EverFocus EZ430/MV2 Specifications

Color Cameras
EZ430
520 TVL IR Bullet Style Weatherproof Color Camera
Features
520 TVL of excellent high resolution technology
•
Motorized lens controller for easy zoom and focus
•
lens adjustment
• Vari-focal lens to offer you a wide variety of
angle viewing
• True Day/Night function with removable IR cut filter
• IRIS level adjustment
• Cable wires are placed inside camera bracket to
eliminate messy wiring and damage
Intelligent vari-frequency for IR control
•
(brightness balance & energy saving)
Split glass design to avoid LED light reflection
•
• Up to 30 meters/98 ft. of IR range
• Up to 20,000 hours of IR LED lifespan
• Vandal resistant for intentional destruction
• Weatherproof and IP66 rated
Dimensions
Infrared Cameras

Specifications

Pickup Device
Video Format
Scanning System
Picture Elements
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Lens Type
Backlight Comp.
Auto Gain Control
Auto White Balance
True Day/Night
Gamma Correction
Video Output
Sync. Mode
Power Source
Power Consumption
Dimensions (L x W x H)
Weight
Operating Temperature
Humidity
IR Distance
IR Wavelength
IR LED Lifespan
Weatherproof
Vandal Resistant
Heater

Ordering Information*

1/3" Sony Super HAD CCD
NTSC or PAL
NTSC: 525 TVL, 60 fields/sec.
PAL: 625 TVL, 50 fields/sec.
768 x 494 (NTSC) / 752 x 582 (PAL)
520 TVL
0.4 Lux / F=1.2 (IR OFF), 0 Lux (IR ON)
Over 48 dB (AGC Off )
1/50 (1/60) ~ 1/100,000
Vari-focal lens f=2.9~10mm , f=9~22mm
Yes
Yes
Yes (2500°K ~ 9000°K)
Yes, with IR cut filter
0.45
BNC 1.0Vp-p, 75ohm
Internal sync.
12VDC/24VAC
12VDC: 12W max. (Heater ON & IR LED ON)
24VAC: 15W max. (Heater ON & IR LED ON)
235.3 x 88 x 174.2 mm / 9.26" x 3.46" x 6.86"
(with bracket & sunshield)
1.15 kg / 2.53 lbs. (with bracket & sunshield)
-40°C ~ 50°C / -40°F ~ 122°F
20% ~ 80% Humidity
30M / 98 ft.
850nm
20,000 hours
IP66 rated
Yes
Yes, built-in
EZ430/MV3: 520 TVL, Bullet IR, IP66, f=2.9~10mm lens
EZ430/MV2: 520 TVL, Bullet IR, IP66, f=9~22mm lens
*Models vary in different countries. Please visit EverFocus regional websites for
detailed ordering information.
28
