INTRODUCTION
1.2 APC W
ORKING
APC D
IMENSIONS
E
A
APC W E
ORK NVELOPES
TOOL CHANGER COVER
C L
OF TOOL HOLDER V-GROOVE
LOWEST POINT ON CAROUSEL
MILL TABLE (AT HOME POSITION)
SIZE: VF-3 48" x 18", (121.92 cm x 45.72 cm)
TRAVEL: VF-3 40" x 20", (101.60 cm x 50.80 cm)
2
A u t o m a t i c A u t o m a t i c
A u t o m a t i c A u t o m a t i c
P a l l e t C h a n g e r
P a l l e t C h a n g e r
D
IMENSIONS
B
9" (22.86 cm)
19.38"
(49.23 cm)
5.8
(14.23 cm)
PALLET
ENCLOSURE USEABLE WORK SPACE
58"
(147.32 cm)
O M
PERATOR'S ANUAL
20" (50.8 cm) DOOR HEIGHT ABOVE PALLET.
A.
40" (101.6 cm) DOOR OPENING WIDTH.
B.
19" (48.26 cm) PALLET WIDTH.
C.
3/8" (.95 cm) DISTANCE BETWEEN PALLETS.
D.
1/2" (1.27) DISTANCE BETWEEN PALLET AND DOOR.
E.
40" (101.6) PALLET LENGTH.
F.
F
D
C
C
C L 0F TOOL HOLDER
TOOL
CHANGE
POSITION
CHIP TRAY
21.69"
(55 cm)
1.38" Chip Tray
(3.51 cm)
MAX Z-AXIS
TRAVEL
APC DOOR
OPENING
26"
(66 cm)
20"
(50.8 cm)
Top of
Pallet
46"
(116.84 cm)
