Installation -
Installation
2
Using the template sheet, make the cabling hole
Template Sheet
1
on the wall/ceiling. After making the cabling hole,
pass the cables through the hole.
1
Connect the network cable and power cable
2
respectively. See the section 'Installation - Cabling'
for details.
assembled to (a) tightly. As a final step, (c) need
to be assembled to (b) without making any space.
Fix the camera on the wall/ceiling by screw
3
provided.
fixing the camera.
After adjusting the view angle, tighten the Pan/
4
Tilt/Rotate screw.
Remove the protective film from the camera to
5
complete the installation.
3
5
7
Put the Lan cable into (a), then (b) will be
b
a
Loosen the Pan/Tilt/Rotate screw a little before
c
