Epson PowerLite 503c User Manual

Epson powerlite 503c: product information
Hide thumbs Also See for PowerLite 503c:
Table of Contents

Advertisement

Quick Links

Download this manual
speaker
foot release lever
foot
control panel
buttons
indicator
lights
power
inlet
®
Kensington
lock port
USB port
PS/2 mouse
port

Projector Specifications

General
Type of display
Poly-silicon Thin Film Transistor (TFT)
Size of LCD panels Diagonal: 0.9 inch (22.9 mm)
Lens
F=2.0 to 2.2, f=35 to 42 mm
Resolution
713c: 1024 768 pixels (native format)
503c: 800 600 pixels (native format)
Color reproduction 24 bit, 16.7 million colors
Brightness
713c: 1200 lumens (ANSI)
503c: 1000 lumens (ANSI)
Contrast ratio
400:1
Image size
26 to 300 inches
Projection distance 3.6 to 45.5 feet (1.1 to 13.8 meters)
Projection methods Front, rear, upside-down (ceiling mount)
Internal sound
system
1 W monaural
lens ring
remote control
receiver
foot
lens cap
computer connector
A/V jacks
audio jacks
S-Video connector
EPSON PowerLite 503c/713c Projector
Optical aspect ratio 4:3 (horizontal:vertical)
Zoom ratio
Noise level
Keystone correction
focus
angle
ring
Projection Lamp
foot
release
Type
lever
Power consumption 150 W
Lamp life
Part number
Remote Control
Range
Batteries
Mouse Compatibility
Supports PS/2, USB, ADB
Dimensions
Height
Width
Depth
Weight
Electrical
Rated frequency
Power supply
Power
consumption
Environmental
Temperature
Humidity
Safety
United States
Canada
CE Marking
9/01
1:1.2
42 dB
±15° (maximum)
UHE (Ultra High Efficiency)
About 1000 hours
ELPLP14
32.8 feet (10 meters)
Alkaline AA (2)
2.8 to 3.4 inches (72 to 87 mm)
8.4 inches (213 mm)
10.5 inches (267 mm)
5.8 lb (2.6 kg)
50 to 60 Hz
100 to 120 VAC, 1.9 A
200 to 240 VAC, 1.0 A
Operating: 230 W
Standby: 5 W
Operating: 41 to 95 °F (5 to 35 °C),
Storage: 14 to 140 °F (–10 to 60 °C),
Operating: 20 to 80% RH,
non-condensing
Storage: 10 to 90% RH,
non-condensing
FCC Part 15B Class B
UL1950 Rev. 3
DOC ICES003 Class B
CSA C22.2 No. 950 Rev. 3
Directive 89/336/EEC, 92/31/EEC
EN 60950
EPSON PowerLite 503c/713c Projector
