Astro PB62
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Astro PB62 and is the answer not in the manual?

Questions and answers

Related Manuals for Ciara Astro PB62

Summary of Contents for Ciara Astro PB62

  • Page 1 Astro PB62 User Guide...
  • Page 2 Intel and Core are trademarks or registered trademarks of Intel Corporation Asus is a trademark of ASUSTeK COMPUTER INC. All other names, brands, and trademarks are trademarks of their respective companies Second printing September 2021 Printed in Canada All rights reserved - © Hypertechnologie CIARA inc. - 2 -...

  • Page 3: Table Of Contents

    1.1 Unpacking your micro PC ......................6 1.2 Choosing a site for the system ..................... 7 1.3 Getting to know your Astro PB62 micro PC .................. 8 1.3.1 Recovery from CIARA recovery USB flash drive ...............11 1.3.2 Windows 10 Recovery from Startup Settings ................12 1.3.3 Corrupted BIOS recovery .......................14...
  • Page 4 CIARA Astro PB62 4.0 TECHNICAL PRODUCT SPECIFICATION CIARA ASTRO PB62 ........42 4.1 Upgrading ..........................44 4.2 Networking ..........................45 4.3 The CIARA Astro PB62 BIOS ......................45 4.3.1 BIOS configuration and installation ..................45 4.3.2 BIOS set-up program menu bar .....................46 4.3.3 BIOS set-up program function keys ..................46 4.3.4 Legacy USB support ......................47...

  • Page 5: About This Guide

    Glossary. Please remember to fill out the Equipment Log and keep a copy in a safe place. With proper care and operating procedures your CIARA Astro PB62 will give you many years of service and high performance computing.

  • Page 6: Installing And Upgrading Your System

    CIARA Astro PB62 1.0 Installing and upgrading your system 1.1 Unpacking your micro PC Your micro PC is packed with ecologic moulded boxboard on four sides to keep it in place during transit. Carefully unpack your micro PC and be sure to save all boxboards for future shipping and transportation.

  • Page 7: Choosing A Site For The System

    Has an appropriate table or desk that will allow you to work without physical discomfort and strain. The Astro PB62 micro PC can be placed horizontally on your desk, mounted vertically on its stand (optional), or mounted behind the monitor with the optional VESA mounting kit.

  • Page 8: Getting To Know Your Astro Pb62 Micro Pc

    CIARA Astro PB62 1.3 Getting to know your Astro PB62 micro PC Front view Air vents (intake Vent) The air vents allow cooler air to enter your Micro PC chassis. IMPORTANT: For an optimum heat dissipation and air ventilation, ensure that the air vents are free from obstructions.
  • Page 9 CIARA Astro PB62 Rear view Wireless antenna jack The jack is used to connect the supplied wireless antenna to enhance wireless signal reception. Air vents (exhaust vent) The air vents allow your Micro PC chassis to expel hot air out.
  • Page 10 CIARA Astro PB62 Configurable port This port varies between models and consists of the following port options: VGA port This port allows you to connect your Micro PC to an external display. Serial (COM) connector The 9-pin serial (COM) connector allows you to connect devices that have serial ports such as mouse, modem, or printers.

  • Page 11: Recovery From Ciara Recovery Usb Flash Drive

    CIARA Astro PB62 1.3.1 Recovery from CIARA recovery USB flash drive Before you start this procedure please back up all your important information, the recovery media will erase all data on HDD before installation. Insert the Recovery flash drive and restart the system.

  • Page 12: Windows 10 Recovery From Startup Settings

    CIARA Astro PB62 1.3.2 Windows 10 Recovery from Startup Settings With the Windows Startup Settings screen (formerly advanced boot options) you can start Windows in different advanced troubleshooting modes so you can find and fix problems on your PC. In previous versions of Windows, you could get to this screen by pressing F8 before Windows started up.
  • Page 13 CIARA Astro PB62 Choose Reset your PC Choose Remove everything Press next Then follow the regular Windows 10 Installation process. - 13 -...

  • Page 14: Corrupted Bios Recovery

    CIARA Astro PB62 1.3.3 Corrupted BIOS recovery The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using the motherboard support USB flash drive that contains the updated BIOS file.

  • Page 15: Using The Ciara Astro Pb62

    1.3.5.1 Introduction The CIARA Astro PB62 is a powerful micro PC that has the ability to run a variety of operating systems. Unless you have specified something different, your system comes configured with a Windows operating system pre-loaded onto the hard drive. Each operating system comes with its own user manuals, and you should refer to these for information specific to your system.

