- Page 1 OUTBOARD MOTORS OWNER’S MANUAL F15A BM/BW/FW F20A BM/BW/FW SUZHOU PARSUN POWER MACHINE CO., LTD. https://www.boat-manuals.com/...
- Page 2 If there is any question concerning the manual, please consult your local PARSUN dealer. Data, illustrations or explanations in this Owner’s Manual do not constitute base for any legal claim against our company.
- Page 3 Engine Identification Numbers Outboard motor serial number The outboard motor serial number is marked on the label. The label can be found on the bracket left assembly or on the upper part of the bracket swivel. Record your outboard motor serial number in the spaces provided to assist you in ordering spare parts from your dealer or for reference in case your outboard motor is stolen.
- Page 4 Engine serial number The engine serial number is carved on the aluminum casting of engine. Engine serial number as follows: Manufacturer’s Declaration This outboard motor complies with the requirements of Directive 2003/44/EC in relation to the exhaust and noise emissions. The following installation and maintenance instructions, if applied, guarantee that the outboard motor will remain in compliance with: 1.
- Page 5 High Altitude Warning Operation at High Altitude The density of air at high altitude is lower than at sea level. Engine power is reduced as the air mass and air fuel ratio decrease. Outboard motor output will be reduced. This is a natural trend and cannot be changed by adjusting the engine.
- Page 6 WARNING Operating the engine with the wrong engine configuration at a given altitude may increase its emissions and decrease fuel efficiency and performance. When the carburetor has been modified for high altitude operation, the air-fuel mixture will be too lean for low altitude use. Operation at altitudes below 609.6 meters (2,000 feet) with a modified carburetor may cause the engine to overheat and result in serious engine damage.
-
Page 7: Table Of Contents
Table of contents 1. Main components and General information ....................1 1.1 Main components ........................... 1 1.2 General information ..........................5 1.2.1Specification ............................5 1.2.2 Fueling instruction ..........................6 1.2.3 Propeller selection ..........................7 2. Operation ..............................8 2.1 Installation .............................. 8 2.1.1 Mounting height ........................... - Page 8 2.11.1 Cruising in shallow water ......................... 29 2.11.2 Cruising in salt water ........................29 2.12 Warning indicators and solutions ......................30 3. Maintenance ............................31 3.1 Greasing ............................... 32 3.2 Cleaning and adjusting spark plug ....................... 33 3.3 Checking the fuel system ........................33 3.3.1 Cleaning the fuel filter ........................
- Page 9 5.1 Impact damage ............................. 49 5.2 Starter will not operate .......................... 49 5.3 Treatment of submerged motor ......................52 6. Troubleshooting ............................53 7. Circuit diagram ............................57 https://www.boat-manuals.com/...
-
Page 10: Main Components And General Information
1. Main components and General information 1.1 Main components 1.Top cowling 8.Clamp bracket 15.Throttle grip 2.Top cowling lock handle 9.Tiller handle 16.Clam bolt 3.Drain screw 10.Starters handle 17.Fuel joint 4.Anti-cavitation plate 11.Warning indicator 18.Fuel tank 5.Propeller 12.Gear shift lever 19.Remote control box 6.Cooling water inlet 13.Engine stop button 7.Tilt &... - Page 11 A portable fuel tank includes parts as follows: 1. Fuel tank cap 3. Air vent screw 2. Fuel joint 4. Fuel gauge WARNING： The fuel tank supplier with this engine could only be used as supply of fuel for its running and must not be as a fuel storage container.
- Page 12 Remote control lever Moving the lever forward from the neutral position engages forward gear. Pulling the lever back from neutral engages reverse. The engine will continue to run at idle until the lever is moved about 35º (a detent can be felt). Moving the lever farther opens the throttle, and the engine will begin to accelerate. Neutral “N”...
- Page 13 NOTE: The neutral throttle lever will operate only when the remote control lever is in neutral. The remote control lever will operate only when the neutral throttle lever is in the closed position. 1. Fully open 2. Fully closed https://www.boat-manuals.com/...
