Microsd Card Installation Guide - Amcrest IP2M-856EW User Manual

Note: Due to specific hardware limitations within your camera it is important to note
that these devices will not be able to automatically pan/tilt or pivot in either the app
or via the web UI on a computer. For this reason, it is imperative to make sure to
mount the cameras properly and position them as efficiently as you can to the areas
you wish to monitor. All positioning actions to the camera will have to be performed
manually.
To install the camera onto a wall, follow the steps below:
1. Use a Torx/Hex wrench (included) to open the dome enclosure by unfastening
the three inner hex screws on enclosure.
2. Place the installation sticker on the wall or ceiling surface that you wish to
mount your camera.
3. Using the X's on the installation sticker, drill 3 holes to allow for the insertion of
the included expansion bolts.
4. If the camera's cable will be exiting through the wall or ceiling surface, please be
sure to drill an exit hole and pull the cable through.
5. If the camera's cable will be exiting through the side of the camera, route the
cable through the U-shaped channel on the side of the enclosure.
6. Align the camera with the installation sticker, then line up the 3 screw holes in
the camera pedestal to the three plastic expansion bolts on the installation
surface. Put the three included screws through the camera then insert them
into the expansion bolts firmly.
7. Adjust the camera in the position that you want it to be in, then reattach the
dome body to the base of the camera. Note: Range of lens: vertical (0°～+65°),
horizontal (0°～+355°). When adjusting the camera into position, please ensure
that the camera's enclosure does not block the image or cause reflection of
IR light.

3.3 MicroSD Card Installation Guide

To Install a microSD card into your camera, please refer to the step by step guide below:
Note: You will need to access the camera's motherboard to insert the microSD card.
