OUTBOARD MOTOR

OWNER'S MANUAL
F2.6BM
SUZHOU PARSUN POWER MACHINE CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Parsun F2.6BM

Summary of Contents for Parsun F2.6BM

  • Page 1: Outboard Motor

    OUTBOARD MOTOR OWNER’S MANUAL F2.6BM SUZHOU PARSUN POWER MACHINE CO., LTD.
  • Page 2 Thank you for owning a PARSUN outboard motor. Thank you for your trust in our company and products.  “PARSUN” outboard motors are powerful, economic and safe with advanced technology and processing technique.  Please read this manual carefully before operating your outboard motor. A through understanding of the manual will help you to know this product for proper operation, maintenance and care.
  • Page 3 Record your outboard motor serial number in the spaces provided to assist you in ordering spare parts from your Parsun dealer, or for reference in case your outboard motor is stolen. Outboard motor serial number location...
  • Page 4 Manufacturer’s Declaration This outboard motor complies with the requirements of Directive 2003/44/EC in relation to the exhaust and noise emissions. The following installation and maintenance instructions, if applied, guarantee that the outboard motor will remain in compliance with: 1. Exhaust emissions limits throughout the normal life or the engine (350 hours or 10 years, whichever occurs first) and under normal conditions of use.
  • Page 5 The part number and recommended minimum altitude for the application of the high altitude carburetor main jet are listed in the table below. MODEL MAIN JET PART NUMBER ALTITUDE Standard Main Jet H100-S F2.6 2000 Feet (609.6 Meters) Altitude Main Jet H100×1.08 WARNING Operating the engine with the wrong engine configuration at a given altitude may increase its...

  • Page 6: Table Of Contents

    Table of contents Main components and General information……………………..……..…………….………….…1 1.1. Main components……………………………..…….………….………………………….…..……1 1.2. General information………………………………………………………….…………………..….3 1.2.1. Specifications…………………………………………………….…………….……………….…3 1.2.2. Fueling instructions…….………………………………….…………..……………….……..…..4 1.2.3. Propeller selection…….……………………………………………….…………………..…...5 Operation…………….……….…………………………………………….………......6 Installation………………………………………………………………….……………....6 2.1.1. Mounting height………………………………………………………….……………....7 2.1.2. Clamping the outboard motor………………………..…………….….………….……....9 Breaking in engine……………………………………………………….…..…….....9 Pre-operation checks………………………………………………….…………….....10 Filling fuel……………………….………………………………………………......12 Starting engine……..…………………………………………………….………......13 Warming up engine.…………………………………………………….………..…....16 Shifting.…………………………………………………….…………….………....…..18 2.7.1.
  • Page 7 2.10 Trimming outboard motor………………………………………………………………..…23 2.11 Tilting up and down…………………………………………………………………..……...24 2.11.1. Tilting up………………………………………………………………………………..….24 2.11.2. Tilting down………………..……………………………………………………..…....26 2.12 Cruising in other conditions…………………………………………………………..……27 2.12.1. Cruising in shallow water…………………………………………………………..…..….27 2.12.2. Cruising in salt water………………………………………………………………..……28 Maintenance………………………………………………………………………………....29 Greasing………………………………………………………………………………....…29 Cleaning and adjusting spark plug………………………………………………..……..…30 Checking fuel system…………………………………………………………………..…...30 Inspecting idling speed………………………………………………………………..….…31 Changing engine oil…………………………………………………………………..…..….31 Checking wiring and connectors……………………………………………………..…..…33...
  • Page 8 3.12 Checking top cowling………….……………………………………………....…..38 3.13 Maintenance table………….………………………………………………....……..39 Transporting and storing outboard motor……..…………………..……….…....…..41 Transporting…………………………………………………………………....…..41 Storing…………………………………………………………….………....………..42 Action in emergency………………………………………..……..........44 Impact damage………………………………………………………………......44 Starter will not operate…………………………………….............44 Treatment of submerged motor…………………………….…………………......48 Troubleshooting………………………………………………….………………......50 Circuit diagram ………………………………………………….……………......54...