-
Page 14: General Information
1.2 General information 1.2.1Specification Main technical data: Items Data Items Data Type of engine Two cylinders,4-stroke Weight (BML/BWL/FWL) 53.7Kg/55.7Kg/54.7Kg Displacement 362cm Recommended fuel Unleaded regular gasoline Bore X stroke 63mm×58.1mm Fuel tank capacity Gear ratio 2.08（27/13） Recommended engine oil SAE10W30 or SAE10W40 Overall length(B/FW) 988mm/665mm Engine oil quantity... -
Page 15: Fueling Instruction
1.2.2 Fueling instruction Fueling instructions： Recommended gasoline: Regular unleaded gasoline，If it is not available, then premium gasoline. If knocking or pinging occurs, use a different brand of gasoline or premium unleaded fuel. If leaded gasoline is usually used, engine valves and related parts should be inspected after every 100 hours of operation. -
Page 16: Propeller Selection
Engine oil: Recommended engine oil: 4-stroke outboard motor oil SAE10W30 and SAE10W40(1.6L). WARNING： Do not start the engine when the oil level is low. Serious damage might occur. Always check the oil level before starting the engine. CAUTION: All 4-stroke engines are shipped from the factory without engine oil. -
Page 17: Operation
2. Operation 2.1 Installation Mount the outboard motor on the center line (keel line) of the boat. For boats without a keel or which are asymmetrical, consult your dealers. 1. Center line (keel line) NOTE: During water testing check the buoyancy of the boat, at rest, with its maximum load. Check that the static water level on the exhaust housing is low enough to prevent water entry into the power head, when water rises due to waves when the outboard is not running. -
Page 18: Mounting Height
The optimum mounting height of the outboard motor is affected by the boat and motor combination and the desired use. Test runs at a different height can help determine the optimum mounting height. For further information, consult your “PARSUN” dealer or boat manufacturer. https://www.boat-manuals.com/... -
Page 19: Clamping The Outboard Motor
2.1.2 Clamping the outboard motor 1. Tighten the transom clamp screw evenly and securely. Occasionally check the clamp screws for tightness during operation of the outboard motor because they could become loose due to engine vibration. CAUTION: Outboards that use clamp bracket screws alone are INSUFFICIENT to properly and safely secure the outboard to the Transom. -
Page 20: Breaking In Engine
3. Secure the clamp bracket to the transom using the appropriate bolts. For details, consult your dealer. WARNING： Avoid using bolts, nuts or washers inappropriate. After tightening, test running the engine and check their tightness. 2.2 Breaking in engine Your new engine requires a period of breaking to allow mating surfaces of moving parts to wear in evenly. CAUTION Failure to follow the break-in procedure could result in reduced engine life or even severe engine Damage. -
Page 21: Pre-Operation Checks
2.3 Pre-operation checks Fuel ·Check to be sure you have plenty of fuel for your trip. ·Make sure there are no fuel leaks or gasoline fumes. ·Check fuel line connections to be sure they are tight. ·Be sure the fuel tank is positioned on a secure, flat surface, and that the fuel line is not twisted or flattened, or likely to contact sharp objects. -
Page 22: Filling Fuel
2. Check the oil level using the dipstick to be sure the level falls between the upper and lower marks. Fill with oil if it is below the lower mark, or drain to the specified level if it is above the upper mark. 1. -
Page 23: Starting Engine
2.5 Starting engine 1. Connect fuel joints securely after loosing the air vent screw on the fuel tank cap (2 or 3 turns). 2. Connect fuel joints securely and squeeze the primer pump with the outlet end up until you feel it become firm (if equipped the fuel joint). - Page 24 3. Place the gear shift lever in neutral. NOTE: The start-in-gear protection device prevents the engine from starting except when in neutral. Attach the engine stop switch lanyard to secure place on your clothing, or your arm or leg. Then install the lock plate on the other end of the lanyard into the engine stop switch.
- Page 25 4. Place the throttle grip in the “START” position (manual start). Turn the main switch to “ON” (Electric start). NOTE: It is not necessary to use the choke when starting a warm engine. If the choke is left in the “START” (start) position while the engine is running, the engine will run poorly or stall.
- Page 26 5. Pull the manual starter handle slowly until you feel resistance. Then give a strong pull straight to crank and start the engine. Repeat if necessary. Turn the main switch to “START” (start), and hold it for a maximum or 5 seconds (Electric start). 6.
