Attach 1x handle (O) to panel [11] and secure with 2x
handle bolts (N).Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
B
B
3 9
3 12
3 7
3 12
E
H
E
N
N
10
B
B
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
6