  • Page 9: Main Components And General Information

    1. Main components and General information 1.1 Main components 1.Top cowling 8.Clamp bracket 14.Throttle grip 2.Carrying handle 9.Tiller handle 15.Clamp screw 3.Steering friction screw 10.Engine stop button/ 16.Rope attachment 4.Anti-cavitation plate Engine stop lanyard switch 17.Gear shift lever 5.Propeller 11.Starter handle 18.Choke knob 6.Cooling water inlet 12.Top cowling lock levers...
  • Page 10 Your model includes a built-in fuel tank, its parts are as follows: 1. Air vent screw 3. Built-in fuel tank 2. Fuel tank cap 4. Fuel cock (close position) WARNING The fuel tank supplied with this engine could only be used as supply of fuel for its running and must not be as a fuel storage container.

  • Page 11: General Information

    1.2 General information 1.2.1 Specifications Parameter Items Data Items Data Type of engine 4-stroke S Recommended fuel Unleaded regular gasoline Displacement 72cm Built-in fuel tank capacity 1.2L Bore X stroke 54.0mm×31.5mm Recommended engine oil SAE10W30 or SAE10W40 Gear ratio 2.08（27/13） Engine oil quantity 0.35L Overall length...

  • Page 12: Fueling Instructions

    1.2.2 Fueling instructions Fueling instructions: Recommended gasoline: Regular unleaded gasoline, If it is not available, then premium gasoline. If knocking or pinging occurs, use a different brand of gasoline or premium unleaded fuel. If leaded gasoline is usually used, engine valves and related parts should be inspected after every 100 hours of operation.

  • Page 13: Propeller Selection

    “PARSUN” dealers stock a range of propellers and can advise you and install a propeller on your outboard that is best suited to your application.

  • Page 14: Operation

    2 Operation 2.1 Installation Mount the outboard motor on the center line (keel line) of the boat. For boats without a keel or which are asymmetrical, consult your dealer. center line (keel line) NOTE: During water testing check the buoyancy of the boat, at rest, with its maximum load. Check that the static water level on the exhaust housing is low enough to prevent water entry into the power head, when water rises due to waves when the outboard is not running.

  • Page 15: Mounting Height

    Improper mounting of the outboard motor could result in hazardous conditions. For permanently  mounted models, your dealer or other person experienced in proper rigging should mount the motor. If you are mounting the motor yourself, you should be trained by an experienced person. For portable models, your dealer or other person experienced in proper outboard motor mounting should show you how to mount your motor.

  • Page 16: Clamping The Outboard Motor

    The optimum mounting height of the outboard motor is affected by the boat and motor combination and the desired use. Test runs at a different height can help determine the optimum mounting height. For further information, consult your “PARSUN” dealer or boat manufacturer. 2.1.2 Clamping the outboard motor Tighten the transom clamp screw evenly and securely.

  • Page 17: Breaking In Engine

    Attach to a secure mounting point on the boat to avoid the engine being completely lost if it accidentally falls off the transom. 3. Secure the clamp bracket to the transom using the appropriate bolts. For details, consult your PARSUN dealer.

  • Page 18: Pre-Operation Checks

    2. For the second hour of operation: Run the engine at 3000 r/min or at approximately three-quarter throttle. 3. For the next eight hours of operation: Avoid continuous operation at full throttle for more than five minutes at a time. 4.
  • Page 19 Checking the engine oil level 1. Put the outboard motor in an upright position (not tilted). 2. Check the oil level using the oil level check window to be sure the level falls between the upper and lower marks. Fill with oil if it is below the lower mark, or drain to the specified level if it is above the upper mark.

  • Page 20: Filling Fuel

    Upper level mark Lower level mark WARNING: If any item in the pre-operation check is not working properly, have it inspected and repaired before operating the outboard motor. Otherwise an accident could occur. CAUTION: Do not start the engine out of water. Overheating and serious engine damage can occur. 2.4 Filling fuel WARNING：...