-
Page 27: Warm Up Engine
2.6 Warm up engine 1. After starting the engine, place the gear shift lever in neutral. For approximately the first 3 minutes after starting, warm up the engine by operating at one fifth throttle or less. Otherwise, it will shorten engine life. NOTE: If the choke knob is left pulled out after the engine starts, the engine will stall. -
Page 28: Shifting
2.7 Shifting WARNING： Before shifting, make sure there are no swimmers or obstacles in the water near you. CAUTION: To shift from forward to reverse or vice versa, first close the throttle so that the engine idles (or runs at low speeds). 2.7.1 Forward 1. -
Page 29: Reverse
2.7.2 Reverse WARNING： When operating in reverse, go slowly. Do not open the throttle more than half. Otherwise the boat could become unstable, which could result in loss of control and an accident. 1. Place the throttle trip in the fully closed position. 2. -
Page 30: Tiller
2.8 Tiller 1. Change direction To change direction, move the tiller handle to the left or right as necessary. 2. Change speed Turn the grip counterclockwise to increase speed and clockwise to decrease speed. 3. Throttle indicator The throttle indicator is on the throttle grip. The fuel consumption curve on the throttle indicator shows the relative amount of fuel consumed for each throttle position. - Page 31 4. Throttle friction adjuster The throttle friction adjuster is on the tiller handle, which provides adjustable resistance to movement of the throttle grip, and can be set according to operator preference. To increase resistance, turn the adjuster clockwise. To decrease resistance, turn the adjuster counterclockwise. When constant speed is desired, tighten the adjuster to maintain the desired throttle setting.
-
Page 32: Stopping Engine
2.9 Stopping engine NOTE: Before stopping the engine, first let it cool off for a few minutes at idle or low speed. Stopping the engine immediately after operating at high speed is not recommended. 1. Push and hold the engine stop button until the engine comes to a complete stop. NOTE: If the outboard motor is equipped with an engine stop switch lanyard, the engine can also be stopped by pulling the lanyard and removing the lock plate from the engine stop switch. -
Page 33: Trimming Outboard Motor
3. Disconnect the fuel line. 2.10 Trimming outboard motor There are 4 or 5 holes provided in the clamp bracket to adjust the outboard motor trim angle. 1. Stop the engine. 2. Remove the trim rod from the clamp bracket while slightly tilting the outboard motor up. 3. - Page 34 WARNING： Stop the engine before adjusting the trim angle. Use care to avoid being pinched when removing or installing the rod. Use caution when trying a trim position for the first time. Increase speed gradually and watch for ...
-
Page 35: Tilting Up
If the engine will be stopped for some time or if the boat is moored in shallows, the outboard motor should be tilted up to protect the propeller and casing from damaged by collision with obstructions, and also to reduce corrosion. WARNING：... - Page 36 Tighten the steering friction adjuster by turning it clockwise to prevent the motor from turning freely. 3. Disconnect the fuel line from the outboard motor. Place the tilt lock lever (if equipped) in the up position. https://www.boat-manuals.com/...
-
Page 37: Tilting Down
5. Hold the rear handle and tilt the engine up fully until the tilt support lever automatically locks. 2.10.2 Tilting down 1. Slightly tilt the outboard motor up. 2. Slowly tilt the outboard motor down while place the tilt lock lever in the down position. 3. -
Page 38: Cruising In Other Conditions
WARNING： If there is too much resistance it could be difficult to steer, which could result in an accident. 2.11 Cruising in other conditions 2.11.1 Cruising in shallow water The outboard motor can be tilted up partially to allow operation in shallow water. WARNING：... -
Page 39: Warning Indicators And Solutions
2.12 Warning indicators and solutions The engine equips oil pressure warning indicator and water temperature warning indicator. If the oil pressure becomes too low (insufficient engine oil) or too high (too much engine oil) when engine speed is over 2200rpm, the oil pressure warning indicator will be activated, and the engine will enter into the protection status, which limits the rpm. -
Page 40: Maintenance
WARNING: Do not start or run the engine before the above warnings are thoroughly checked and resolved, otherwise, serious engine damage could occur. 3. Maintenance While using the outboard motor, the periodic maintenance is necessary for you to ensure its performance. WARNING：... -
Page 41: Greasing
3.1 Greasing https://www.boat-manuals.com/... -
Page 42: Cleaning And Adjusting Spark Plug
