  • Page 1 compass ® User manual...

  • Page 2: Foreword

    Foreword Congratulations on your new device. Compass ® products bring real progress to your business and secure real benefits for both you and your customers. You have decided to purchase our training equipment. We thank you for this trust. The equipment has undergone extensive safety and functional testing to reduce potential hazards and risks.

  • Page 3: Table Of Contents

    Table of contents Foreword ............................ 2 Notes on the instructions for use .................... 6 Safety instructions (legend) ............................6 Safety instructions ........................7 Marking on the device ..............................7 Applied symbols for transport..........................8 Liability notice .................................8 Intended use ..................................9 Indications and contraindications ........................10 Patient population ..............................
  • Page 4 Settings ................................. 22 compass ® 600 Leg Press ............................23 Intended Purpose ............................. 23 Indications ................................23 Settings ................................. 24 compass ® 600 Butterfly/Butterfly Reverse ....................... 26 Purpose ................................. 26 Indications ................................26 Settings ................................. 27 compass 600 Trunk Extension/Trunk Flexion ....................29 ®...
  • Page 5 Compass 600 Chest Press ........................... 50 ® Compass ® 600 Rowing ........................... 50 Compass 600 Leg Press ..........................51 ® Compass ® 600 Butterfly/Butterfly Reverse ..................... 51 Compass 600 Pulldown/Dip ........................51 ® Compass ® 600 Shoulder Press/Vertical Rowing................... 51 Compass ®...

  • Page 6: Notes On The Instructions For Use

    Notes on the instructions for use These instructions for use are part of the product and must be kept safe and accessible throughout the entire service life. In the event of a change of ownership, the operating instructions must be handed over to the new owner. If supplements to these operating instructions are supplied, they must be added to the document.

  • Page 7: Safety Instructions

    Safety instructions Marking on the device Figure Description Reference Observe operating instructions EN ISO 15223-1 Manufacturer, name, address, year EN ISO 15223-1 manufacture CE Mark EU 2017/ 745 Serial number EN ISO 15223-1 Unique Device Identification EU 2017/ 745 Multi-year inspection sticker EN 62353 Next test date (countersigned by perforation)

  • Page 8: Applied Symbols For Transport

    Applied symbols for transport Figure Description Reference TOP - top here DO NOT stack Protect from moisture Temperature range ISO 15223-1 Humidity ISO 15223-1 Liability notice The device is built according to the current state of the art and the recognized safety rules. Nevertheless, unauthorized misuse may result in hazards to persons and the device.

  • Page 9: Intended Use

    Intended use The devices are manufactured according to the international standards EN ISO 20957-1 and EN ISO 20957-2 as class S (studio); they are intended for commercial use e.g. in health-oriented fitness facilities or physiotherapy practices for use on patients. Before the start of the first training session, the patient is instructed by qualified personnel.

  • Page 10: Indications And Contraindications

    Indications and contraindications The indications for the use of the devices in therapy are shown in chapter 7 for the respective devices. The devices are contraindicated and must not be used for the conditions listed below: • Febrile diseases • Current pain at rest or during activity, as well as acute health complaints •...

  • Page 11: Safety Regulations

    Only use original accessories, otherwise no liability will be accepted. The device may only be opened by proxomed service or authorized personnel. Do not reach with your hands between the moving bearings/rollers. 3.10 Combination with other products Compass 600 devices can optionally be used with the smart assist accessory.

  • Page 12: Storage, Transport And Installation

    Storage, transport and installation Store the devices dry, free of seawater and protected from dust within the temperature range of -5°C to +45°C. Protect the devices from impacts, scratches and moisture. Note that the load-bearing capacity of the substrate must be according to the weight of the devices. Use the devices only in dry rooms free of seawater air (<65% humidity).

  • Page 13: Commissioning

    Commissioning Before each start-up, check that the training device is in perfect technical condition.  Locking bolt on function, the locking button must engage automatically.  Protective cladding - present or damaged.  Screw connections - check for tight connection. ...