  • Page 21: Starting Engine

    3. Securely close the cap after filling the tank. Wipe up any spilled fuel. 2.5 Starting engine 1. Loosen the air vent screw on the fuel tank cap. One turn for built-in tank. 2. Open the fuel cock.
  • Page 22 3. Place the gear shift lever in neutral. NOTE: Attach the engine stop switch lanyard to secure place on your clothing, or your arm or leg. Then install the lock plate on the other end of the lanyard into the engine stop switch. WARNING: The engine must be started in neutral otherwise damage to the starter can occur.
  • Page 23 4. Place the throttle grip in the “START” (start) position. 5. Pull out the choke knob fully. NOTE:  It is not necessary to use the choke when starting a warm engine.  If the choke is left in the “START” (start) position while the engine is running, the engine will run poorly or stall.

  • Page 24: Warming Up Engine

    6. Pull the manual starter handle slowly until you feel resistance. Then give a strong pull straight to crank and start the engine. Repeat if necessary. 7. After the engine starts, slowly return the manual starter handle to its original position before releasing it. 8.
  • Page 25 If water is not flowing out of the hole at all times while the engine is running, stop the engine  and check whether the cooling water inlet on the lower case or the cooling water pilot hole is blocked. If the problem cannot be located and corrected, consult your PARSUN dealer. ...

  • Page 26: Shifting

    2.7 Shifting WARNING: Before shifting, make sure there are no swimmers or obstacles in the water near you. CAUTION: To shift from forward to reverse or vice versa, first close the throttle so that the engine idles (or runs at low speeds). 2.7.1 Forward 1.

  • Page 27: Reverse

    2.7.2 Reverse WARNING: When operating in reverse, go slowly. Do not open the throttle more than half. Otherwise the boat could become unstable, which could result in loss of control and an accident. 1. Place the throttle trip in the fully closed position. 2.

  • Page 28: Tiller

    NOTE: The outboard motor can turn 360° in its bracket (full-pivot system). The boat can also be backed up by simply turning the outboard motor around 180° with the steering handle facing toward you. 2.8 Tiller 1. Change direction To change direction, move the tiller handle to the left or right as necessary. 2.
  • Page 29 Choose the setting that offers the best performance and fuel economy for the desired operation. 1.Throttle indicator 4. Throttle friction adjuster The throttle friction adjuster is on the tiller handle, which provides adjustable resistance to movement of the throttle grip, and can be set according to operator preference. To increase resistance, turn the adjuster clockwise.

  • Page 30: Stopping Engine

    2.9 Stopping engine NOTE: Before stopping the engine, first let it cool off for a few minutes at idle or low speed. Stopping the engine immediately after operating at high speed is not recommended. PROCEDURE: 1. Push and hold the engine stop button until the engine comes to a complete stop. NOTE: If the outboard motor is equipped with an engine stop switch lanyard, the engine...

  • Page 31: Trimming Outboard Motor

    2.10 Trimming outboard motor There are 4 or 5 holes provided in the clamp bracket to adjust the outboard motor trim angle. 1. Stop the engine. 2. Remove the trim rod from the clamp bracket while slightly tilting the outboard motor up.

  • Page 32: Tilting Up And Down

    WARNING:  Be sure all people are clear of the outboard motor when tilting up and down, also be careful not to pinch any body parts between the drive unit and engine bracket.  Tighten the air vent screw and place the fuel cock in the closed position if the outboard motor will be tilted for more than a few minutes.
  • Page 33 2. Tighten the steering friction adjuster by turning it clockwise to prevent the motor from turning freely. 3. Tighten the air vent screw. 4. Close the fuel cock.

  • Page 34: Tilting Down

    Hold the rear handle and tilt the engine up fully until the tilt support lever automatically locks. 2.11.2 Tilting down 1. Slightly tilt the outboard motor up. 2. Slowly tilt the outboard motor down while pulling the tilt support bar lever up.

  • Page 35: Cruising In Other Conditions

    3. Loose the steering friction adjuster by turning it counterclockwise, and adjust the steering friction according to operator preference. WARNING: If there is too much resistance it could be difficult to steer, which could result in anaccident. 2.12 Cruising in other conditions 2.12.1 Cruising in shallow water The outboard motor can be tilted up partially to allow operation in shallow water.

