- Page 1 MOTORIZED TREADMILL SF-T7603 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).
-
Page 2: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION When using an electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using this treadmill. DANGER – To reduce the risk of electric shock: 1. Always unplug this treadmill from the electrical outlet immediately after using and before cleaning. WARNING –... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly. It is your responsibility to ensure that all users of the equipment are informed of all warnings and precautions. -
Page 4: Important Note
IMPORTANT OPERATING INSTRUCTION 1. Insert the power plug directly into the socket. 2. Read the manual before operating the equipment. 3. Changes in speed do not occur immediately. Set your desired speed using the adjustment keys on the main console. The speed will increase gradually. 4. -
Page 5: Exploded Diagram
EXPLODED DIAGRAM... -
Page 6: Parts List
PARTS LIST Description Spec. Qty. Description Spec. Qty. Base Frame Allen Socket Bolt M8*40 Main Frame Allen Socket Bolt M8*45 Computer Bracket Allen Socket Screw M10*35 Left Upright Tube Allen Socket Bolt M6*55 Right Upright Tube Allen Socket Screw M6*45 Motor Bracket Allen Screw M6*35... -
Page 7: Hardware Package
HARDWARE PACKAGE Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: The model number (found on cover of manual) The product name (found on cover of manual) ... - Page 8 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 1: Open the carton and remove contents. Place the Main Frame (No. 2) on the ground and ensure you have a work area that is clean and has adequate space.
- Page 9 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 4: During assembly, support the Left & Right Upright Tubes (No. 4 & No. 5) with your hands to prevent them from falling.
- Page 10 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 6: Attach the Left & Right Upright Tube Covers (No. 33 & No. 34) to the Base Frame (No.
-
Page 11: Maintenance And Care
MAINTENANCE & CARE General cleaning will help prolong the life and performance of your treadmill. Keep the unit clean and maintained by dusting the components on a regular basis. Clean both sides of the Running Belt (No. 20) to prevent dust from accumulating underneath. Keep your running shoes clean so that dirt from your shoes does not wear out the Running Board (No. -
Page 12: Lubricating The Treadmill
LUBRICATING THE TREADMILL IMPORTANT NOTE: You will need to lubricate your treadmill before the first use. RUNNING BELTS & TREADMILL LUBRICANT: Lubricating the Running Board (No. 70) and Running Belt (No. 20) is essential as the friction between the two affects the life span and function of the treadmill. It is suggested that the Running Board (No. -
Page 13: Folding Instructions
FOLDING INSTRUCTIONS FOLDING: Place your hand at position “G” and lift Main Frame (No. 2) up until the Air Pressure Cylinder (No. 13) locks into the tube. When Pressure Cylinder (No. 13) successfully locks into the tube, you will hear a “click”... -
Page 14: How To Move The Treadmill
HOW TO MOVE THE TREADMILL Before attempting to move the treadmill, please make sure that it has been properly folded. Unplug the power cord. Start by placing one hand at position “G” to support the top end of the treadmill. Next, place one foot at position “I”... -
Page 15: Adjusting The Incline
ADJUSTING THE INCLINE ATTENTION: For your safety and convenience, always fold the treadmill (as shown below) before attempting to adjust the incline. There are three holes located on the Adjustable Foot Pad (No. 29). To adjust the level of incline, remove 2 Fixing Pins (No. 7) from the left and right side. Align the holes of the Adjustable Foot Pad (No. -
Page 16: Important Electrical Information
IMPORTANT ELECTRICAL INFORMATION WARNING: This treadmill requires a power source of 10 amps (100-120V) in order to properly operate. For your safety, as well as the safety of others, please verify that the power source is correct before plugging the equipment. Any power source above or below this level could cause significant damage to the equipment and or user. -
Page 17: The Display Console
THE DISPLAY CONSOLE QUICK START 1. Insert the magnet end of the Safety Key (No. 66) into the computer console. 2. Press the START button, and the system will automatically display a 3 second countdown. Once the countdown reaches zero, the running belt will start at the initial default speed of 0.5 MPH. 3. -
Page 18: Window Display
WINDOW DISPLAY SPEED: Displays the current speed. The speed range on this treadmill is 0.5 - 9 MPH. When setting PROGRAMS, the speed is programmed in intervals. PROGRAMS are from P1-P9. When setting MODE, the window displays H1-H3. TIME: Displays the time elapsed (0:00-99:59 MINS). If the time reaches 99:59, the treadmill will stop smoothly and display “END”... -
Page 19: Function Keys
FUNCTION KEYS PROGRAM: Press the PROGRAM button to set your desired interval setting. Programs are displayed as P1-P9 and the various intervals are shown on the treadmill. MODE: Press this button to select a MODE. Pressing once will enter H1, the TIME countdown mode starting from 10:00 MINS. -
Page 20: Body Mass Index
TIME INTERVAL= setting time/10 TIME PROG 1.8 3.7 3.1 SPEED 1.8 2.5 2.5 SPEED 1.8 3.1 3.7 SPEED 3.7 3.7 3.7 SPEED 3.1 3.7 4.3 SPEED 6.2 6.2 5.0 SPEED 2.5 3.1 3.7 SPEED 5.0 3.7 5.6 SPEED 2.5 3.7 5.0 SPEED BODY MASS INDEX: Press the PROGRAM button until the window displays FAT to access Body Mass Index. - Page 21 TREADMILL FUNCTIONS SAFETY LOCK FUNCTION: Removing the Safety Key (No. 66) from the computer console while the treadmill is running will cause it to stop immediately. Once the treadmill reaches a full stop, the window display of the computer will show “- - -” and will beep 3 times. To start the treadmill again, insert the magnet end of the Safety Key (No.
-
Page 22: Exercise Instructions
EXERCISE INSTRUCTIONS GETTING STARTED: Before starting any exercise program, you should consult your physician to determine if you have any medical or physical conditions that could put your health and safety at risk or prevent you from using the equipment properly. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. -
Page 23: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SUGGESTED ACTION Not plugged in. Plug cord into outlet. Treadmill does not start Safety Key not inserted. Insert Safety Key. Not calibrated correctly. Re-calibrate speed setting. Running speed Speed set in the wrong Change setting to proper inaccurate units of measurement.
