- Page 1 PSGL1500 1500VA GLADIATOR Line Interactive Pure Sine Wave UPS NetGuard Software ® ® Download the latest PowerShield NetGuard UPS Monitoring Software: www.powershield.com.au/downloads Default password: administrator Version: 1.1...
-
Page 2: Table Of Contents
Table of Contents SAFETY INSTRUCTION ..................1 1. Introduction ....................3 2. Package Contents ..................3 3. Product Overview ..................3 4. Installation ....................4 5. Battery Replacement ................... 7 6. Operation ....................9 7. Trouble Shooting ..................15 8. Specifications ..................... 16... -
Page 3: Safety Instruction
SAFETY INSTRUCTION Thank you for purchasing this PowerShield power protection product. Please comply with all warnings and operating instructions in this manual. Save this manual and carefully read the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. - Page 4 Maintenance, service and faults The UPS system operates with hazardous voltages. Repairs may be carried out only by qualified maintenance personnel. Caution - risk of electric shock. Even after the unit is disconnected from the mains (building wiring outlet), components inside the UPS system are still connected to the battery and electrically live and dangerous.
-
Page 5: Introduction
1. Introduction This PowerShield product is an intelligent line interactive pure sinewave UPS (Uninterruptible Power Supply) which is designed to protect your personal computer or sensitive electronic equipment from all forms of power interference, including complete power failure. 2. Package Contents NOTE: Before installation, please inspect the unit. -
Page 6: Installation
Place UPS: This PowerShield UPS is equipped with a fan for cooling. Therefore, place the UPS in a well-ventilated area. Maintain minimum clearance of 100mm in the front of the UPS and 300mm... - Page 7 The CPU Monitor file can be downloaded from https://powershield.com.au/support- menu/download-area/netguard-software-downloads/ HID Function This PowerShield UPS is equipped with HID function. You may simply connect one computer with installed OS via USB port to execute safe shutdown during power failure even though there is no monitoring software installed.
- Page 8 Step 4: Turn On the UPS Before using the UPS, be sure to remove this label from the LCD remote panel module. To turn on the UPS, simply press the ON/OFF button on the front panel for 2 seconds. UPS will beep once and LED bars will light up with different colors in order of light blue, orange, yellow, green, blue, purple and scroll from bottom to top in 6 secs.
-
Page 9: Battery Replacement
3 to 5 years. Environmental factors do affect battery life. High temperatures, poor utility power, and frequent, short duration discharges have a negative impact on battery life. l WARNING! This PowerShield UPS contains potentially hazardous voltages. Do not attempt to disassemble the UPS beyond the battery replacement procedure. - Page 10 Please follow the steps below to replace the batteries if necessary. Step 1: Turn off the equipment that is plugged into the output of the UPS. Step 2: Turn off the UPS. Step 3: Remove AC input plug of the UPS from the AC wall outlet. Step 4: Remove all equipment from the output sockets of the UPS.
-
Page 11: Operation
6. Operation Button Function Button Function ON/OFF Press and hold 2 seconds to turn on or off the UPS. Hold “on/off” button for 10 seconds to reset the unit in case of communication failure between remote panel and UPS. Quick press 5 times to reset pairing when wireless transmission fails. - Page 12 Load information Indicates the load level by 0-24%, 25-49%, 50-74% and 75- 100%, or overload alarm. Mode operation information UPS operates on the Line mode. UPS operates on the AVR mode. UPS operates on the Battery mode. Setting of LED bars. Indicates PC’s CPU temperature (°C) Setting the temperature alarm level.
- Page 13 Warning Indicator Display Warning Flashing/on Alarm Over-current on output Flashing every 0.5 secs Sounding every 0.5 secs Overload Flashing every 0.5 secs Sounding every 0.5 secs Low battery Flashing every 0.5 secs Sounding every 1 sec Battery replacement or Sounding every 2 secs battery is not connected.
- Page 14 LED OFF LED ON(default) On-Off RGB LED ENERGY SAVING Normal(default) Brightness of RGB LED High Normal(default) Scrolling speed of RGB LED High Breath(default) Scrolling Effects of RGB Solid White Orange Green Yellow(default) Color selection of RGB LED in Blue Purple Line mode Others Orange...
- Page 15 White Orange Yellow Green Color selection of RGB LED in Blue(default) Purple Battery mode Others Backlight control When remote 1min (default) Permanent on panel is connected to Setting range is from permanent on, then 1 to 60 minutes. Increment of each click is 1 min. docking base Permanent on When remote...
- Page 16 Selectable Selectable LCD Screen LCD Screen Information Information NiMH Input battery frequency voltage PC CPU Battery frequency voltage PC CPU Battery temperature Capacity Estimated backup time utilization Panel board Output firmware Voltage version Output Firmware Frequency version of docking base board Output UPS control...
-
Page 17: Trouble Shooting
7. Trouble Shooting If the UPS system does not operate correctly, please solve the problem by using the table below. Problem/Fault code Possible Cause/Fault Event Solutions UPS will not turn on after Hold the On/Off button too short. Press and hold the On/Off button pressing On/Off button. -
Page 18: Specifications
Overload fault Contact your dealer. is on. icon is illuminated and a The UPS has an internal problem. Contact your dealer. constant alarm. 8. Specifications POWERSHIELD GLADIATOR GAMING UPS MODEL GLADIATOR GAMING UPS Model Number PSGL1500 Capacity 1500VA / 900W...