3.2 Cleaning and adjusting spark plug You should periodically remove and inspect the spark plug because heat and deposits will cause the spark plug to slowly break down and erode. If necessary, you should replace the spark plug with another of the correct type. -
Page 43: Cleaning The Fuel Filter
WARNING： Check for fuel leakage regularly. If any fuel leakage is found, the fuel system must be repaired by a qualified mechanic. 2. Check the fuel filter periodically. If foreign matter is found in the filter, clean it. 3.3.1 Cleaning the fuel filter 1. -
Page 44: Inspecting Idling Speed
3 . Remove the filter element, and wash it in solvent. Allow it to dry. Inspect the filter element and O-ring of the filter cup to make sure they are in good conditions. Change them if necessary. If any water is found in the fuel, check and clean the portable fuel tanks should be checked and cleaned. -
Page 45: Changing Engine Oil
CAUTION: Correct idling speed inspection is only possible if the engine is fully warmed up. If not warmed up fully, the idle speed will measure higher than normal. If you have difficulty verifying the idle speed, or the idle speed requires adjustment, consult your dealer or other qualified mechanic. 3.5 Changing engine oil WARNING：... - Page 46 3. Put a new gasket on the oil drain screw. Tighten the drain screw. 4. Add the correct amount of oil through the filler hole. Install the filler cap. 5. Start the engine and make sure that there are no oil leaks. 6.
-
Page 47: Checking Wiring And Connectors
3.6 Checking wiring and connectors Check that each grounding wire is properly secured and each connector is engaged securely. 3.7 Checking for leakage Check that no exhaust or water leaks from the joints between the exhaust cover, cylinder head and body cylinder. -
Page 48: Removing The Propeller
1. Check each of the propeller blades for wear, erosion from cavitation or ventilation, or other damage. 2. Check the propeller shaft for damage. 3. Check the splines’ shear pin for wear or damage. 4. Check for fish line tangled around the propeller shaft. 5. -
Page 49: Changing Gear Oil
4. Tighten the propeller nut. Align the propeller nut with the propeller shaft hole. Insert a new cotter pin in the hole and bend the cotter pin ends. 3.9 Changing gear oil WARNING： Be sure the outboard motor is securely fastened to the transom or a stable stand. Never get under the lower unit while the outboard motor is tilted, even when the tilt support lever or knob is locked. -
Page 50: Cleaning Fuel Tank
CAUTION: Inspect the used oil after it has been drained. If the oil is milky, water is getting into the gear case which can cause gear damage. Consult your dealer. ） 5. Use a flexible or pressurized filling device; inject the gear oil into the gear oil drain screw hole.（250cm 6. -
Page 51: Checking And Replacing Anode(S)
3.11 Checking and replacing anode(s) Inspect the external anodes periodically. Remove scales from the surfaces of the anodes. Consult your dealer for replacement of external anodes. CAUTION: Do not paint anodes, as this would render them ineffective and can cause more rapid engine corrosion. -
Page 52: Maintenance Table
3.13 Maintenance Table When utilized under normal condition, maintained and repaired in the proper manner, the motor can work normally within the normal life period. The normal life of the engine is 350 hours or 10 years, whichever occurs first. Frequency of maintenance operations may be adjusted according to the operating conditions, but the following table gives general guidelines. - Page 53 Continuation /…1 Initial Every Item Operations 10 hours 50 hours 100 hours 200 hours ( 1 month ) ( 3 months ) ( 6 months ) ( 1 year ) Throttle link/throttle ○ cable/Throttle pick-up Check/adjustment timing ○ Water pump Check ●...
-
Page 54: Transporting And Storing
4 Transporting and storing 4.1 Transporting The outboard motor should be trailed and stored in the normal running position. If there is insufficient road clearance in this position, then trailer the outboard motor in the tilt position using a motor support device. CAUTION: Do not use the tilt support lever or knob when trailing the boat. -
Page 55: Storing
4.2 Storing When store your outboard motor for prolonged periods of time (2 months or longer), several important procedures must be performed to prevent excessive damage. It is advisable to have your outboard motor serviced by an authorized dealer prior to storage. However, you, the owner, with a minimum of tools, can perform the following procedures. - Page 56 CAUTION: If the fresh water level is below the level of the anti-cavitation plate, or if the water supply Is insufficient, engine seizure may occur. WARNING： Do not touch or remove electrical parts when starting or during the operation. ...