  • Page 16: Troubleshooting Your System After First Install

    CIARA Astro PB62 1.4 Troubleshooting your system after first install 1.4.1 Helpful hints If you encounter some minor problems with the micro PC, monitor, or software, see the following list of general suggestions before taking further action : • Check that the micro PC and monitor are plugged into a working electrical outlet.

  • Page 17: Solving General Problems

    You should be able to easily resolve the general problems described in this section. If a problem persists and you are unable to resolve it, or if you feel uncomfortable about performing the operation, contact CIARA at 1-877-242-7272 and ask for the Customer Service department.

  • Page 18: Solving Hard Drive Problems

    CIARA Astro PB62 1.5.1 Solving hard drive problems Solving hard drive problems Problem Cause Solution Hard drive error occurs. Hard disk has bad sectors or has Use a utility to locate and block usage of bad failed. sectors. If necessary, reformat the hard disk.

  • Page 19: Solving Display Problems

    CIARA Astro PB62 1.5.2 Solving display problems Solving display problems Problem Cause Solution Blank screen (no video). Monitor is not turned on and the Turn on the monitor and check that the monitor light is not on. monitor light is on.

  • Page 20: Solving Audio Problems

    CIARA Astro PB62 1.5.3 Solving audio problems Solving audio problems Problem Cause Solution Sound does not come out of the Software volume control is Double-click the Speaker icon on the taskbar, speaker or headphones. turned down. and then make sure that Mute is not selected and use the volume slider to adjust the volume.

  • Page 21: Solving Keyboard And Mouse Problems

    Keyboard connector is not Connect keyboard correctly keyboard commands and typing. properly connected. Keyboard needs repairs. Contact CIARA so that we may proceed to repairs. Micro PC is in Last State mode. Press the power button to resume from Last State mode.

  • Page 22: Solving Hardware Installation Problems

    PC the faulty module. beeps six times. 3. If a faulty module is found, Contact CIARA for the replacement of the module. 4. 4. If the problem persists, Contact CIARA for this may necessitate the replacement of the motherboard.

  • Page 23: Solving Memory Problems

    PC beeps three times. 3. If a faulty module is found, Contact CIARA for the replacement of the module. 4. 4. If the problem persists, Contact CIARA for this may necessitate the replacement of the motherboard.

  • Page 24: Component Installation Guide

    CIARA Astro PB62 1.6 Component installation guide 1.6.1 Precautions against static electricity ATTENTION: Components such as processors and memory may be permanently damaged by shocks arising from static electricity. It is hence important to wear antistatic, smock, gloves, shoes and ankle during the installation process.

  • Page 25: Opening And Replacing The Top Cover

    CIARA Astro PB62 1.6.2 Opening and replacing the top cover 1- Turn off your Micro PC then disconnect all cables and peripherals. 2- Remove the screw from the rear (A), then push the top cover towards the front to remove the top cover (B).

  • Page 26: Installing 2.5" Hdd Or Ssd

    CIARA Astro PB62 1.6.3 Installing 2.5” HDD or SSD 1- Remove the screw securing the storage bay (A), push the storage bay towards the front of the chassis (B) then lift it to remove it from the chassis (C). NOTE: Only follow steps 2 - 4 if your Micro PC comes pre- installed with a HDD or SSD.

  • Page 27: Installation Of The Memory Modules

    Access Memory (DDR4 SDRAM) is packaged only in 260-pin Small Outline Dual In-line Memory Modules (SO-DIMMs). Your CIARA Astro PB62 uses only SO-DIMM memory modules. Each SO-DIMM module can have a capacity of 8 GB, 16 GB or 32 GB.
  • Page 28 CIARA Astro PB62 3- Remove the three (3) screws securing the fan. 4- Flip the fan over towards the rear of the chassis, but do not remove the fan completely. 5- Align and insert the memory module into the slot (A) and press it down (B) until it is securely seated in place.

  • Page 29: Installation Of The Cpu

    CIARA Astro PB62 1.6.5 Installation of the CPU 1- Follow steps 1 - 3 under the Installing top memory module section to prepare removing the heatsink and fan module. 2- Loosen the four (4) screws securing the CPU heatsink one by one in a diagonal sequence as shown.

  • Page 30: Installation Of M.2 Ssd

    CIARA Astro PB62 1.6.6 Installation of M.2 SSD Your Micro PC comes with two (2) M.2 slots, one on the top side of the motherboard, and one on the bottom of the motherboard. 1.6.6.1 Installation of an M.2 SSD to the top M.2 slot NOTE: The top M.2 slot will be disabled if a 10th gen Intel®...
  • Page 31 CIARA Astro PB62 5- Lift and remove the motherboard from the chassis, then flip the motherboard over. 6- Align and insert the M.2 SSD into the M.2 slot on the bottom side of the motherboard. 7- Secure the M.2 SSD with the bundled screw.

