Disk-array enclosure types

2U, 25 2.5" drive DAE

3U, 15 3.5" drive DAE
62 EMC VNX Series VNX5600 Unified Installation Guide
DAEs are optional components that add extra storage.
If DAEs are used, the DAEs should be installed immediately above the last installed
system component in the cabinet. The arrangement of the DAEs in a cabinet may depend
upon a number of factors. The hardware information guide for your system provides
additional information on DAE assembling and arrangement.
Note
The 4U 60 drive DAE and the 3U 120 drive DAE are not included here. They require a deep
rack and a Services engagement.
Figure 46 on page 62 shows the 2U, 25 2.5" drive DAE type. This DAE type uses a 2U rail
kit for installation into the system cabinet.
Figure 46 2U, 25 2.5" drive DAE
B
#
Figure 47 on page 63 shows the 3U, 15 3.5" drive DAE type. This DAE type uses a 3U rail
kit for installation into the system cabinet.
A
VNX-000227
