For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-AC6058
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
Rev: 18-09-06
Advertisement
Table of Contents
Related Manuals for Furniture of America CM-AC6058
Summary of Contents for Furniture of America CM-AC6058
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-AC6058 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 6pcs #A x 12pcs Wood Dowels Ø8x30mm Shelf Panels #B x 18pcs #2 x 1pc Top Back Panel Barrel Nut Ø1/4"...
- Page 4 Insert dowels (#A) and barrel nuts (#B) to shelf panel (#1), then align top back panel (#2) to shelf panel (#1). Secure by using bolts (#D) onto barrel nuts (#B) in shelf panel (#1). #A x 2pcs #B x 3pcs #D x 3pcs Insert dowels (#A) and barrel nuts (#B) to shelf panel (#1), then align middle back panels (#3)
- Page 5 Insert dowels (#A) and barrel nuts (#B) to shelf panel (#1), then align bottom back panel (#4) to shelf panel (#1). Secure by using bolts (#D) onto barrel nuts (#B) in shelf panel (#1). #A x 2pcs #B x 3pcs #D x 3pcs Align shelves (#1) to the right side frame (#6), then secure by using bolts (#C).
- Page 6 Secure shelves (#3) to the side frame (#6) by using bolts (#C). #C x 9pcs Align left side frame (#5) to the shelves, then secure by using bolts (#C). #C x 12pcs Page 6 of 7...
- Page 7 Secure shelves (#3) to the left side frame (#5) by using bolts (#C). #C x 9pcs #C x 2pcs #F x 2set Page 7 of 7...