  • Page 32: Installation Of M.2 Wifi Module

    CIARA Astro PB62 1.6.7 Installation of M.2 WiFi module NOTE: Your Micro PC includes a M.2 slot for 2230 wireless and Bluetooth modules. 1- Follow steps 1 - 2 under the Installing 2.5” HDD or SSD section to remove the storage bay.

  • Page 33: Chassis Characteristics

    CIARA Astro PB62 1.6.8 Chassis Characteristics Mid-Tower Specifications Drive Bay Space : Int. 1 x 2.5" Power Source : External AC adapter 150 W Dimensions : 175 x 175 x 42 mm [1.286 L] Processor cooling fan : 1 x 85 mm rear exhaust...

  • Page 34: Certification And Declaration

    CIARA is licensed to supply the Windows 10 operating systems software with its CIARA Astro PB62 micro PCs. A package of the latest version of Windows software and a manual is included with the CIARA Astro PB62.

  • Page 35: Declaration Of Conformity

    CIARA Astro PB62 2.2 Declaration of conformity We, Manufacturer/Importer CIARA 9300 Trans-Canada Highway Montreal, Quebec H4S 1K5 Tel : (514) 798-8880 Fax : (514) 798-8889 Declare that the product Micro PC System CIARA Astro PB62 is in conformity with ICES-003 and Part 15 subpart B of the FCC Rules.

  • Page 36: Fcc Information To User

    Warning Changes or modifications not expressly approved by CIARA could void the user’s authority to operate the equipment. This equipment is equipped with a shielded 3-wire power cord and plug. Use this power cord in conjunction with a properly grounded electrical outlet to avoid electrical shock and to reduce radio frequency interference that may emanate from the power cord.

  • Page 37: Energy Star

    • The CIARA Astro PB62 micro PCs contribute significant energy savings nationwide. • The CIARA Astro PB62 micro PCs deliver the features and performance demanded by consumers, in addition to increased energy efficiency. • If the CIARA Astro PB62 micro PCs cost more than a conventional, less-efficient computer, purchasers will recover their investment in increased energy efficiency through utility bill savings, within a reasonable period of time.

  • Page 38: One Year Limited Warranty

    CIARA representative within one month of receipt of your system. If you have purchased a different type of warranty, or an extension to the standard warranty, you will need to provide the CIARA Service Contract Number to the Customer Support representative when placing a call for service or support.

  • Page 39: Procedures To Be Followed For Service During The Warranty Period

    Make a back-up copy of all of the files on your hard disk before returning your computer for service. CIARA is not responsible for the loss or damage of any data on the returned system. In some cases, hard disks may need to reformatted or replaced. It is the responsibility of the user to ensure data is backed up prior to shipment to CIARA.

  • Page 40: Limited Warranty

    User’s Guide which accompanies the Product or other misuse, abuse or negligence to the Product ; (ii) by the use of parts not manufactured or sold by CIARA ; (iii) by modification of the Product ; (iv) as a result of service by anyone other than CIARA or an Authorized CIARA Service Provider ;...

  • Page 41: Documenting Your Computer

    Please keep your equipment log up to date and include a copy of it whenever your equipment is returned to CIARA for servicing. The equipment log is also helpful if your CIARA computer is lost, stolen, or damaged. It can serve as your record of when the equipment was placed in service, and the dates of all equipment upgrades and configuration changes.

  • Page 42: Technical Product Specification Ciara Astro Pb62

    CIARA Astro PB62 4.0 Technical product specification CIARA Astro PB62 This is the User's Guide for the CIARA Astro PB62 family of micro PCs. The CIARA Astro PB62 is a series of miro PCs that use tenth ® and eleventh generation Intel Core™...
  • Page 43 CIARA Astro PB62 Processor : and 11 generation Intel® Core™ with integrated HD Graphics controller, with LGA1200 connector. System Board : Asus® PB62 main board uses Intel® B560 chipset BIOS : Asus Flash BIOS standard, with ACPI, APM, ENERGY STAR®, DMI, Plug & Play and SMBIOS features.

  • Page 44: Upgrading

    4.1 Upgrading As the purchaser of a powerful state of the art CIARA Astro PB62 micro PC you have no doubt decided on the features and upgrade capabilities that you might wish to add to your computer. There are many exciting possibilities for upgrading your CIARA Astro PB62.

