This instruction manual contains important information necessary for the
proper assembly and safe use of the appliance.
•
Read and follow all warnings and instructions before assembling and
using the appliance.
•
Keep this manual for future reference.
Questions, problems, missing parts? Before returning to the retailer, please call your Barbeques
Galore customer service department at 1800 978 555 for after sales service and support.
FOR OUTDOOR USE ONLY. NOT FOR COMMERCIAL USE.
4 Burner Hotplate Barbeque
Operating Instructions
Product Code: G4NEX
Model Number: 720-0786D
(See also Assembly Instructions
Manual)
Part Number: 19000791A0
Advertisement
Table of Contents
Related Manuals for Nexgrill G4NEX
Summary of Contents for Nexgrill G4NEX
- Page 1 4 Burner Hotplate Barbeque Operating Instructions Product Code: G4NEX Model Number: 720-0786D (See also Assembly Instructions Manual) • This instruction manual contains important information necessary for the proper assembly and safe use of the appliance. • Read and follow all warnings and instructions before assembling and using the appliance.
-
Page 2: Table Of Contents
Table of Contents Safety Instruction ......3 Care and Maintenance ....12 Gas Hook–Up . -
Page 3: Safety Instruction
Safety Instruction DANGER WARNING If you smell gas: Do not store or use gasoline or other flammable liquids or vapours in the • Shut off gas to the appliance. vicinity of this or any other appliance. • Extinguish any open flame. •... - Page 4 WARNING CAUTION: Beware of Flashback Do not try lighting this appliance without reading the “LIGHTING INSTRUCTIONS” section of this manual. CAUTION: Spiders and small insects occasionally spin webs or make nests in the CERTIFIED IN ACCORDANCE WITH AS 5263.0-2013 & burner tubes during transit and ®...
- Page 5 • LP-Gas Supply System DO NOT install this unit into combustible enclosures. Minimum clearance from sides and back of unit to • If the information is not followed combustible construction, 91.44 cm / 36 in. from sides exactly, a fire resulting in death 305 mm and 91.44 cm / 36 in.
- Page 6 When using the barbeque, do not touch the cooking surfaces, WARNING flame tamer or immediate surroundings as these areas Keep a spray bottle of soapy water near the gas supply become extremely hot and could cause burns. Use only dry valve and check the connections before each use.
- Page 7 Diagrammatical Representation Of “Outdoor Areas” Within a partial enclosure that includes an overhead cover and more than two walls, the following shall apply: This appliance shall only be used in an above ground open- air situation with natural ventilation, without stagnant areas, One wall that is equivalent to at least 25% of the total wall area where gas leakage and products of combustion are rapidly is completely open.
-
Page 8: Gas Hook-Up
Gas Hook-Up L.P. TANK REQUIREMENT Make sure all burner valves are in their OFF position. Inspect valve connections, port, and regulator assembly. Only gas cylinders with a "POL" low pressure connection are Look for any damage or debris. Remove any debris. to be used with this BBQ. -
Page 9: Leak Testing
Leak Testing GENERAL ALWAYS CHECK FOR LEAKS AFTER EVERY L.P. GAS CYLINDER CHANGE Although all gas connections on the barbeque are leak tested at the factory prior to shipment, a complete gas leak test check must be performed at the installation site due to possible mishandling in shipment, or excessive pressure Check all gas supply fittings for leaks before each use. -
Page 10: Seasoning Your Hotplate
Seasoning Your Hotplate IMPORTANCE OF HOTPLATE SEASONING SEASONING YOUR HOTPLATE It is very important to maintain a seasoned hotplate surface Thoroughly clean off food residue. in order to maintain optimum performance and long life of Evenly apply a generous amount of cooking oil (flax the unit. -
Page 11: Component Identification
Match Light 1. If the burner will not light after several attempts then the burner can be match lit. Before using the match, turn the knobs clockwise to OFF and allow 5 minutes for any accumulated gas to dissipate. 2. Clip a match on one end of the lighting rod. 3. -
Page 12: Care And Maintenance
Care and Maintenance HOTPLATE SURFACE Warning: If you wish to replace main burner, we strongly recommend that you hire a professionally To clean your hotplate following each use, gently scrape any trained technician to replace it. Please understand that remaining food residue with a spatula and wipe with a towel. we will not be responsible for any liability, personal To remove stuck food, pour hot water onto hotplate surface to injury, or property damage resulting from an... -
Page 13: Troubleshooting
Troubleshooting SPIDER AND INSECT WARNING PREHEATING Checking and cleaning burner/ venturi tubes for insects and It is necessary to preheat the barbeque before cooking insect nests. A clogged tube can lead to a fire beneath the certain foods, depending on the type of food and the cooking barbeque. -
Page 14: Ordering Parts
Ordering Parts HOW TO ORDER REPLACEMENT PARTS To obtain replacement parts, contact your Barbeques Galore local store on 1800 978 555 for after sales To make sure you obtain the correct replacement part (s) for service and support. your gas barbeque, please refer to the parts list on page 20. The following information is required to assure getting the IMPORTANT correct part. -
Page 15: Cooking Chart
Cooking Chart WEIGHT OR HEAT APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS SETTING TIME AND TIPS Slice. Dot with butter or margarine. Wrap in Vegetables heavy -duty foil. Cook, turning occasionally. Fresh Beets Cook, turning once. Brush occasionally with Carrots Medium 12 to 20 minutes melted butter or margarine. - Page 16 WEIGHT OR HEAT APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS SETTING TIME AND TIPS Cook, turning occasionally. 30 to 40 Ribs Medium During last few minutes brush with barbecue minutes sauce. Turn several times. Ham steaks 2.5 cm / 1 in. High 4 to 8 minutes Trim edges.
-
Page 17: Recipe Suggestion
Recipe Suggestions BBQ SALMON Turn the burner to high. Drain seafood VEGETABLE KEBABS reserving marinade. On each of twelve 2 large salmon steaks 3 medium-sized zucchini 250 cm skewers, thread 2 shrimps and 2 tbs. Oil 12 cherry tomatoes 2 scallops, alternating with pineapple Salt &... -
Page 18: Warranty And Consumer Guarantee
WARRANTY AND CONSUMER GUARANTEE Barbeques Galore Warranty is provided in addition to other rights and remedies as set out below under ‘Consumer Guarantees’. Warranty Term Subject to the conditions set out below, this product is warranted to the purchaser to be free from defects in workmanship and materials from the date of purchase for the terms specified below. -
Page 19: Exploded View
Exploded View... -
Page 20: Parts List
Parts List Part (Description) QTY IN BARBEQUE PART NUMBER QTY IN SPARE PARTS PACK Griddle NX720-0786D01 Flame channel NX720-0786D02 Burner pin assembly NX720-0786D03 Burner NX720-0786D04 Burner igniter wire A NX720-0786D05 Burner igniter wire B NX720-0786D06 Burner igniter wire C NX720-0786D07 Burner igniter wire D NX720-0786D08 Grease box...
