Campbell CS215 Instruction Manual

Temperature and relative humidity probe
Hide thumbs Also See for CS215:
Table of Contents

Advertisement

Quick Links

Download this manual
CS215 Temperature and
Relative Humidity Probe
Revision: 8/14
C o p y r i g h t
©
2 0 0 5 - 2 0 1 4
C a m p b e l l
S c i e n t i f i c ,
I n c .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS215 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Campbell CS215

Summary of Contents for Campbell CS215

  • Page 1 CS215 Temperature and Relative Humidity Probe Revision: 8/14 C o p y r i g h t © 2 0 0 5 - 2 0 1 4 C a m p b e l l S c i e n t i f i c ,...
  • Page 3 Limited Warranty “Products manufactured by CSI are warranted by CSI to be free from defects in materials and workmanship under normal use and service for twelve months from the date of shipment unless otherwise specified in the corresponding product manual. (Product manuals are available for review online at www.campbellsci.com.) Products not manufactured by CSI, but that are resold by CSI, are warranted only to the limits extended by the original manufacturer.
  • Page 4 SCIENTIFIC, INC., phone (435) 227-9000. After an application engineer determines the nature of the problem, an RMA number will be issued. Please write this number clearly on the outside of the shipping container. Campbell Scientific’s shipping address is: CAMPBELL SCIENTIFIC, INC.
  • Page 5 Periodically (at least yearly) check electrical ground connections. • WHILE EVERY ATTEMPT IS MADE TO EMBODY THE HIGHEST DEGREE OF SAFETY IN ALL CAMPBELL SCIENTIFIC PRODUCTS, THE CUSTOMER ASSUMES ALL RISK FROM ANY INJURY RESULTING FROM IMPROPER INSTALLATION, USE, OR MAINTENANCE OF TRIPODS, TOWERS, OR ATTACHMENTS TO TRIPODS AND TOWERS SUCH AS SENSORS, CROSSARMS, ENCLOSURES, ANTENNAS, ETC.

  • Page 7: Table Of Contents

    Table of Contents PDF viewers: These page numbers refer to the printed version of this document. Use the PDF reader bookmarks tab for links to specific sections. 1. Introduction ..............1 2. Cautionary Statements ..........1 3. Initial Inspection ............1 4.
  • Page 8 D.2.1 CR200(X) Series Datalogger Example ........D-3 D.2.2 CR1000 Datalogger Example ........... D-4 D.2.3 CR10X Datalogger Example ............ D-5 Figures 7-1. CS215 and 41303-5A Radiation Shield on a tripod mast ....9 7-2. CS215 and 41303-5A Radiation Shield on a CM200 Series Crossarm ..................9 9-1.
  • Page 9 Table of Contents Tables 7-1. Datalogger Wiring................6 C-1. Environmental Tests ................ C-1 D-1. SDI-12 Command and Response Set ..........D-1...
  • Page 10 Table of Contents...

  • Page 11: Introduction

    CS215 Temperature and Relative Humidity Probe Introduction The CS215 Temperature and Relative Humidity Probe is designed for general meteorological and other data logging applications. It uses the SDI-12 communications protocol to communicate with any SDI-12 recorder, simplifying installation and programming.

  • Page 12: Quickstart

    CS215 Temperature and Relative Humidity Probe Quickstart Short Cut is an easy way to program your datalogger to measure the CS215 sensor and assign datalogger wiring terminals. Use the following procedure to get started. 1. Install Short Cut by clicking on the install file icon. Get the install file from either www.campbellsci.com, the ResourceDVD, or find it in...
  • Page 13 5. Under the Available Sensors and Devices list, select the Sensors | Meteorological | Relative Humidity & Temperature folder. Select CS215 Temperature & Relative Humidity Sensor. Click to move the selection to the Selected device window. Data defaults to degree Celsius.

  • Page 14: Overview

    Overview The CS215 probe uses a single chip element that incorporates both a temperature and an RH sensor. Each element is individually calibrated with the calibration corrections stored on the chip. The element is easily changed in the field.

