Haas TRT 210 Operator's Manual
Hide thumbs Also See for TRT 210:

Advertisement

Quick Links

Haas Technical Publications
HAAS SERVICE AND OPERATOR MANUAL ARCHIVE
TRT Tilting Rotary Table Operators Manual 96-5048 RevE English June 2002
This content is for illustrative purposes.
Historic machine Service Manuals are posted here to provide information for Haas machine owners.
Publications are intended for use only with machines built at the time of original publication.
As machine designs change the content of these publications can become obsolete.
You should not do mechanical or electrical machine repairs or service procedures unless you are qualified
and knowledgeable about the processes.
Only authorized personnel with the proper training and certification should do many repair procedures.
WARNING: Some mechanical and electrical service procedures can be
extremely dangerous or life-threatening.
Know your skill level and abilities.
All information herein is provided as a courtesy for Haas machine owners
for reference and illustrative purposes only. Haas Automation cannot be held
responsible for repairs you perform. Only those services and repairs that are
provided by authorized Haas Factory Outlet distributors are guaranteed.
Only an authorized Haas Factory Outlet distributor should service or repair a
Haas machine that is protected by the original factory warranty. Servicing by
any other party automatically voids the factory warranty.
Manual_Archive_Cover_Page Rev A
June 6, 2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRT 210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Haas TRT 210

  • Page 1 TRT Tilting Rotary Table Operators Manual 96-5048 RevE English June 2002 • This content is for illustrative purposes. • Historic machine Service Manuals are posted here to provide information for Haas machine owners. • Publications are intended for use only with machines built at the time of original publication. •...
  • Page 2 Manual_Archive_Safety_Pages Rev A June 6, 2013 Haas Technical Publications...
  • Page 3: Read Before Operating

    Manual_Archive_Safety_Pages Rev A Haas Technical Publications June 6, 2013 EFORE PERATING ACHINE ♦ Only authorized personnel should work on this machine. Untrained personnel present a hazard to themselves and the machine, and improper operation will void the warranty. ♦ Use appropriate eye and ear protection while operating the machine. ANSI approved impact safety goggles and OSHA approved ear protection are recommended to reduce the risks of sight damage and hearing loss. ♦ Do not operate the machine unless the doors are closed and the door interlocks are functioning properly. Rotating cut- ting tools can cause severe injury. When a program is running, the mill table and spindle head can move rapidly at any time in any direction. ♦ The Emergency Stop button is the large, circular red switch located on the Control Panel. Pressing the Emergency Stop button will instantly stop all motion of the machine, the servo motors, the tool changer, and the coolant pump. Use the Emergency Stop button only in emergencies to avoid crashing the machine. ♦ The electrical panel should be closed and the key and latches on the control cabinet should be secured at all times except during installation and service. At those times, only qualified electricians should have access to the panel. When the main circuit breaker is on, there is high voltage throughout the electrical panel (including the circuit boards and logic circuits) and some components operate at high temperatures. Therefore, extreme caution is required. Once the ma- chine is installed, the control cabinet must be locked and the key available only to qualified service personnel. ♦ Consult your local safety codes and regulations before operating the machine. Contact you dealer anytime safety is- sues need to be addressed. ♦ DO NOT modify or alter this equipment in any way. If modifications are necessary, all such requests must be handled by Haas Automation, Inc. Any modification or alteration of any Haas Milling or Turning Center could lead to personal injury and/or mechanical damage and will void your warranty. ♦ It is the shop owner’s responsibility to make sure that everyone who is involved in installing and operating the machine is thoroughly acquainted with the installation, operation, and safety instructions provided with the machine BEFORE they perform any actual work. The ultimate responsibility for safety rests with the shop owner and the individuals who...
  • Page 4: Modifications To The Machine

    Manual_Archive_Safety_Pages Rev A June 6, 2013 Haas Technical Publications ♦ Follow these guidelines while performing jobs on the machine: Normal operation - Keep the door closed and guards in place, while machine is operating. Part loading and unloading – An operator opens the door or guard, completes task, closes door or guard before press- ing cycle start (starting automatic motion). Tool loading or unloading – A machinist enters the machining area to load or unload tools. Exit the area completely before automatic movement is commanded (for example, next tool, ATC/Turret FWD/REV). Machining job set-up – Press emergency stop before adding or removing machine fixtures. Maintenance / Machine Cleaner– Press emergency stop or power off the machine before entering enclosure. Do not enter the machining area anytime the machine is in motion; severe injury or death may result. Unattended Operation Fully enclosed Haas CNC machines are designed to operate unattended; however, your machining process may not be safe to operate unmonitored. As it is the shop owner’s responsibility to set up the machines safely and use best practice machining techniques, it is also their responsibility to manage the progress of these methods. The machining process must be monitored to pre- vent damage if a hazardous condition occurs. For example, if there is the risk of fire due to the material machined, then an appropriate fire suppression system must be installed to reduce the risk of harm to personnel, equipment and the building. A suitable specialist must be contacted to install monitoring tools before machines are allowed to run unattended. It is especially important to select monitoring equipment that can immediately perform an appropriate action without human intervention to prevent an accident, should a problem be detected. MODIFICATIONS TO THE MACHINE DO NOT modify or alter this equipment in any way. If modifications are necessary, all such requests must be handled by Haas Automation, Inc. Any modification or alteration of any Haas machining center could lead to personal injury and/or mechanical damage and will void your warranty.
  • Page 5: Safety Decals

