CONTEC MEDICAL SYSTEMS 35072 User Manual

Finger oximeter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PROFESSIONAL MEDICAL PRODUCTS
PULSOXIMETRO OXY-2
OXY-2 FINGER OXIMETER
OXYMÈTRE DE POULS OXY-2
PULSIOXÍMETRO OXY-2
OXÍMETRO DE PULSO OXY-2
ΠΑΛΜΙΚΌ ΌΞΎΜΕΤΡΌ OXY-2
Manuale d'uso - User manual
Manuel de l'utilisateur - Guía de uso
Guia para utilização - Οδηγίες χρήσης
ATTENZIONE: Gli operatori devono leggere e capire
completamente questo manuale prima di utilizzare
il prodotto.
ATTENTION: The operators must carefully read
and completely understand the present manual
before using the product.
AVIS: Les opérateurs doivent lire et bien comprendre ce manuel avant d'utiliser le produit.
ATENCIÓN: Los operadores tienen que leer y entender completamente este manual
antes de utilizar el producto.
ATENÇÃO: Os operadores devem ler e entender completamente este manual antes
de usar o produto.
ΠΡΌΣΌΧΗ: Οι χειριστές αυτού του προϊόντος πρέπει να διαβάσουν και να
καταλάβουν πλήρως τις οδηγίες του εγχειριδίου πριν από την χρήση του.
CMS50DL (Gima 35072)
CONTEC MEDICAL SYSTEMS CO., LTD
No.112 Qinhuang West Street,
Economic & Technical Development Zone, Qinhuangdao,
Hebei Province, PEOPLE'S REPUBLIC OF CHINA
Made in China
Importato da / Imported by / Importé par / Importado por /
Importado por / Εισάγεται από:
Gima S.p.A. Via Marconi, 1 - 20060 Gessate (MI) Italy
gima@gimaitaly.com - export@gimaitaly.com
www.gimaitaly.com
Shanghai International Holding Corp. GmbH (Europe)
Eiffestrasse 80, 20537, Hamburg, Germany
+60°C
%
-40°C
0%
95%
106kPa
50kPa
0123
IP22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 35072 and is the answer not in the manual?

Questions and answers

Related Manuals for CONTEC MEDICAL SYSTEMS 35072

Summary of Contents for CONTEC MEDICAL SYSTEMS 35072

  • Page 1 ΠΡΌΣΌΧΗ: Οι χειριστές αυτού του προϊόντος πρέπει να διαβάσουν και να καταλάβουν πλήρως τις οδηγίες του εγχειριδίου πριν από την χρήση του. CMS50DL (Gima 35072) 0123 CONTEC MEDICAL SYSTEMS CO., LTD No.112 Qinhuang West Street, Economic & Technical Development Zone, Qinhuangdao, Hebei Province, PEOPLE’S REPUBLIC OF CHINA Made in China Importato da / Imported by / Importé...

  • Page 2: Instructions To User

    ENGLISH Instructions to User Dear users, thank you very much for purchasing the Pulse Oximeter. The Manual describes, in accordance with the Pulse Ox- imeter’s features and requirements, main structure, func- tions, specifications, correct methods for transportation, installation, usage, operation, repair, maintenance and storage, etc.

  • Page 3: Instructions For Safe Operations

    ENGLISH device is harmful to the eyes, so the user and the maintenance man should not stare at the light.  Testee can not use enamel or other makeup.  Testee’s fingernail can not be too long.  Please refer to the correlative literature about the clin- ical restrictions and caution.
  • Page 4 ENGLISH • The disposal of scrap instrument and its accessories and packings(including battery, plastic bags, foams and paper boxes) should follow the local laws and reg- ulations. • Please check the packing before use to make sure the device and accessories are totally in accordance with the packing list, or else the device may have the pos- sibility of working abnormally.