  • Page 14: Training Tips

    Training tips The device must be adjusted to the ergonomic conditions of the user before the first training. The adjustment of the training device for the user is the responsibility of the qualified personnel. CAUTION Improper or excessive training can lead to health problems To avoid injuries and to make the training more effective, a general and special warm-up •...
  • Page 15 Different training methods are used. If training is done according to the repetition method, • several series of exercises are performed with appropriate breaks. The load intensity is based on the load capacity of the individual indications, the rehabilitation • phase and the treatment goal.

  • Page 16: Device Descriptions

    Device descriptions ® compass 600 Abductor/Adductor Weight tower B - Backrest A - Start angle C - Footrests Intended Purpose Compass 600 Abductor/Adductor is intended for muscular stabilization of the abducting or adducting ® leg muscles. Abduction Adduction Indications Sarcopenia of the leg muscles •...

  • Page 17: Settings

    Settings - Start angle/Leg supports 130° 11 à 13° - Backrest 75° (80-5°) Stepless (8 positions) - Footrests right/left optional 30 cm 16 à 2 cm...

  • Page 18: Compass ® 600 Leg Extension/Leg Curl

    compass ® 600 Leg Extension/Leg Curl C - Start angle Femoral fixation B - Legrest Leg rest Weight tower A - Seat Intended Purpose Compass® 600 Leg Extension/Leg Curl is intended for muscular stabilization of the leg extension or leg curl muscles.

  • Page 19: Settings

    Settings - Seat depth 21 cm (45-66 cm) Stepless (12 positions) - Legrest 26 cm (19-45 cm) Stepless (25 positions) - Start angle 105° (10-85°) 12 à 10°...
  • Page 20 Leg fixation 105° (10-85°) 6 à 10°...

  • Page 21: Compass ® 600 Chest Press/Rowing

    compass ® 600 Chest Press/Rowing Weight tower B - Start angle left C - Start angle right A - Seat Intended Purpose Compass 600 Chest Press/Rowing is intended for muscular stabilization of the trunk muscles. ® Chest Press Rowing Indications Sarcopenia of the trunk muscles •...

  • Page 22: Settings

    Settings - Seat height 17 cm (53-70 cm) Stepless (8 positions) - Start angle left 50° (45-95°) 7 à 8° - Start angle right 50° (45-95°) 7 à 8°...

  • Page 23: Compass

    compass ® 600 Leg Press Weight tower B - Seat Shoulder pads B - seat depth C - Backrest A - Foot plates Intended Purpose Compass ® 600 Leg Press is intended for muscular stabilization of the leg extensor muscles. Leg Press Calf Training Indications...

  • Page 24: Settings

    Settings – Foot plate incline ATTENTION Make adjustments 15° with two hands! (75-90°) 5 à 4° - Seat depth 45 cm (65-110 cm) 10 à 5 cm – Backrest incline ATTENTION Make adjustments with two hands! 70° (70-180°) 8 à 10°...
  • Page 25 - Foot height 60 cm Stepless (9 positions) Shoulder pads 30 cm (41-71 cm) Stepless Balance Board optional Stepless...

  • Page 26: Compass ® 600 Butterfly/Butterfly Reverse

    compass ® 600 Butterfly/Butterfly Reverse B - Training arm Weight tower C - Start angle left D - Start angle right A - Seat Purpose Compass 600 Butterfly/Butterfly Reverse is intended for muscular stabilization of the upper back ® muscles or chest muscles. Butterfly Reverse Butterfly Indications...

  • Page 27: Settings

    Settings - Seat height 17 cm (53-70 cm) Stepless (8 positions) - Training arm width 22° 3 à 11° - Start angle left 130° 14 à 10°...
  • Page 28 - Start angle right 130° 14 à 10°...

  • Page 29: Compass ® 600 Trunk Extension/Trunk Flexion

    compass ® 600 Trunk Extension/Trunk Flexion Weight tower B - Upper body pad C - Start angle A - Seat Intended Purpose Compass ® 600 Trunk Extension/Trunk Flexion is intended for muscular stabilization of the trunk extensor or trunk flexor musculature. Trunk Extension Trunk Flexion Indications...

