"DECREASE" control button (inverted triangle-button)
This button decreases the pulse width from 300~50µs, decreases the pulse rate from 120 to 2Hz, and decreases the
timer from continuous mode to 90 to 5 min.
"MODE" button (round-button on the right side of the control panel)
This button selects a Stimulation-Mode. It displays the mode status from three types of function modes; which are
Synchronous, Constant and Alternate.
"SET" button (round-button on the middle of the control panel)
This button set the ramp, on time, off time, rate, width and timer. Press the 'SET' button to enter a parameter
setting mode including ramp, on time, off time, rate, width and timer.
LCD screen
This LCD displays stimulating mode, ramp, on time, off time, pulse rate, pulse width and display timer. The channel
output will be indicated on the left side (Channel 1) and right side (Channel 2) of the LCD screen. The modes will be
displayed on the top of the LCD panel. The ramp, on time, off time, pulse rate, and pulse width will be shown on the
middle-right of the screen. The timer and clock symbol display on the middle-left of the screen, the clock symbol will
flash in final 5 min.
Battery compartment
9 Voltage battery- 1 pc