  • Page 5: Indication For Use

    ENGLISH 110kg).  The device may not work for all patients. If you are unable to achieve stable readings, discontinue use.  The update period of data is less than 5 seconds, which is changeable according to different individual pulse rate. ...

  • Page 6: Major Applications And Scope Of Application

    ENGLISH 2 OVERVIEW The pulse oxygen saturation is the percentage of HbO in the total Hb in the blood, so-called the O concen- tration in the blood. It is an important bio-parameter for the respiration. For the purpose of measuring the SpO more easily and accurately, our company developed the Pulse Oximeter.

  • Page 7: Environment Requirements

    ENGLISH The product is not suitable for use in continu- ous supervision for patients. The problem of overrating would emerge when the patient is suffering from toxicosis which caused by carbon monoxide, the de- vice is not recommended to be used under this circumstance.

  • Page 8: Clinical Restrictions

    ENGLISH Glow and Infrared-ray Emission Tube Glow and Infrared-ray Receipt Tube Figure 1. Operating Principle 3.2 Caution 1. The finger should be placed properly (see the at- tached illustration of this manual, Figure 5), or else it may cause inaccurate measurement. 2.

  • Page 9: Technical Specifications

    ENGLISH will be more sensitive to interference. 2. For those with a substantial amount of staining dilu- tion drug (such as methylene blue, indigo green and acid indigo blue), or carbon monoxide hemoglobin (COHb), or methionine (Me+Hb) or thiosalicylic he- moglobin, and some with icterus problem, the SpO determination by this monitor may be inaccurate.

  • Page 10: Installation

    ENGLISH 9. Optical Sensor Red light (wavelength is 660nm, 6.65mW) Infrared (wavelength is 880nm, 6.75mW) Optical sensor is a light-emitting component, which will affect other medical devices ap- pling the same wavelength range. 5 ACCESSORIES • One hanging rope • Two batteries (optional) •...

  • Page 11: Mounting The Hanging Rope

    ENGLISH 6.2 Battery Step 1. Refer to Figure 3. and insert the two AAA size batteries properly in the right direction. Step 2. Replace the cover. Please take care when you insert the batter- ies for the improper insertion may damage the device.

  • Page 12: Repairing And Maintenance

    ENGLISH 7 OPERATING GUIDE 7.1 Insert the two batteries properly to the direction, and then replace the cover. 7.2 Open the clip as shown in Figure 5. 7.3 Let the patient’s finger put into the rubber cushions of the clip (make sure the finger is in the right posi- tion), and then clip the finger.

  • Page 13: Troubleshooting

    ENGLISH High-pressure sterilization cannot be used on the device. Do not immerse the device in liquid. It is recommended that the device should be kept in a dry environment. Humidity may reduce the useful life of the de- vice, or even damage it. 9 TROUBLESHOOTING Trouble Possible Reason...
  • Page 14 ENGLISH 10 SYMBOLS Symbol Description Type BF applied part % SpO The pulse oxygen saturation(%) PRbpm Pulse rate (bpm) The battery voltage indication is deficient (change the battery in time avoiding the inexact measure) 1. No finger inserted 2. An indicator of signal inadequacy Battery positive electrode Battery cathode Power switch...

  • Page 15: Function Specification

    ENGLISH Manufacturer Authorized representative in the European community Date of manufacture +60°C Store between -40 and 60°C -40°C Humidity limitation 106kPa Atmospheric pressure limitation 50kPa 11 FUNCTION SPECIFICATION Display Information Display Mode The Pulse Oxygen Digital Saturation (SpO Pulse Rate (BPM) Digital Pulse Intensity (bar-graph) Digital bar-graph display...
  • Page 16 ENGLISH Battery Requirement 1.5V (AAA size) alkaline batteries × 2 or rechargeable battery Battery Useful Life Two batteries can work continually for 24 hours Dimensions and Weight Dimensions 60(L) × 30.5(W) × 32.5(H) mm Weight About 50g (with the batteries) Disposal: The product must not be disposed of along with other domestic waste.