  • Page 30: Settings

    Settings - Seat height 12 cm (43-55 cm) Stepless (8 positions) - Upper body pad adjustment 26 cm (19-45 cm) Stepless (25 positions) - Start angle 45° (50-95°) 6 à 10°...

  • Page 31: Compass ® 600 Pulldown/Dip

    compass ® 600 Pulldown/Dip Weight tower B - Training arm A - Seat Intended Purpose compass ® 600 Pulldown/Dip is intended for muscular stabilization of the upper chest and dorsal upper arm muscles. Pulldown Indications Sarcopenia of the shoulder muscles •...

  • Page 32: Settings

    Settings - Seat height 17 cm (53-70 cm) Stepless (8 positions) - Training arm height 40 cm (94-134 pcs. 158-198 Sbf.) 9 à 5 cm (1-9 pcs; 10-18 Sbf. )

  • Page 33: Compass ® 600 Shoulder Press/Vertical Row

    compass ® 600 Shoulder Press/Vertical Row Weight tower A – Seat height B - Training arm Seat Intended Purpose Compass ® 600 Shoulder Press/Vertical Row Machine is intended for muscular stabilization of the shoulder muscles. Shoulder Press Vertical Row Indications Sarcopenia of the shoulder muscles •...

  • Page 34: Settings

    Settings - Seat height 17 cm (53-70 cm) Stepless (8 positions) - Training arm height 40 cm (18-58 cm Rzug v. 82-122 cm sp.) 9 à 5 cm (1-9 Rzug v.; 10-18 sp. )

  • Page 35: General Training Settings

    General training settings Weight settings 5 kg Main weights max. 100 kg max. 20 weights à 5 kg Fine weights optional 4 kg 4 weights à 1 kg CAUTION No external weights may be attached to the devices! Weight settings 10 kg Main weights max.
  • Page 36 Fine weights optional 8 kg 4 weights à 2 kg CAUTION No external weights may be attached to the devices! Movement limitation optional Up to 100 cm stepless Lordosis cushion Optional Not for trunk extensors/flexors Stepless WARNING Fastening lordosis cushion by means of magnets. –...

  • Page 37: Maintenance, Cleaning, Servicing, Disposal

    Maintenance, cleaning, servicing, disposal CAUTION The devices are subject to an annual safety and functional test in accordance with §7 of the Medical Devices Operator Ordinance "Maintenance of Medical Devices". With the optional "smart assist ISO" accessory, a metrological test (MTP) is performed at 2-year intervals in accordance with the manufacturer's specifications.
  • Page 38 The authorized service will help you quickly and competently. You will find the "Repair order/ malfunction report" form in the enclosed medical device book. Create an error message and send it by mail (service@proxomed.com) or use our servicehelper form (see chap. 9Service ). We will be glad to help you.

  • Page 39: Service

    If our devices do not work properly, our customer support team will help you quickly and easily. steps directly to the goal! Scan servicehelper QR code or go to https://www.proxomed.com/leistungen/technischer- service/servicehelper-meldung. This will take you directly to our servicehelper form.

