- Page 1 User Manual 0123 Page 1...
-
Page 3: Table Of Contents
Contents General ................................1 Identification of the User Manual ........................1 Importance of the User Manual ........................1 Classification ..............................2 Identification and Specification ........................2 Safety information ............................3 Symbol ................................3 Secure installation of the machine ........................3 Safe operation of the machine ........................ -
Page 4: General
If due to modifications a revision by the manufacturer is required, this is implemented by the manufacturer • and identified with a new version number. The machines are equipped with the proxomed SmartPanel. There is a detailed separate User Manual for • the proxomed SmartPanel. -
Page 5: Classification
Classification According to the Medical Product Law (in German MPG) the tergumed ® 710 machine is a Class 1 medical device with a measurement function. The machines are compliant with the requirements of EN ISO 20957-1 / ISO 20957-2-class S (= Studio) or I (= Rehab) and are intended for use in industrial facilities. -
Page 6: Safety Information
Secure installation of the machine The installation of this machine should be carried out directly by • the manufacturer or by a proxomed® authorised service technician. Only then can safe and proper functionality be guaranteed. For queries, please contact the proxomed® service under the contact option given in Chapter 14. -
Page 7: Safe Operation Of The Machine
Safe operation of the machine The correct function of the machine is guaranteed when the ambient temperature is in the range of 18 - • 22° Celsius (before the first time use after setting up, allow the machine to acclimatise for at least 24 hours at the specified ambient temperature). -
Page 8: Indications And Contra-Indicators
Check the machine before starting training that it is secure; there are no defective parts and no signs of • other manipulation. If you notice any deficiencies or are not sure, ask the supervisor before you start training. Before every training, make sure of the correct biomechanical positioning with reference to the pivot point, •... -
Page 9: Use And Area Of Application
• Progressive instability of spinal column • Hypertensive Carotid Sinus Syndrome • Tinnitus • Spondylolisthesis (> Meyerding Classification II) • Root and spinal cord symptoms (with considerable neurological symptoms) If medication is being taken, then a doctor should be consulted. Use and Area of Application The system is designed to be used in the following fields of application: •... -
Page 10: Correct Usage
The five tergumed 710 test and training machines train the relevant muscle groups that are for the stabilisation of the spinal column. The name of each machine refers to the movement that is performed with the appropriate machine for the test or training (Extension, Flexion, Lateral flexion, Rotation, Cervical (-extension, -flexion, -lateral flexion).) -
Page 11: Characterisation Of The Patients
Characterisation of the patients The use of the tergumed 710 is intended for users from 14 to 80 years old, as long as the ergonomic requirements are met and the necessary support is ensured. The contra-indicators listed in Chapter 3.5 must be observed. The use is intended for both female and male users. -
Page 12: Prepare The Product For Use
24 months. Note: If you do however fine some unexpected damage stop the training immediately. If there is a problem, which you cannot easily solve then contact the proxomed ® Service. The authorised Service will provide you with quick and competent help or give you instructions on how to do this. -
Page 13: Training Manual And Technical Data
Testing of electrical components and the correct functioning of the software is subject to the compulsory start-up of the machine at the client's location. Training Manual and Technical Data 11.1 Basic patient positioning In addition to the device-specific chronological sequence for the positioning of the trainee or patient, there are some basic guidelines for all five machine types. -
Page 14: General Settings And Optional Accessories
® It is necessary that the weight pin be always inserted to until it stops. Only original weight pins from proxomed ® are to be used! The weight block includes a special slot below the weight stack for fixing the lever arm. -
Page 15: Smartpanel
Automatic seat height adjustment after the chip card in the SmartPanel has been inserted. Article number • Electronic seat height incl. auto-lift tergumed 710: Item 10353000 only on new machines 12.7 Seat tilt adjustment for Back-Extension and Back Curler (optional) Correct Usage Setting the seat tilt with the Back-Extension and Back Curler in a range of plus or minus 8 degrees. -
Page 16: Specific Data For The Machines Of The Tergumed
Specific data for the machines of the tergumed ® 710 line 13.1 tergumed ® 710 Extension, item 10350100 Correct Usage With this machine, the back extensors are trained. The training takes place usually in a closed system, i.e. the soles of the feet are in contact with a footrest, while the knee is fixed from the front. -
Page 17: Tergumed ® 710 Flexion, Item 10350200
13.2 tergumed ® 710 Flexion, item 10350200 Correct Usage With this machine, the trunk muscles are trained. The training takes place usually in a closed system, i.e. the feet are in contact with a footrest, while the knee is fixed from the front. This allows an optimal stabilisation of the pelvis during the exercise. -
Page 18: Tergumed ® 710 Rotation, Item 10350300
13.3 tergumed ® 710 Rotation, item 10350300 Correct Usage With this machine, the oblique and deep abdominal muscles are trained. The training takes place in a closed system, i.e. the feet are in contact with a footrest, while the knee is fixed from the front. This allows an optimal stabilisation of the pelvis during the exercise. -
Page 19: Tergumed ® 710 Lateral Flexion, Item 10350400
13.4 tergumed ® 710 Lateral Flexion, item 10350400 Correct Usage With this machine, the lateral trunk muscles are trained. The pelvis is secured via a pelvic fixation. The feet are placed on the machine floor in approximately 90 degrees of rotation to the knee and fixed above the hip displacement padding from the front near the pelvis. -
Page 20: Tergumed 710 Cervical Trainer, Item 10350500
13.5 tergumed ® 710 Cervical Trainer, item 10350500 General Information With this machine, the dorsal, ventral and the lateral cervical muscles are trained. The implementation of the initial test or a training session on the tergumed ® Cervical Trainer should always take place with the positioning in the extension movement and the other directions of movement based on these settings. -
Page 21: Tergumed ® 710 Cervical Flexion
The lever arm length can be continuously adapted after releasing the rotary screw. The starting position (in flexion) for the extension movement can be set in 7.5 ° steps by pulling the locking pin on the excenter. The weight load can be continuously adapted to the weight stack with the adjustment wheel. -
Page 22: Tergumed ® 710 Cervical Lateral Flexion
13.5.3 tergumed ® 710 Cervical Lateral Flexion Correct Usage The cervical lateral flexion muscles are trained by using this machine. The stabilisation of the torso is via the lateral stabilisation padding. Following after consultation with a injuries can be treated physician . -
Page 23: Training Recommendation
Guarantee The basis are the Terms and Conditions from proxomed for warranty, as far as no other agreement has been made. Our general Terms and Conditions of sale and terms of payment in the respective current version can be viewed on our website: http://www.proxomed.de/de/agb.php... -
Page 24: Training Weight Cervical Trainer
Training weight Cervical Trainer Page 21... - Page 25 Page 22...
- Page 26 Manual are only approximated for typographical reasons; we assume no liability for typographical errors. Errors and omissions accepted. 0123 ® proxomed is a company certified by the TÜV SÜD Product Service GmbH. User Manual tergumed 710 Version 06, 04.10.2017 User Manual Page 23 Version 05...
