EverFocus EMC700 Specifications

EMC700
Outdoor Day/Night Mini Bullet Camera
Features
• Ultra resolution of over 720 horizontal TV lines for
astounding image quality
• Exview HAD II sensor delivers amazing ultra high
sensitivity of .05 lux – very low light sensitivity
without DSS low light boost - Zero Ghosting
guaranteed
• Astounding image quality from the 3.6mm lens
• Digital Wide Dynamic Range expansion to deliver
properly exposed images despite unbalanced
lighting in the scene
• Provides 2D-Noise Reduction to improve picture
clarity while enabling DVRs to improve disk storage
utilization
• Easy to use OSD setup menu with local controls or
RS-485 remote control
• Compact cylinder is suitable for indoor or outdoor
covert/discrete surveillance, or coverage where
space is limited
• The flexible angle viewing with its 3 Axis rotation
design allows wall or ceiling mounting
• IP67 weather resistant rating means that it will
withstand the elements of outdoor conditions
Dimensions: mm/in
90.7
75.2
16.8
Ordering Info
EMC700: Day/Night Cylinder Camera, Black, 720+ TVL, 3.6mm
2012 EverFocus Product Catalog Vs 1.1 - Models vary in different countries. Visit www.everfocus.com and select your country for additional ordering and specification information.
39
1/4"-20 UNC
10.5
Joy-Stick
Control Rubber
EverFocus is not responsible for typographical errors. Product specifications are subject to change without notice.
www.everfocus.com
U
720+
720
+
Ultra Series
2D
Noise
Reduction

Specifications

Part Number
1/3" Sony Exview HAD II 960H High Sensitivity Interline
Pickup Device
Video Format
Picture Elements
Effective Pixels (NTSC |
PAL)
Scanning System
Scanning Frequency
Horizontal Resolution
Sensitivity
S/N Ratio
Electronic Shutter
Video Output
Gamma Correction
Lens Type
Lens Options
BLC
HLC
Gain Control
White Balance
Sync Mode
Day/Night
OSD Menu
English, Spanish, French, Chinese, German, Japanese,
OSD Languages
Digital Noise Reduction
ATR
Motion Detection
Privacy Mask
Power Source
Power Consumption
Operating Temp
Humidity
Dimensions (in | mm)
Weight (lbs | gm)
Mount
Certifications
Analog Solutions
OSD
12VDC
Waterproof
IP67
EMC700
CCD
NTSC or PAL
1020 x 508 (NTSC) | 1020 x 508 (NTSC)
976 x 494 (NTSC) | 976 x 582 (PAL)
2:1 Interlace
H: 15.734 KHz, V: 59.94 Hz | H: 15.625KHz, V: 50Hz
720+ TVL
.05 Lux
Over 50dB (AGC off)
1/60s~1/100,000s
BNC 1.0Vp-p 75Ω
0.45
3.6mm
Fixed
On
On
Auto
ATW/One Push/User2/Anti-Crawl/Manual/Push Lock
Internal Sync
Auto Digital Day/Night
Multiple Functions
Portuguese, Russian
2D-DNR
Wide Range ATW (1,800K to 10,500k)
Off/On for 4 selectable zones
Off/On for 4 selectable zones
12VDC regulated supply required
110mA (1.32W)
14°F~122°F | -10°C~50°C
Less than 80% non-condensing
Body alone: .9" (22.86mm) diameter/3" (76.2mm) long
; | 5.52" (140.21mm) in line, longest extension; in 90°
position, ~4.95 (125.73mm)" long and 2.75" (69.85mm)
high
0.2lbs | 91g
Mount Bracket Included
CE/FCC
DIGITAL
WDR