  • Page 36: Cruising In Salt Water

    CAUTION: The cooling water inlet on the lower unit should be not above the surface of the water when setting up for and cruising in shallow water. Otherwise severe damage from overheating can result. For tilting procedure, see section 2.11. 2.12.2 Cruising in salt water After operating in salt water, wash out the cooling water passages with fresh water to prevent them from becoming clogged with salt deposits.

  • Page 37: Maintenance

    WARNING: Be sure to turn off the engine when you perform maintenance unless otherwise specified. If you or the owner is not familiar with machine servicing, this work should be done by your PARSUN dealer or other qualified mechanic. CAUTION: If replacement parts are necessary, use only genuine PARSUN parts or parts of the same type and of equivalent strength and materials.

  • Page 38: Cleaning And Adjusting Spark Plug

    3.3 Checking the fuel system 1. Check the fuel lines for leaks, crack, or malfunction. If a problem is found, your PARSUN dealer or other qualified mechanic should repair it immediately.

  • Page 39: Inspecting Idling Speed

    Correct idling speed inspection is only possible if the engine is fully warmed up. If not warmed up fully, the idle speed will measure higher than normal. If you have difficulty verifying the idle speed, or the idle speed requires adjustment, consult a PARSUN dealer or other qualified mechanic. 3.5 Changing engine oil WARNING: ...
  • Page 40 CAUTION: Change the engine oil after the first 10 hours of operation, and every 100 hours or at 6-month intervals thereafter. Otherwise the engine will wear quickly. Change the engine oil when the oil is still warm. 1. Put the outboard motor in an upright position (not tilted). 2.

  • Page 41: Checking Wiring And Connectors

    3.7 Checking for leakage Check that no exhaust or water leaks from the joints between the exhaust cover, cylinder head, and body cylinder. Check for oil leaks on the around the engine. CAUTION: If any leaks are found, consult your PARSUN dealer.

  • Page 42: Checking Propeller

    3.8 Checking propeller WARNING:  Before inspecting, removing or installing the propeller, always take actions to ensure the enginewill not accidentally starts, such as removing the spark plug caps from the spark plugs, placing the shift control in neutral, and removing the lanyard from the engine stop switch, etc.. Serious accident could occur if the engine starts when you are nearby.

  • Page 43: Removing The Propeller

    5. Check for the propeller shaft oil seal for damage. 3.8.1 Removing the propeller 1. Straighten the cotter pin and pull it out using a pair of pliers. 2. Remove the propeller nut, washer, and spacer (if equipped). 3. Remove the propeller and thrust washer. 1.

  • Page 44: Changing Gear Oil

    4. Tighten the propeller nut. Align the propeller nut with the propeller shaft hole. Insert a new cotter pin in the hole and bend the cotter pin ends. 3.9 Changing gear oil WARNING:  Be sure the outboard motor is securely fastened to the transom or a stable stand. ...

  • Page 45: Cleaning Fuel Tank

    Inspect the used oil after it has been drained. If the oil is milky, water is getting into the gear case which can cause gear damage. Consult PARSUN dealer. 5. Use a flexible or pressurized filling device, inject the gear oil into the gear oil drain screw hole.

  • Page 46: Checking And Replacing Anode(S)

    3.11 Checking and replacing anode(s) Inspect the external anodes periodically. Remove scales from the surfaces of the anodes. Consult a PARSUN dealer for replacement of external anodes. CAUTION: Do not paint anodes, as this would render them ineffective and can cause more rapid engine corrosion.

  • Page 47: Maintenance Table

    Frequency of maintenance operations may be adjusted according to the operating conditions, but the following table gives general guidelines. The “●” symbol indicates the check-ups which you may carry out by yourself. The “○” symbol indicates work to be carried out by your Parsun dealer. Initial Every...
  • Page 48 Continuation /…1 Initial Every Item Operations 10 hours 50 hours 100 hours 200 hours ( 1 month ) ( 3 months ) (6 months ) ( 1 year ) ○ Thermostat Check Throttle link/throttle ○ Check/ cable/Throttle pick-up adjustment timing ○...

