Status bar
1. HR: current sampled heart rate value
2. Lead-off and overload: In demo mode, it displays "DEMO ECG". In sampling mode, it
displays the detected lead status. A red lead icon represents lead-off. A yellow lead icon
represents overload.
3. Print status indication:
Display content
Process...
Waiting...
No Paper.
Print Timeout.
ECG Timeout
Low Power
Display field
The screen displays sampled 12-lead ECG waveform, by double clicking the waveform,
you can switch between 3-lead, 6-lead and 12-lead.
Operation field
Control the print display mode of the device through corresponding operation settings.
1. Speed: click the screen to switch the speed between 12.5 mm/s, 25 mm/s and 50 mm/s.
2. Gain (sensitivity): click the screen to switch the gain between 5 mm/mV, 10 mm/mV and 20
mm/mV. The calibration voltage signal and overall gain (sensitivity) can be checked by
calibration function.
3. Filter: click the screen to switch the filter between no filter, AC filter , EMG filter and DFT
filter.
4. Print mode: use the
6×2, Auto 4×3+1, Auto 4×3, Auto 3×4+1, Auto 3×4, Auto 2×6+1, Auto 2×6, Rhythm 7, Rhythm
6, Rhythm 5, Rhythm 4, Rhythm 3 and Rhythm 2.
5. Print/End print: use the
Auto mode: After starting to print, the system automatically prints and stores the real-time
12-lead ECG waveform. The length is determined by the relevant settings in the print setup.
Based on the settings, the automatic analysis data and conclusions are printed, and the system
automatically ends printing.
Manual mode: After starting to print, user need to switch the lead to print the waveform of
different leads, that is, the ECG printed in the manual mode is asynchronous, and the data is not
saved. User need to press the PRINT button again when the print needs to be terminated.
6. End sampling: After the device starts sampling, use the
and back to the main interface.
Explanation
It is printing.
It is finishing printing.
Lack of paper, user should restart printing after loading paper.
Communication failure between this system and printing
sub-system.
Communication failure between this system and sampling
sub-system.
Low power, it cannot start printing.
button to switch the print mode between Manual, Auto 6×2+1, Auto
button to start or end the printing operation.
20
EKG6012
button to end the sampling,
