Manufacturer Part Number Qty Reference Designators
R28, R34, R36, R44, R46,
R54, R56, R64, R66, R74,
CRCW12060000Z0EA 17
R76, R84, R86, R94, R96,
R104, R106
RT0603BRD0710KL 1 R31
ERJ-3RQFR22V 1 R32
CRCW04022K70JNED 2 R33, R125
R35, R37, R40, R41, R45,
R47, R50, R51, R55, R57,
R60, R61, R65, R67, R70,
RG1608P-102-B-T5 32 R71, R75, R77, R80, R81,
R85, R87, R90, R91, R95,
R97, R100, R101, R105,
R107, R110, R111
R42, R43, R52, R53, R62,
R63, R72, R73, R82, R83,
CRCW06030000Z0EA 18
R92, R93, R102, R103, R112,
R113, R130, R133
R114, R115, R116, R117,
CRCW040249R9FKED 9 R118, R119, R120, R121,
R123
RC0402JR-070RL 1 R127
EVQPNF04M 1 S1
SH-J1, SH-J2, SH-J3, SH-J4,
382811-6 7
SH-J5, SH-J6, SH-J7
ED555/4DS 1 T1
1803332 4 T2, T3, T4, T5
ED555/3DS 1 T6
5001 2 TP1, TP2
5002 3 TP3, TP4, TP5
ADS8686-PZA 1 U1
TPS7A4700RGWR 1 U3
REF5025AIDGKT 1 U4
BR24G32FVT-3AGE2 1 U5
OPA192IDBVT 1 U6
INA149AID 1 U7
GRM188R60J106ME84 0 C20, C22
D4, D5, D6, D7, D8, D9, D10,
SMBJ14CA 0 D11, D12, D13, D14, D15,
D16, D17, D18, D19
SBAU319 – November 2019
Submit Documentation Feedback
Table 8. ADS8686S EVM Bill of Materials (continued)
Manufacturer
Vishay-Dale RES, 0, 5%, 0.25 W, 1206
Yageo America RES, 10.0 k, 0.1%, 0.1 W, 0603
Panasonic RES, 0.22, 1%, 0.1 W, 0603
Vishay-Dale RES, 2.7 k, 5%, 0.063 W, 0402
Susumu Co Ltd RES, 1.00 k, 0.1%, 0.1 W, 0603
Vishay-Dale RES, 0, 5%, 0.1 W, 0603
Vishay-Dale RES, 49.9, 1%, 0.063 W, 0402
Yageo America RES, 0, 5%, 0.063 W, 0402
Panasonic Switch, Tactile, SPST-NO, 0.05A, 12V, SMD
AMP Shunt, 100mil, Gold plated, Black
On-Shore Technology Terminal Block, 3.5mm Pitch, 4x1, TH
Phoenix Contact Header(shrouded), 3.81mm, 8x1, Tin, R/A, TH
On-Shore Technology Terminal Block, 3.5mm Pitch, 3x1, TH
Keystone Test Point, Miniature, Black, TH
Keystone Test Point, Miniature, White, TH
Texas Instruments 16-Channel DAS with 16-Bit, Bipolar Input, Dual Simultaneous Sampling ADC, PZA0080A (LQFP-80)
Texas Instruments 36-V, 1-A, 4.17-uVRMS, RF LDO Voltage Regulator, RGW0020A (VQFN-20)
Low Noise, Very Low Drift, Precision Voltage Reference, -40 to 125 degC, 8-pin MSOP(DGK), Green (RoHS & no
Texas Instruments
Sb/Br)
Rohm I2C BUS EEPROM (2-Wire), TSSOP-B8
Precision, Rail-to-Rail Input/Output, Low Offset Voltage, Low Input Bias Current Op Amp with E-trim, 4.5 to 36 V,
Texas Instruments
-40 to 125 degC, 8-Pin SOT-23 (DBV), Green (RoHS & no Sb/Br), Tape and Reel
Texas Instruments High Common Mode Voltage Difference Amplifier, -40 to 125 degC, 8-pin SOIC (D8), Green (RoHS & no Sb/Br)
MuRata CAP, CERM, 10 uF, 6.3 V, +/- 20%, X5R, 0603
Littelfuse Diode, TVS, Bi, 14 V, SMB