  • Page 40: 10 Accessories

    10 Accessories smart assist Item no. 10629100 Support during movement execution. Connection to proxotrain software for training planning, training control and training documentation. Butterfly/Butterfly Abductor/Adductor Chest Press/Rowing Pullldown/Dip Available for: Reverse Shoulder Press/Vertical Leg Extension/Curl Leg Press Trunk Extension/Flexion smart assist ISO Item no.
  • Page 41 Position sensor technology (only with smart assist*ISO) The position sensor system is intended for the exact reproducible individual training position in the device. It enables quick and easy device adjustment on the compass ® 600 devices. Butterfly/Butterfly Abductor/Adductor Chest Press/Rowing Pullldown/Dip Available for: Reverse...
  • Page 42 Range of Motion Limiter Item no. 10692700 Limitation of motion is intended for limiting the range of motion (ROM). Butterfly/Butterfly Abductor/Adductor Chest Press/Rowing Pullldown/Dip Available for: Reverse Shoulder Press/Vertical Leg Extension/Curl Leg Press Trunk Extension/Flexion Weight block increase Item no. 11210400 Upgrading the weight block for increasing the intensity of training...
  • Page 43 Adjustable footrests for Abductor/Adductor Item no. 10692900 Adjustable footrests to fit leg length for a closed kinetic chain workout to stabilize joints. Butterfly/Butterfly Abductor/Adductor Chest Press/Rowing Pullldown/Dip Available for: Reverse Shoulder Press/Vertical Leg Extension/Curl Leg Press Trunk Extension/Flexion Laser pointer for positioning the joint axis Item no.
  • Page 44 Footrest for Leg Press Item no. 10693200 The footrest makes it possible to put down the untrained leg during single-leg training. Pull out the footrest and fold it down. Butterfly/Butterfly Abductor/Adductor Chest Press/Rowing Pullldown/Dip Available for: Reverse Shoulder Press/Vertical Leg Extension/Curl Leg Press Trunk Extension/Flexion Balance Board for Leg Press...
  • Page 45 Walker holder / Water bottle holder Item no. 10611000 Holder for walker or drinking bottle. Holder can be used as a walker holder or bottle holder depending on use. Attach magnetic holder to load-bearing metal cladding. Butterfly/Butterfly Abductor/Adductor Chest Press/Rowing *Pullldown/Dip Available for: Reverse...

  • Page 46: 11 Technical Data

    11 Technical data Movement Isometric Device Patient Training Adjustable size dimension weight weight weight load Depth x width x Depth x width x maximum maximum maximum maximum height in cm height in cm compass ® 600 Ab-/Adductor 384 kg 200 kg 104 kg 141 x 110 x 165 205 x 180 x 165...
  • Page 47 Ambient conditions operation Temperature +5° to +45° Celsius Humidity <65% Transport and storage Temperature -5° to +45° Celsius Humidity < 65% Requirements Medical Device Directive 93/ 42/ EEC Product life 7 years as medical device Stationary training equipment EN ISO 20957-1, ISO 20957-2 Use class according to ISO 20957-1 Risk classification 93/ 42/ EEC...

  • Page 48: 12 Warranty

    It is the customer's responsibility to ensure the functionality of the device by replacing the wear parts at an early stage if the intervals for safety checks specified by proxomed are not adhered to or if no maintenance contract has been concluded with proxomed.

  • Page 49: Appendix

    13 Appendix 13.1 Real training weight Lever arms, friction, pulleys, and other factors cause the weight of the equipment to change between the set weight and the real weight arriving at the training arm. The following tables provide a rough overview: Compass ®...

  • Page 50: Compass ® 600 Leg Curl

    Compass 600 Leg Curl ® Staked weight in kg 14,4 21,2 28,0 34,8 41,6 48,4 55,2 62,0 68,8 75,6 12,5 19,3 26,1 32,9 39,7 46,5 53,3 60,1 66,9 73,7 10,2 17,0 23,8 30,6 37,4 44,2 51,0 57,8 64,7 71,5 13,0 19,2 25,4 31,6...
  • Page 51 Compass ® 600 Leg Press Staked weight in kg 101, 111, 120, 129, 138, 147, 156, 166, 175, 184, 193, 202, 19,2 28,4 37,5 46,7 55,9 65,1 74,3 83,4 92,6 104, 113, 123, 132, 141, 150, 159, 169, 178, 187, 196, 205, 22,1...
  • Page 52 Compass 600 Trunk Extension ® Staked weight in kg 14,6 22,3 30,0 37,7 45,4 53,1 60,8 68,5 76,2 83,9 14,9 22,6 30,3 38,0 45,7 53,4 61,1 68,8 76,6 84,3 15,4 23,1 30,8 38,5 46,2 53,9 61,6 69,3 77,0 84,7 13,2 20,2 27,2 34,2...
  • Page 53 Changes: proxomed® reserves the right to change products if, in our opinion, these measures lead to an improvement in quality and function. All illustrations in these instructions for use are only approximate for typographical reasons; we accept no liability for typographical errors.
