Summary of Contents for CAS MW-II Series
-
Page 2: Table Of Contents
CONTENTS PRECAUTIONS ..........4 PREFACE ............6 NAMES AND FUNCTIONS ......6 OPERATIONS ..........8 General Weighing..........8 Weighing with Tare ......... 10 Counting Mode..........10 % Mode ............12 Set Mode ............13 RS232C INTERFACE ........20 ERROR MESSAGE ........ -
Page 3: Precautions
PRECAUTIONS... - Page 4 PRECAUTIONS...
-
Page 5: Preface
We believe that your needs will be satisfied and you will have reliability with in variable weight. This manual will help you with proper operations and care of the MW-II series. Please keep it handy for the future references. NAMES AND FUNCTIONS... - Page 6 DISPLAY KEYBOARD ■ KEY FUNCTIONS KEYS FUNCTIONS Used to set the zero point to 0. 00. Used to enter a tare weight and used to cancel a tare weight. Used to enter the weight of sample in PCS and % mode. Used to convert the mode as below.
-
Page 7: Operations
POWER Use only DC 9V/300mA adaptor. Insert the adaptor jack into the outlet and turn on the scale. OPERATIONS ■ When you turn on the display, make sure that the platter is empty. “OL-H” Otherwise, the display will show the . - Page 8 ■ Sample Print Format 2000/10/13 - Date is automatically printed after printing 13:24:52 w : 100.00 g 10 items. 13:34:52 w : 99.99 g - If the mode is changed, date is printed automatically. - W means that weight is stable and w means 13:45:23 w : 100.00 g that weight is not stable.
-
Page 9: Weighing With Tare
Weighing with Tare ■ Tare is the weight of container being used for a commodity. ■ The TARE key subtracts the weight of the container. ① Place the container on the platter. ② Press the TARE key, then you will see the NET on the display. - Page 10 ② To change sample size, press the PRINT key until the display shows “PUt 20”, “PUt 50”, “PUt100” or “PUt200”. ③ Place 10 samples on the platter and press the SET key, when the display shows “Put 10”. If the display shows “10”, you can count samples from now.
-
Page 11: Mode
2) Counting samples If you have set the sample size, place another samples to count on the platter then the display shows the number of samples. To exit this counting mode, press the MODE key. ▶ Note that you can use tare function and zero adjustment in counting mode. % Mode ■... -
Page 12: Set Mode
Setup Mode To go to setup mode, press the SET key for 3 seconds. In this mode, you can set the scale for your specific applications. MENU SUB MENU OPTION DESCRIPTION U.grAm ON/OFF ON: You can use this unit or U.ct ON/OFF function on weighing... - Page 13 U.OZt MW-II (Setup Mode)
- Page 14 ■ UNIT ① Press the SET key for 3 seconds. you will see the unit menu. ② Press the SET key, you can set unit gram. ③ Press the SET key, you will see the default. - On : You can use gram unit on weighing mode. - Off : You can not use gram unit on weighing mode.
- Page 15 ③ Press the SET key. ④ Press the SET key, you will see the default. ⑤ Press the MODE key to change this option. - KEY : Printing is performed by pressing the PRINT key. - AUTO : Printing is performed automatically when the weight or the unit is changed and the display is stable..
- Page 16 ■ Print Control Code Letter Style Code Enlarged width + Double print 1b.21.30 Bold 1b.21.08 Double print 1b.21.10 Enlarged width 1b.21.20 Underline 1b.21.80 4) “P .PdAtE” ① Press the MODE key, you will see “P .PdAtE” menu on the display. ②...
- Page 17 ⑤ Press the MODE key until the display shows option you want. - ON : Power is always turned ON. - 10 min : If you don’t operate the scale for 10 minutes, power is turned off automatically. - 30 min : If you don’t operate the scale for 30 minutes, power is turned off automatically. - 60 min : If you don’t operate the scale for 60 minutes, power is turned off automatically.
- Page 18 5) Back light - “ S.bAcKL” ▶ Note : If you purchase the scale with back light function, y ou can see this menu. ① Press the MODE key, you will see “S.bAcKL” menu on the display. ② Press the SET key, you will see the default(OFF). ③...
-
Page 19: Rs232C Interface
RS 232C INTERFACE ■ You can control the scale by using the PC. - Use Hyper terminal program. ■ Open the hyper terminal program and press the Z key on the keyboard of PC, zero adjustment is performed. If you press the P key on the keyboard of PC, you will see the weight on the screen. -
Page 20: Error Message
ERROR MESSAGE ERROR DESCRIPTION SOLUTIONS Call your CAS dealer for Calibration Error span calibration Under load Error ① ① There is no platter Place the platter ② ② Sample weight is low Place more samples on the platter See minimum sample... -
Page 21: Specifications
SPECIFICATION ※MW-2N High Resolution Series MODEL 2000 3000 6000 MAXIMUM CAPACITY 200g 300g 600g MINIMUM SCALE e=d= e=d= e = d = 0.005g e =d = 0.05g DIVISION 0.01g 0.1g TARE SUBTRACTION 200g 300g 600g DISPLAY 6 digit(L.C.D) WEIGHT UNIT g, ct, oz, ozt, lb, tL, dwt, mom, GN, PCS, % LINEARITY ±0.005g... - Page 22 ※MW-2N Low Resolution Series MODEL 2000 3000 6000 MAXIMUM CAPACITY 200g 300g 600g MINIMUM SCALE e=d= e=d= e = d = 0.01g e =d = 0.1g DIVISION 0.02g 0.2g TARE SUBTRACTION 200g 300g 600g DISPLAY 6 digit(L.C.D) WEIGHT UNIT g, ct, oz, ozt, lb, tL, dwt, mom, GN, PCS, % LINEARITY ±0.01g ±0.02g...
- Page 23 MEMO...
- Page 24 MEMO...
- Page 25 MEMO...