-
Page 57: Flusher
4.3 Flusher Perform this procedure right after operation for thorough flushing. CAUTION: Do not perform this procedure while the engine is running. The water pump may be damaged from overheat, or serious damage can occur 1. After stopping the engine, remove the water pipe connector from the water pipe plug. 1. -
Page 58: Actions In Emergency
WARNING： Do not leave the water pipe connector loose on the bottom cowling water pipe plug or let the pipe hang free during normal operation. Water will leak out of the connector instead of cooling the engine, which can cause serious overheating. Be sure the connector is tightened securely on the pipe plug after flushing the engine. - Page 59 injure someone. Do not install the starter mechanism or top cowling after engine is running. Keep loose clothing and other objects away when starting the engine. Do not touch the flywheel or other moving parts when the engine is running. Do not touch the ignition coil, spark plug wire, spark plug cap, or other electrical components ...
- Page 60 4. Prepare the engine for starting. For further information, see section 2.5. 5. Insert the knotted end of the emergency starter rope into the notch in the flywheel rotor and wind the rope several turns around the flywheel clockwise. 6. Pull the rope slowly until resistance is felt. 7.
-
Page 61: Treatment Of Submerged Motor
5. Feed engine fogging oil or engine oil through the carburetor(s) and spark plug holes while starting the engine. 6. Take the outboard motor to a PARSUN dealer as soon as possible. CAUTION: Do not attempt to run the outboard motor until it has been completely inspected. -
Page 62: Troubleshooting
6. Troubleshooting Trouble type Possible reason Recovery action Starter components are faulty Have serviced by your dealer Starter will not operate Shift level is not in neutral Shift to neutral Fuel tank is empty Fill tank with clean, fresh fuel Fuel is contaminated or stale Fill tank with clean, fresh fuel Clean or replace with recommended... - Page 63 Continuation /…1 Trouble type Possible reason Recovery action Check for pinched or kinked fuel line or Fuel system is obstructed other obstructions in fuel system Fuel is contaminated or stale Fill tank with clean, fresh fuel Fuel filter clogged Clean or replace with recommended type Spark plug gap is incorrect Inspect and adjust as specified Check wires for wear or breaks.
- Page 64 Continuation /…2 Trouble type Possible reason Recovery action Propeller is damaged Repair or replace propeller Adjust trim angle to achieve most efficient Trim angle is incorrect operation Motor is mounted at incorrect transom Adjust motor to proper transom height height Boat bottom is fouled with marine growth Clean boat bottom Weeds or other foreign matter are tangled...
- Page 65 Continuation /…3 Trouble type Possible reason Recovery action Thermostat is faulty or clogged Have serviced by your dealer Air vent screw on fuel tank is closed Open air vent screw Fuel pump has malfunctioned Have serviced by your dealer Engine power loss Fuel joint connection is incorrect Connect correctly Check and replace spark plug(s) as...
-
Page 66: Circuit Diagram
7. Circuit diagram F15A/F20ABM 1. C.D.I. unit 2. Charge coil 3. Magneto coil 4. Lighting coil 5. Impulse coil 6. Solenoid valve 7. Ignition coil 8. Spark plug 9. Temperature switch 10. Oil pressure switch 11. Engine stop switch 12. Warning lamp https://www.boat-manuals.com/... - Page 67 F15A/F20ABW https://www.boat-manuals.com/...
- Page 68 13. Spark plug 1. C.D.I. unit 14. Temperature switch 2. Charge coil 15. Oil pressure switch 3. Magneto coil 16. Neutral switch 4. Lighting coil 17. Engine start switch 5. Impulse coil 18. Engine stop switch 6. Solenoid valve 19. Warning lamp 7.
- Page 69 F15A/F20AFW https://www.boat-manuals.com/...
- Page 70 13. Spark plug 1. C.D.I. unit 14. Temperature switch 2. Charge coil 15. Oil pressure switch 3. Magneto coil 16. Warning lamp 4. Lighting coil 17. Trim & tilt motor (For electric tilt model) 5. Impulse coil 18. Wiring terminal (For electric tilt model) 6.
