SURFACE MOUNTED WITH A
UNIVERSAL MOUNTING BRACKET
FLUSH MOUNT USING MOUNTING SCREWS:
USING THE TEMPLATE, MARK LOCATION OF
OPENING AND MOUNTING HOLES ON WALL.
DRILL HOLES APPROPRIATE TO MOUNTING
HARDWARE AND CUT OUT THE OPENING.
PENDANT MOUNTING WITH
OPTIONAL CHAIN AND
'EYE' SCREW
UNIVERSAL BRACKET
UNIVERSAL BRACKET WITH CLAMP
"C" CLAMP FOR "I" BEAM MOUNTING
ATTACH CLAMP TO HORN
HOLDING FLEXHORN FIRMLY AGAINST A FLAT
SURFACE, DRILL THROUGH EACH MOUNTING BOSS
AS SHOWN.
OTHER MOUNTING OPTIONS:
5
ATTACH FLEXHORN TO BEAM
FLUSH MOUNTING IN A STUD WALL
INSTALLED WITH MOUNTING SCREWS
OR CONSTRUCTION CEMENT.
OPTIONAL V-9805
VANDAL RESISTANT ENCLOSURE
947826