  • Page 45: Networking

    The purpose of this section is to describe the procedures to set up the BIOS configuration options of your CIARA Astro PB62 micro PC. All this work is done for you at the CIARA factory enabling the system to be ready to start on Power on. However, we are describing this procedure as a means of transparency.

  • Page 46: Bios Set-Up Program Menu Bar

    CIARA Astro PB62 4.3.2 BIOS set-up program menu bar NOTE ® ® To configure Intel AMT settings in Intel ME press <Ctrl>+<P> to activate the interface, while the system is booting. ® The default password for Intel ME is “admin”.

  • Page 47: Legacy Usb Support

    CIARA Astro PB62 4.3.4 Legacy USB support Legacy USB support enables USB devices to be used even when the operating system’s USB drivers are not yet available. Legacy USB support is used to access the BIOS Setup program, and to install an operating system that supports USB. By default, Legacy USB support is set to Enabled.

  • Page 48: Bios Recovery

    CIARA Astro PB62 4.3.7 BIOS recovery It is unlikely that anything will interrupt a BIOS update; however, if an interruption occurs, the BIOS could be damaged. The following table lists the drives and media types that can and cannot be used for BIOS recovery. The BIOS recovery media does not need to be made bootable.

  • Page 49: Adjusting Boot Speed

    CIARA Astro PB62 4.3.8.4 Changing the default boot device during POST Pressing the <F8> key during POST causes a boot device menu to be displayed. This menu displays the list of available boot devices (as set in the BIOS setup program’s Boot Device Priority Submenu). The following table lists the boot device menu options.

  • Page 50: Bios Security Features

    CIARA Astro PB62 4.3.10 BIOS security features The BIOS includes security features that restrict access to the BIOS Setup program and who can boot the computer. A supervisor password and a user password can be set for the BIOS Setup program and for booting the computer, with the following restrictions •...

  • Page 51: Disk Drives

    Many Serial ATA drives use new low-voltage power connectors and require adapters or power supplies equipped with low-voltage power connectors. 4.4.2 M.2 slots CIARA Astro PB62 system is equipped with two M.2 slots, M key : • One M.2 slot PCIe gen3 x4 type 2280 to accommodate SSD drive •...

  • Page 52: Audio Subsystem

    4.7 I/O Port set-up Each CIARA Astro PB62 micro PC system includes built-in multi-I/O capabilities. These provide your computer with two DisplayPorts 1.2, one SATA connector (6.0 Gb/s) supporting one drive, four USB 3.2 Gen 2 Type A ports, one USB 3.2 Gen 1 Type-C port, one headphone jack, one mic in at front panel ;...

  • Page 53: Lan Connectors Leds

    CIARA Astro PB62 4.8.2 RJ-45 LAN connectors LEDs Two LEDs are built into the RJ-45 LAN connectors located on the back panel (see Figure). These LEDs indicate the status of the LAN. Table describes the LED states when the board is powered up and the LAN subsystem is operating.

  • Page 54: Replacing The System Battery

    In all CIARA Astro PB62 models the battery is a custom 3 V Lithium battery model CR-2032U made by Asus that can be installed only by CIARA. This type of battery should last at least 3 years, if the system is not in use. When the computer is plugged in, the standby current from the power supply extends the life of the battery.

  • Page 55: Spare Parts

    These spare parts will either correspond to the components in your system or will be a replacement equivalent or better than what you had in your system. You can procure these spare parts at any time by contacting CIARA at http://www.ciaratech.com...

  • Page 56: Glossary

    CIARA Astro PB62 GLOSSARY 32-Bit -- In computer architecture, 32-bit integers, memory addresses, or other data units are those that are at most 32 bits (4 octets) wide. Also, 32-bit CPU and ALU architectures are those that are based on registers, address buses, or data buses of that size. 32-bit is also a term given to a generation of computers in which 32-bit processors were the norm.
  • Page 57 CIARA Astro PB62 integrated circuit. Chip set -- The logic devices on the motherboard that connects the microprocessor and other board functions. Clock -- A circuit that sends a consistent, periodic signal that is used to step logic information through a computer circuit.
  • Page 58 CIARA Astro PB62 Jumper -- On a printed circuit board, a patch connector, wire, or cable used to establish a circuit. LCD -- A liquid crystal display (LCD) is a thin, flat electronic visual display that uses the light modulating properties of liquid crystals (LCs).
  • Page 59 CIARA Astro PB62 Resolution -- A measure of the quality of the image that can be shown on a particular display ; usually expressed as the number of pixels that can be displayed horizontally across the display screen by the number of pixels that can be displayed vertically on the display screen.
  • Page 60 CIARA Astro PB62 NOTES : - 60 -...
