Summary of Contents for Epson EMP-6100
- Page 1 EMP Monitor Operation Guide...
-
Page 2: Meanings Of Symbols Used
Indicates information that is related to a topic or which may be useful to know. Indicates a page where a related topic or more a detailed explanation is provided. Indicates the name of a projector port or a computer menu or item name. [ (Name) ]... -
Page 3: Table Of Contents
Registration using automatic detection ... 5 Registration using IP address (Manual registration) ... 6 Editing the manually-registered projector list ... 7 Deleting a projector from the projector list... 7 Main EMP Monitor window Button functions... 8 Understanding the projector list... 9 Displaying detailed information ... -
Page 4: Operating Environment
Projector C System configuration example If the projector's "Network Monitoring" or "Standby Mode" configuration menu is set to "ON" or "Network ON", the projector can still be monitored when it is in standby mode (when the indicator is lit orange). -
Page 5: Registering Projectors For Monitoring
EMP Monitor is started from that point onwards. PROCEDURE Click [Start] - [Programs] (or [All Programs]) - [EPSON Projector] - [EMP Monitor] in that order to start EMP Monitor. -
Page 6: Registration Using Automatic Detection
Select the projector(s) to be registered, and then click [Add]. You can select several projectors at the same time. If a projector does not appear in the list, use "Registration using IP address (Manual registration)". • Projectors that have been registered using automatic detection will be re-detected on the basis of projector name and the IP addresses for these projectors will be displayed each time EMP Monitor is started. -
Page 7: Registration Using Ip Address (Manual Registration)
Enter the IP address for the projector to be registered in the [IP address] box, and then click [Confirm]. If a projector with the specified IP address is found on the network, the projector's name will be displayed, so check that it is the target projector. -
Page 8: Editing The Manually-Registered Projector List
Registering projectors for monitoring Editing the manually-registered projector list Use the following procedure to change the projector name or IP address for projectors that have been registered manually. PROCEDURE Select the projector to be edited in the [Register projector] dialogue box, and then click [Edit]. -
Page 9: Main Emp Monitor Window
Main EMP Monitor window The main window shows the status information for each projector. To carry our operations for projectors, select the projectors from the projector list and then click the buttons. To close the window, click the in the top-right corner. -
Page 10: Understanding The Projector List
Main EMP Monitor window Understanding the projector list The projector list uses the following icons to show the projector statuses. Status: Shows the projector status. Power on and normal status Power off and normal status Power on and abnormal status... -
Page 11: Displaying Detailed Information
Displaying detailed information You can check detailed information on the status of individual projectors that are connected. PROCEDURE Select the projector to be checked in the main window. Click [View details]. Detailed status information will be displayed in the [Details] dialogue box. -
Page 12: A Projector Cannot Be Monitored Or Controlled Using Emp Monitor
A projector cannot be monitored or controlled using EMP Monitor Cause Is the projector connected to Connect the network cable correctly. s"Network Cable Connections" in the the network correctly? accessory User's Guide Has the projector been set Check the settings for the "Network"... -
Page 13: Appendices
Appendices When using EMP-81/61, you need to make a setting for the adapter. Make the setting as shown in the following table. Menu Main Item Port Properties Serial Port Settings Connect Mode Settings Additional Settings Security Security Settings Sub Item Serial Protocol Speed Character Size... - Page 14 Neither is any liability assumed for damages resulting from the use of the information contained herein. Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses,...