  • Page 15: Temperature Measurement

    CS215 Temperature and Relative Humidity Probe Filter Material: Sintered high-density polyethylene, average pore size 13 µm EMC Compliance: Tested and conforms to BS EN61326:2002 Calibration: Sensirion SHT75 sensor element is individually calibrated during manufacture. Temperature Measurement Operating Range: –40 to +70 °C Accuracy: ±0.3 °C at 25 °C...

  • Page 16: Wiring To Datalogger

    “daisy-chain” fashion which can minimize cable runs in some applications. (See below for limits on the total cable length.) The SDI-12 address of the CS215 can be set two ways: By sending the required commands to the sensors via an SDI-12 •...

  • Page 17: Crbasic Programming

    The SDI12Recorder() measurement instruction programs CRBasic dataloggers (CR200(X)-, and CR800-series, CR1000, CR3000, and CR5000) to measure the CS215 sensor. This instruction sends a request to the sensor to make a measurement and then retrieves the measurement from the sensor. See Section 8.1, Sensor Measurements, for more information.

  • Page 18: Installation

    See Section 10, Attributions and References, for a list of references that discuss temperature and relative humidity sensors. When used in the field, the CS215 must be housed in a radiation shield. Typically, the 41303-5A six-plate solar radiation shield is used. The white color reflects solar radiation, and the louvered construction allows air to pass freely through, thereby keeping the probe at or near ambient temperature.

  • Page 19: Cs215 And 41303-5A Radiation Shield On A Tripod Mast

    6. Route the cable to the datalogger, and secure the cable to the mounting structure using cable ties. 41303-5A CS215 Tripod or Tower Mast FIGURE 7-1. CS215 and 41303-5A Radiation Shield on a tripod mast Tripod or Tower Mast 41303-5A CS215 CM200 Series Crossarm FIGURE 7-2.

  • Page 20: Operation

    See Appendix D, SDI-12 Sensor Support, for additional commands and details of the SDI-12 protocol. NOTE Only CS215 sensors with serial numbers after E1587 or those with upgraded firmware support the aR! Command. 8.1.1 Measurements at Fast Scan Rates 8.1.1.1 CRBasic Dataloggers...

  • Page 21: Edlog Dataloggers

    8.1.1.2 Edlog Dataloggers The aM! command takes about 700 milliseconds in total to make a measurement from the CS215. If it is included in the main program table (table 1) the program will be delayed for this interval which will limit the maximum scan rate for fast running programs.

  • Page 22: Power Conservation

    CS215 Temperature and Relative Humidity Probe 8.1.3 Power Conservation The CS215 draws less than 70 µA of current between measurements. In most applications, this is insignificant compared to the datalogger and other power uses, so the sensor can be permanently connected.

  • Page 23: Maintenance

    CS215 Temperature and Relative Humidity Probe Maintenance The CS215 probe requires minimal maintenance. Check the radiation shield monthly to make sure it is free from dust and • debris. • Clear the white filter on the end of the sensor of debris. If dirt or salt is engrained into the filter, it should be cleaned with distilled water or replaced.
  • Page 24 CS215 Temperature and Relative Humidity Probe There are eight holes in the socket, while the element only has four • pins. • The element will work when fitted into either side of socket but must be installed in one of the two possible orientations to work.

  • Page 25: Correct Fit Of Sensor Element (Side View)

    CS215 Temperature and Relative Humidity Probe Gold colored Sensing part of side of the tip the element. Printing on this side. Sensing Element Gold pins Sensor Thread for the connector filter sticking out of the end of the tube Center line of...

  • Page 26: Attributions And References

    CS215 Temperature and Relative Humidity Probe Sensing part of element NOT on the center line Center line of the sensor body FIGURE 9-2. Incorrect fit of sensor element (side view) 10. Attributions and References AASC, 1985: The State Climatologist (1985) Publication of the American Association of State Climatologists: Heights and Exposure Standards for Sensors on Automated Weather Stations, v.
  • Page 27 CS215 Temperature and Relative Humidity Probe Meyer, S. J. and K. G. Hubbard, 1992: Nonfederal Automated Weather Stations and Networks in the United States and Canada: A Preliminary Survey, Bulletin Am. Meteor. Soc., 73, No. 4, 449-457. Weiss, A., 1977: Algorithms for the calculation of moist air properties on a hand calculator, Amer.
  • Page 28 CS215 Temperature and Relative Humidity Probe...

