Reset palette

Resets palette pen parameters configured using Define palette.
This setting item sets the palette pen parameters back to the default.
This setting item is displayed by tapping in the following order.
Printer settings > Print settings > HP-GL/2 print settings > Line & pen manager > Pen setup
• • All palettes
Resets all palette pen parameters.
• • Palette A
Resets Palette A pen parameters.
• Palette B •
Resets Palette B pen parameters.
PALETTE DEFAULTS
Palette defaults are the same settings as Default in the initial state.
Pen number Line Width (mm) Colors (R, G, B)
0 0.13
1 0.18
2 0.25
3 0.35
4 0.50
5 0.65
6 0.70
7 0.80
8 0.90
9 1.0
10 1.4
11 2.0
12 3.0
13 5.0
14 8.0
Line Attributes Tip
0 (255, 255, 255) Rounds
1 (0, 0, 0) Rounds
2 (255, 0, 0) Rounds
3 (0, 255, 0) Rounds
4 (255, 255, 0) No setting
5 (0, 0, 255) No setting
6 (255, 0, 255) No setting
7 (0, 255, 255) No setting
8 (233, 233, 233) No setting
12 (127, 127, 127) No setting
19 (255, 214, 0) No setting
27 (0, 255, 214) No setting
35 (214, 0, 255) No setting
68 (205, 205, 0) No setting
100 (0, 168, 168) No setting
308
Connecting Line
Rounds Rounds
Rounds Rounds
Rounds Rounds
Rounds Rounds
No setting Miter
No setting Miter
No setting Miter
No setting Miter
No setting Miter
No setting Miter
No setting Miter
No setting Miter
No setting Miter
No setting Miter
No setting Miter
