Nexgrill Industries, Inc.
145 Brea Canyon Road
Walnut, CA 91789
ASSEMBLY & OPERATING INSTRUCTIONS FOR
OUTDOOR GAS GRILL
FOR MODEL 720-0008-T OUTDOOR GAS GRILL
TABLE OF CONTENTS
PAGE
SAFETY INSTRUCTIONS................................................................................1
ASSEMBLY INSTRUCTIONS............................................................................4
LIGHTING INSTRUCTIONS.............................................................................10
CLEANING & MAINTENANCE..........................................................................12
PARTS LIST..................................................................................................14
WARRANTY..................................................................................................16
READ THE FOLLOWING INSTRUCTIONS CAREFULLY AND BE SURE YOUR GRILL IS
PROPERLY INSTALLED, ASSEMBLED AND CARED FOR. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY
DAMAGE. IF YOU HAVE QUESTIONS CONCERNING ASSEMBLY OR OPERATION,
CONSULT YOUR DEALER, GAS APPLIANCE SERVICE REPRESENTATIVE OR YOUR
GAS COMPANY.
NOTE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH THE CONSUMER AFTER INSTALLATION.
NOTE TO THE CONSUMER:
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS OUTDOOR COOKING GAS APPLIANCE IS NOT INTENDED TO BE INSTALLED IN
OR ON RECREATION VEHICLES AND/OR BOATS.
IF YOU HAVE ANY QUESTIONS CONCERNING ASSEMBLY OR OPERATION, CALL OUR
SERVICE CENTER AT 1-800-913-8999, MONDAY THROUGH FRIDAY, 8:00AM-5:00PM
PACIFIC COAST TIME. PLEASE DO NOT RETURN TO THE PLACE OF PURCHASE.
Advertisement
Table of Contents
Related Manuals for Nexgrill 720-0008-T
Summary of Contents for Nexgrill 720-0008-T
-
Page 1: Table Of Contents
Nexgrill Industries, Inc. 145 Brea Canyon Road Walnut, CA 91789 ASSEMBLY & OPERATING INSTRUCTIONS FOR OUTDOOR GAS GRILL FOR MODEL 720-0008-T OUTDOOR GAS GRILL TABLE OF CONTENTS PAGE SAFETY INSTRUCTIONS……………………………………………………………………..1 ASSEMBLY INSTRUCTIONS………………………………………………………………….4 LIGHTING INSTRUCTIONS…………………………………………………………………..10 OPERATING INSTRUCTIONS………………………………………………………………. 11 CLEANING & MAINTENANCE………………………………………………………………..12 PARTS LIST……………………………………………………………………………………..14... -
Page 2: Safety Instructions
CAN/CGA. 1-b149.1 and/or 2 installation Code for Gas Burning Appliances and Equipment. THE LOCATION FOR YOUR GRILL Do NOT use your gas grill in garages, porches breezeways, sheds or other enclosed areas. Your gas grill is to be used OUTDOOR ONLY. Always... - Page 3 Safety Instructions Series or a combination LP-gas cylinder valve and quick-disconnect assembly complying with 1.5.5-c and a safety relief device having a direct communication with the vapor space of the cylinder,(2) the cylinder supply system must be arranged for vapor withdrawal, and (3)the cylinder used must include a collar to protect the cylinder valve.
- Page 4 NATURAL GAS SAFETY(FOR natural gas model) Your natural gas grill is designed to operate on 7’’ water column residential (1/4 psi or 1.75 kpa) regulate at the residential meter, Check with your gas utility for local gas pressure and with your local municipality for building code requirements.
- Page 5 Assembly Instruction PLEASE READ THE INSTRUCTIONS Tools required: Philips Head Screwdriver(not provided),Wrench(provided). The following hardware is provided ITEM DESCRIPTION TRUSS HEAD SCREW TRUSS HEAD SCREW Step 1: Remove side panels and casters from the carton. Secure two casters to side panel marked “...
- Page 6 Assembly Instructions Step 3: ” ” Assemble the front panel accordingly with 4 pieces of Truss Head 1/4 -20*1/2 Screw. Step 4: Remove the upper portion of grill from carton . Slide- in the upper portion of grill to the cart.
-
Page 7: Assembly Instructions
Assembly Instructions Step 5: ” ” Bolt the upper portion of grill the cart with Truss Head 1/4 -20 ×1/2 Screw in 4 corners of bowl assembly. Make sure 4 screws are tightened. Step 6: ” Assemble the back panel accordingly with 4 pieces of Truss Head 1/4 -20 ×... - Page 8 Assembly Instructions Step 7: ” ” Assemble side shelf on the left side of grill with 4 pieces of Truss Head 1/4 -20 × 1/2 screw .Make sure 4 screws are tightened. Repeat this figure on the right side of the grill for the left shelf.
- Page 9 Assembly Instructions Step 9 Assemble each condiment tray with two 1/4”-20 X 1/2” truss head screws . STEP 10: We provide four utensil hooks for the left tray. please hang the four hooks in the hole of the condiment tray.
- Page 10 Assembly Instruction Your gas grill is ready to use.
-
Page 11: Lighting Instructions
7. Adjust control knobs to desired cooking temperature. NOTE: To light gas grill with a match, follow steps 1 through 6 above. Then , insert lighted paper book match with lighting stick through the cooking grids to the burner. Press in the control knob and rotate left to “HI”... -
Page 12: Operation Instructions
As with all appliances, proper care and condition and prolong their life. Your gas grill is no exception. By following these cleaning procedures on a timely basis, your grill will be kept clean and working properly with minimum effort. -
Page 13: Cleaning &Maintenance
Grease will not be able to drip down into grease collector and a grease fire could occur. Exterior: Your gas grill is made of heavy stainless steel, it should provide you with years of trouble-free service. KEEPING... - Page 14 Cleaning & Maintenance CLEANING THE BURNER TUBES AND BURNER PORTS (to prevent FLASH-BACK) To reduce the chance of FLASH-BACK, the procedure below should be followed at least once a month in late summer or early fall when spiders are most active, or when your grill has not been used for an extended period of time.
- Page 15 Parts list ILLUSTRATED PARTS BREAKDOWN MODEL 720-0008-T OUTDOOR STAINLESS STEEL GAS GRILL...
-
Page 16: Parts List
Motor bracket HOW TO ORDER REPLACEMENT PARTS: To make sure you obtain the correct replacement part(s) for your gas grill, please refer to the parts list on this page. The following information is required to assure getting the correct part. -
Page 17: Warranty
Our obligation under this warranty is limited to repair or replacement, at our option, of the product during the warranty period. The extent of any liability of Nexgrill Industries inc. under this warranty is limited to repair or replacement. This warranty does resulting from any of the following: negligent use or misuse of the product supply use contrary to operating instructions, or alteration by any such repair or replacement.