  • Page 29: Importing Short Cut Code Into Crbasic Editor

    Appendix A. Importing Short Cut Code Into CRBasic Editor This tutorial shows: How to import a Short Cut program into a program editor for • additional refinement • How to import a wiring diagram from Short Cut into the comments of a custom program A.1 Importing Short Cut Code into a Program Editor Short Cut creates files that can be imported into either CRBasic Editor or...

  • Page 30: Edlog

    Appendix A. Importing Short Cut Code Into CRBasic Editor 5. The program can now be edited, saved, and sent to the datalogger. 6. Import wiring information to the program by opening the associated .DEF file. Copy and paste the section beginning with heading “-Wiring for CRXXX–”...

  • Page 31: Example Programs

    Appendix B. Example Programs B.1 CRBasic Programs B.1.1 Example CR200(X) Program This example program shows the measurement of a single CS215 and can be used directly with CR200(X) series dataloggers. 'CR200(X) Series Datalogger 'Program measures one CS215 sensor every 30 seconds and stores the average 'temperature and a sample of relative humidity every 10 minutes.

  • Page 32: Example Program For Cr800, Cr850, Cr1000, Cr3000, Or Cr5000

    CR5000 This program can be used directly with CR800 series, CR1000, CR3000, and CR5000 dataloggers. 'Program measures one CS215 sensor every 5 seconds and stores the average 'temperature and a sample of relative humidity every 10 minutes. 'Wiring Diagram...

  • Page 33: Edlog Program

    0 (the default) and connected to control port 1. ;{CR10X} ;Example program for a CS215 sensor on control port 1 ;Measures every minute and stores some summary statistics ;once per hour...
  • Page 34 Appendix B. Example Programs...

  • Page 35: Environmental Performance

    Appendix C. Environmental Performance This appendix details tests and limitations of the sensor when exposed to extremes of the environment. C.1 Tests to Defined Standards The sensor element has been tested by the manufacturer and found to comply with various environmental test standards as shown in the table below: TABLE C-1.

  • Page 36: Operating Range Of Rh Element

    World Meteorological Organization. If an RH value is required to be referenced to ice, the CS215 readings will need to be corrected. One consequence of using water as the reference is that the maximum humidity...

  • Page 37: Sdi-12 Sensor Support

    An active sensor responds to each command. Responses have several standard forms and terminate with <CR><LF> (carriage return – line feed). Standard SDI-12 commands supported by the CS215 are listed in TABLE D-1. TABLE D-1. SDI-12 Command and Response Set...

  • Page 38: Address Query Command

    Transparent mode is entered while the PC is in telecommunications with the datalogger through a terminal emulator program. It is easily accessed through Campbell Scientific datalogger support software, but is also accessible with terminal emulator programs such as Windows HyperTerminal. Datalogger...

  • Page 39: Cr200(X) Series Datalogger Example

    D.2.1 CR200(X) Series Datalogger Example 1. Connect a single CS215 to the CR200(X) (see TABLE 7-1). 2. In the LoggerNet Connect screen navigate to the Datalogger menu and select Terminal Emulator. The terminal emulator window will open. In the Select Device menu, located in the lower left-hand side of the window, select the CR200Series station.

  • Page 40: Cr1000 Datalogger Example

    Appendix D. SDI-12 Sensor Support D.2.2 CR1000 Datalogger Example 1. Connect a CS215 to the CR1000 (see TABLE 7-1). 2. In the LoggerNet Connect screen navigate to the Datalogger menu and select Terminal Emulator. The terminal emulator window will open. In the Select Device menu, located in the lower left-hand side of the window, select the CR1000 station.

  • Page 41: Cr10X Datalogger Example

    Appendix D. SDI-12 Sensor Support D.2.3 CR10X Datalogger Example 1. Connect CS215 to the CR10(X) (see TABLE 7-1). 2. Download a datalogger program that contains the SDI-12 Recorder (P105) instruction with valid entries for each parameter. Make sure that parameter 3 of the P105 instruction matches the control port number where the sensor is connected.
  • Page 42 Appendix D. SDI-12 Sensor Support...
