4. CONTROLS AND INDICATORS
Front View
Amplitude Knob
Mode
Channel Output
Timer
Increase Button
Decrease Button
Set Button
Top View
Channel 1 On/Off and
Amplitude Control
Channel 1 Output
Knob Cover
Receptacle
Battery Indicator
Pulse Rate
Pulse Width
Mode Button
Lid Cover
6
Knob Cover
Channel 2 On/Off and
Amplitude Control
Channel 2 Output
Receptacle
Back View
Knob Cover
Clip
Battery Cover
