5.3 Connect lead wires to unit:
Before proceeding to this step, be sure the unit is completely turned OFF. Holding the insulated portion of the lead
wire connector, insert the angled-"L" plug into the receptacle on the top of the main unit. Ensure the leads are
inserted correctly.
The unit has two output receptacles controlled by Channel 1 and Channel 2 Amplitude Control knobs at the top of
the unit. You may choose to use one channel with one pair of lead wires or both channels with two pairs of lead
wires. Using both channels give the user the advantage of stimulating two different areas at the same time.
Self-adhesive
Electrodes Pads
Angle"L"-shape
plug
11