    Manual_Archive_Safety_Pages Rev A Haas Technical Publications June 6, 2013 SAFETY DECALS To help ensure that CNC tool dangers are quickly communicated and understood, hazard symbol decals are placed on Haas Machines in locations where hazards exist. If decals become damaged or worn, or if additional decals are needed to emphasize a particular safety point, contact your dealer or the Haas factory. Never alter or remove any safety decal or symbol. Each hazard is defined and explained on the general safety decal, located at the front of the machine. Particular loca- tions of hazards are marked with warning symbols. Review and understand the four parts of each safety warning, explained below, and familiarize yourself with the symbols on the following pages. NEVER OPERATE THIS MACHINE WITH THE DOORS OPEN...
  • Page 6 Manual_Archive_Safety_Pages Rev A June 6, 2013 Haas Technical Publications MILL WARNING DECALS...
  • Page 7 Manual_Archive_Safety_Pages Rev A Haas Technical Publications June 6, 2013 LATHE WARNING DECALS...
  • Page 8 Manual_Archive_Safety_Pages Rev A June 6, 2013 Haas Technical Publications OTHER SAFETY DECALS Other decals may be found on your machine, depending on the model and options installed:...
  • Page 9 1.1 D ESCRIPTION The HAAS tilting rotary table is a fully automatic, programmable, rotary positioning device. The unit is made up of a mechanical table that holds the workpiece, a second table that rotates the first, and an electronic unit that controls the movement of the tables.
  • Page 10 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 11 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 12 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 13 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL (Approx Travel Limit) (Min. Clearance) -Compound angles in one set-up ...reduce run time, while increasing part accuracy -Continuous milling/spiral -Comes with standard air collet ±120°...
  • Page 14 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL B-Axis 360º A-Axis ±120º 13” 38.5” 7.06 8.50 26.21 2.99 9.46 37.14...
  • Page 15 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL " . 5 7 " . 0 0 " . 8 5 . 2 1 " 62.57 33.00 9.21 12.00 50.64 8.10 MOUNTING POSITION (BOTTOM VIEW)
  • Page 16 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 17 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL 1/2-13UNC T-Nuts, Studs, Flange nuts, and Washers Toe Clamp Assembly...
  • Page 18 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL Figure 1. SEMI-FOURTH AND -FIFTH AXIS OPERATION TO MILL TRT160 RS232 PORT OR A-AXIS INTERFACE PORT B-AXIS NING NING U .S HIGH HIGH NING NING HIGH HIGH...
  • Page 19 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL 49-0001 79-0001 Shipping Plate...
  • Page 20 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 21 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 22 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 23 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 24 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 25 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 26 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 27 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 28 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 29 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL G(AC25) F(AC125)
  • Page 30 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL 58-16755 58-4059 1. Valve Mounting Block 6. 1/4 Male Adapter 7. Quick Release Fitting 2. Slip Ring 3. Air Valve 8. Male Comp. Fitting 4.
  • Page 31 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 32 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL U .S U .S...
  • Page 33 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 34 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL STEP MODE PROG PROG DISPLAY DISPLAY SCAN SCAN OVER OVER HIGH HIGH DEGREES POWER SERVO SERVO RUNNING LOAD LOAD LOAD LOAD STEP STEP AXIS SCAN SCAN ZERO...
  • Page 35 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 36 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 37 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 38 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 39 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL U .S U .S...
  • Page 40 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 41 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL Brushless Rotary Two-Axis Control 7 8 9 MODE MODE PROG PROG DISPLAY SCAN STEP STEP SCAN SCAN CLEAR CYCLE CYCLE ZERO ZERO ZERO ZERO START START RETURN...
  • Page 42 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 43 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 44 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 45 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 46 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 47 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 48 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 49 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 50 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 51 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 52 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 53 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 54 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL STEP MODE PROG PROG DISPLAY DISPLAY SCAN SCAN OVER OVER HIGH HIGH DEGREES POWER SERVO SERVO RUNNING LOAD LOAD LOAD LOAD AXIS STEP STEP SCAN SCAN ZERO...
  • Page 55 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL 14 10 STEP MODE PROG PROG DISPLAY DISPLAY SCAN SCAN OVER OVER HIGH HIGH DEGREES POWER SERVO SERVO RUNNING LOAD LOAD LOAD LOAD AXIS STEP STEP SCAN...
  • Page 56 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 57 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 58 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL Brushless Rotary Two-Axis Control 7 8 9 MODE MODE PROG PROG DISPLAY SCAN STEP STEP SCAN SCAN CLEAR CYCLE CYCLE ZERO ZERO ZERO ZERO START START RETURN...
  • Page 59 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL 12 14 Brushless Rotary Two-Axis Control 7 8 9 MODE MODE PROG PROG DISPLAY SCAN STEP STEP SCAN SCAN CLEAR CYCLE CYCLE ZERO ZERO ZERO ZERO START...
  • Page 60 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 61 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 62 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 63 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 64 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 65 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 66 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 67 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 68 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 69 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 70 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 71 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 72 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 73 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL Front Platter Seal Rear Brake Seal...
  • Page 74 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 75 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 76 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 77 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL IT QTY P/N DESC 24 1 35-3073 INDEXER HANDLE ASSY 20-2059 HANDLE COLLET CLOSER 48-1664 PIN ROLL 3/16 X 5/8 48-1665 PIN DOWEL 5/16 X 3/4 IT QTY P/N DESC 25 1...
  • Page 78 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
  • Page 79 TILTING ROTARY TILTING ROTARY T A B L E T A B L E PERATOR’S ANUAL...
