COMPONENT LIST

Battery size shown for
illustrative purposes only
1. SAFETY INTERLOCK SWITCH
2.
ON/OFF SWITCH
3. DUST NOZZLE
4 BASE PLATE LOCKING LEVER
5. BASE PLATE
PENDULUM STROKE ADJUSTING
6.
LEVER
7. BLADE GUIDE ROLLER
*If applicable
10
2825 21-18JS Jig Saw Manual.indd 10 2825 21-18JS Jig Saw Manual.indd 10
13
10
8
11
12
1
5
6
7
FASTENING SCREWS FOR THE
8.
PARALLEL STOP
9. PARALLEL STOP
10. CHARGER*
BATTERY PACK* -
11.
BLE ON PAGE 11 FOR BATTERY INFORMATION
BATTERY TEST BUTTON AND
12.
CHARGE INDICATOR*
13. BLADE FIXTURE
