EverFocus EMC500NHWX Specifications

Color Cameras
EM-C500NHWX
550 TVL Discreet Mini Cylinder Style Color Camera
IP67
Features
1/3" Sony ICX638 Super HAD CCD
•
550 TVL of horizontal resolution
•
Small cylinder style color camera with superior image
•
19mm / 0.75" in diameter
•
Low light sensitivity of 0.2 Lux
•
Low current consumption of 90mA max.
•
Ideal for indoor or outdoor discreet surveillance
•
IP67 rated
•
Dimensions
54.7 mm / 2.2"
1/4" - 20UNC
500 mm /19.7"
27
Bullet Style Cameras
550
Mounting Hole
(1/4" - 20UNC)

Specifications

NTSC
Video Format
1/3" Sony ICX638 Super HAD CCD
Image Sensor
2:1 Interlace
Scanning System
H: 15.734 KHz, V: 59.94 Hz
Scanning Frequency
811 (H) x 508 (V), 401K
Total Pixels
768 (H) x 494 (V), 380K
Effective Pixels
550 TVL
Horizontal Resolution
1/60 ~ 1/100,000 sec. (auto)
Electronic Shutter
Over 45 dB (AGC Off)
S/N Ratio
BNC 1.0 Vp-p, 75 ohm
Video Output
0.45
Gamma Correction
Internal Sync.
Sync. Mode
Auto
Backlight Comp.
Auto
Auto Gain Control
0.2 Lux/F=2.0
Sensitivity
3.6mm lens
Lens
12VDC
Power Source
90mA max.
Power Consumption
54.7 x 19 x 19 mm / 2.2" x 0.75" x 0.75"
Dimensions (L x W x H)
91 g / 0.2 lbs.
Weight
-10°C ~ 45°C / 14°F ~ 122° F
Operating Temp.
-20°C ~ 60°C / -4°F ~ 140°F
Storing Temp.

Ordering Information

EM-C500NHWX: 550 TVL, Mini Cylinder Camera,
IP67, 3.6mm lens
