Inca Three Drawer
Assembly Instructions
5
8
3
Slide panel [8] down along the grooves between the panels [3]
and [4] to form the back of the unit as shown.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
4
3
Attach panel [1] to panels [3], [4] and [5] with 4x dowels (A) and secure with
4x locking nuts (D) and 2x screws (B). Tighten with a screwdriver.
1
A
D
A
5
D
B
A
D
4
B
4