  • Page 49: Transporting And Storing Outboard Motor

    4 Transporting and storing 4.1 Transporting The outboard motor should be trailed and stored in the normal running position. If there is insufficient road clearance in this position, then trailer the outboard motor in the tilt position using a motor support device. CAUTION: Do not use the tilt support lever or knob when trailering the boat.

  • Page 50: Storing

    When storing your PARSUN outboard motor for prolonged periods of time (2 months or longer), several important procedures must be performed to prevent excessive damage. It is advisable to have your outboard motor serviced by an authorized PARSUN dealer prior to storage.However, you, the owner, with a minimum of tools, can perform the following procedures.
  • Page 51 5. Fill the tank with fresh water to above the level of the anti-cavitation plate. CAUTION: If the fresh water level is below the level of the anti-cavitation plate, or if the water supply is insufficient, engine seizure may occur. 6.

  • Page 52: Action In Emergency

    2. Inspect the control system and all components for damage. 3. Whether damage is found or not, return to the nearest harbor slowly and carefully. 4. Have a PARSUN dealer inspect the outboard motor before operating it again. 5.2 Starter will not operate If the starter mechanism does not operate, the engine can be started with an emergency starter rope.
  • Page 53 The procedure is as follows: 1. Remove the top cowling. 2. Remove the fuel tank bolts. 3. While lifting the fuel tank up, remove the bolt from the starter case. While lifting the starter case up, disconnect the choke wire from the carburetor.
  • Page 54 5. Remove the starter case. 6. Install the fuel flywheel case by installing the bolts. 7. Install 2 bolts into the rear section of the fuel tank. 8. Prepare the engine for starting. For further information, see section 2.5.
  • Page 55 9. Turn the lever on the carburetor to operate the choke system when the engine is cold. After the engine starts, return the lever to the original position. 10. Insert the knotted end of the emergency starter rope into the notch in the flywheel rotor and wind the rope several turns around the flywheel clockwise.

  • Page 56: Treatment Of Submerged Motor

    5.3 Treatment of submerged motor If the outboard is submerged, immediately take it to a PARSUN dealer. Otherwise some corrosion may begin almost immediately. 1. Thoroughly wash away contaminants with fresh water. 2. Remove the spark plug(s), then face the spark plug hole downward to allow any mud, or contaminants to drain.
  • Page 57 6. Take the outboard motor to a PARSUN dealer as soon as possible. CAUTION: Do not attempt to run the outboard motor until it has been completely inspected.

  • Page 58: Troubleshooting

    6. Troubleshooting Trouble type Possible reason Recovery action Starter components are faulty Have serviced by your dealer Starter will not operate Shift level is not in neutral Shift to neutral Fuel tank is empty Fill tank with clean, fresh fuel Fuel is contaminated or stale Fill tank with clean, fresh fuel Inspect spark plug(s).
  • Page 59 Continuation /…1 Trouble type Possible reason Recovery action Spark plug gap is incorrect Inspect and adjust as specified Check wires for wear or breaks. Ignition wiring damaged or poorly Tighten all loose connections. connected Replace worn or broken wires Specified engine oil is not being used Check and replace oil as specified Engine idles Thermostat is faulty or clogged...
  • Page 60 Continuation /…2 Trouble type Possible reason Recovery action Weeds or other foreign matter are tangled Remove foreign matter and clean on gear housing lower unit Spark plug(s) are fouled or incorrect Inspect spark plug(s). Clean or type replace with recommended type Check for pinched or kinked fuel line Fuel system is obstructed or other obstructions in fuel system...
  • Page 61 Continuation /…3 Trouble type Possible reason Recovery action Propeller is damaged Repair or replace propeller Propeller shaft is damaged Have serviced by your dealer Weeds or other foreign matter are tangled on Engine vibrates Remove and clean propeller propeller excessively Motor mounting bolt is loose Tighten bolt Steering pivot is loose...

  • Page 62: Circuit Diagram

    7. Circuit diagram Spark plug Earthing Engine stop switch Ignitor ass'y black Magnet flywheel white S N . DESCRIPTION...
