Liberty ® LRI3E / Regency Horizon ® HRI3E
MODELS: LRI3E-NG11 Natural Gas
HRI3E-NG11 Natural Gas
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
919-996e
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Gas Insert
LRI3E-LP11 Propane
HRI3E-LP11 Propane
Installer: Please complete the details on the back cover
ANSI Z21.88-2017
and leave this manual with the homeowner.
CSA 2.33-2017
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
www.regency-fire.com
10.14.21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Liberty LRI3E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Regency Fireplace Products Liberty LRI3E

  • Page 1 Liberty ® LRI3E / Regency Horizon ® HRI3E Owners & Gas Insert Installation Manual www.regency-fire.com MODELS: LRI3E-NG11 Natural Gas LRI3E-LP11 Propane HRI3E-NG11 Natural Gas HRI3E-LP11 Propane WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
  • Page 2 TO THE NEW OWNER Congratulations! You are the owner of a state-of-the-art Gas Insert by Regency. The Regency Gas Insert Series of hand crafted appliances has been designed to provide you with all the warmth and charm of a fireplace, at the flick of a switch. The models LRI3E-11 / HRI3E-11 of this series have been approved by Warnock Hersey/Intertek for both safety and efficiency.
  • Page 3: Table Of Contents

    table of contents Requirements ..............17 OWNER’S INFORMATION Installation Checklist ............18 Materials Required ............18 Copy of Safety Label HRI3E-11 / ........7 Minimum Fireplace Dimensions ........18 Copy of Safety Label LRI3E-11 ........8 Minimum Clearances to Combustibles ......19 MA Code - CO Detector ..........9 Gas Connection ............20 Important Message ............10 Alternate Approved Caps/Adaptor .......21...
  • Page 4: Unit Dimensions With Vignette Faceplate

    dimensions UNIT DIMENSIONS WITH VIGNETTE FACEPLATE 28" (711mm) 21-5/16" (540mm) 10-3/8" (262mm) 10-3/8” (262mm) 29-1/16" (738mm) 26" (660mm) 22-3/4" (576mm) UNIT DIMENSIONS WITH VIGNETTE FACEPLATE + SMALL BACKING PLATE 28” 711mm 21-5/16” 540mm 31-1/4” 794mm 29-1/16” 738mm 22-11/16” 576mm Not Shown: Regular backing plate - 35-3/4"...
  • Page 5: Unit Dimensions With 4 Sided Vignette Faceplate + Back- Ing Plate

    dimensions UNIT DIMENSIONS WITH 4 SIDED VIGNETTE FACEPLATE + BACKING PLATE 28” 711mm 21-5/16” 540mm 35-3/4” 908mm 29-1/4” 743mm 10-3/8” 262mm 3” 14” 76mm 355mm ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. LRI3E-11 / HRI3E-11 Direct Vent Gas Insert...
  • Page 6: Unit Dimensions With Arched Vignette Faceplate

    dimensions UNIT DIMENSIONS WITH ARCHED VIGNETTE FACEPLATE 16 " 16 " UNIT DIMENSIONS WITH ARCHED VIGNETTE FACEPLATE + BACKING PLATE 16 " 16 " LRI3E-11 / HRI3E-11 Direct Vent Gas Insert...
  • Page 7: Copy Of Safety Label Hri3E-11

    dimensions COPY OF SAFETY LABEL HRI3E-11 NOTE: Regency units are constantly being improved. Check the label on This is a copy of the labels that accompany each HRI3E-11 Gas Insert. We have printed a copy of the contents here for your review. the unit and if there is a difference, the label on the unit is the correct one.
  • Page 8: Copy Of Safety Label Lri3E-11

    safety decal COPY OF SAFETY LABEL LRI3E-11 This is a copy of the labels that accompany each LRI3E-11 Gas Insert. NOTE: Regency units are constantly being improved. Check the label on We have printed a copy of the contents here for your review. the unit and if there is a difference, the label on the unit is the correct one.
  • Page 9: Ma Code - Co Detector

    requirements installer's information MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...
  • Page 10: Important Message

    owner's information IMPORTANT MESSAGE FOR YOUR SAFETY YOUNG CHILDREN SHOULD BE CARE- SAVE THESE INSTRUCTIONS FULLY SUPERVISED WHEN THEY ARE This appliance requires air for proper combustion. IN THE SAME AREA AS THE APPLI- Always provide adequate combustion and ventilation The LRI3E-11 / HRI3E-11 Gas Inserts must be ANCE.
  • Page 11: Lighting Procedure

    owner's information LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has Note: The first try for ignition will last approximately 60 seconds. If there is no several options for starting/operating the appliance using the battery flame ignition (rectification) the board will stop sparking for approximately holder and ON/OFF key on the hand held transmitter.
  • Page 12: Copy Of Lighting Instruction Plate

    owner's information COPY OF THE LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1.
  • Page 13: Proflame Ii Remote Control Operating Instructions

    owner's information PROFLAME II REMOTE CONTROL OPERATING INSTRUCTIONS IMPORTANT:The Proflame Transmitter 2 is an integrated part of the TECHNICAL DATA Proflame 2 System, which consists of these elements: REMOTE CONTROL • Proflame 2 Transmitter, to be used in conjunction with: •...
  • Page 14 owner's information Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the flame height in accordance light control. To activate this function use the Mode Key (fig. 1) to index to the difference between the set point temperature and the actual to the AUX icon (fig.
  • Page 15 owner's information 5. "Clr" will remove a mode—use the up or down arrow while hold- Continuous Pilot/Intermittent Pilot (CPI/IPI) selection ing down ON/OFF and MODE (mode icon will disappear once removed). Note: Power vent models do not have a Continuous 6.
  • Page 16 owner's information 5. "Clr" will remove a mode—use the up or down arrow while hold- Continuous Pilot/Intermittent Pilot (CPI/IPI) selection ing down ON/OFF and MODE (mode icon will disappear once removed). Note: Power vent models do not have a Continuous 6.
  • Page 17: Installation

    installation General Safety Information GAS PRESSURE FACTORY-BUILT (METAL) WOOD- TESTING BURNING FIREPLACE 1. The appliance installation must conform with REQUIREMENTS local codes or in the absence of local codes, The appliance must be isolated from the gas sup- with CAN/CGA B149 (in Canada) or the National ply piping system by closing its individual manual NOTE: Any parts that are removed must be removed Fuel Gas Code ANSI Z223.1 in the U.S.A.
  • Page 18: Installation Checklist

    installation INSTALLATION MATERIALS REQUIRED CHECKLIST A 120 Volt AC power cord is hooked up to operate the fan and operate the gas valve when batteries are not installed in the receiver. Plug the 3 wire cord into a suitable receptacle. Do not cut the ground Before installing vent system ensure that the damper terminal off under any circumstances.
  • Page 19: Minimum Clearances To Combustibles

    installation MINIMUM CLEARANCES TO COMBUSTIBLES The clearances listed below are minimum distances unless otherwise stated: A major cause of fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this decorative gas appliance be installed only in accordance with these instructions. Clearance: Dimension Measured From:...
  • Page 20: Gas Connection

    installation THE APPLIANCE MUST NOT BE CONNECTED TO A CHIMNEY GAS CONNECTION FLUE SERVING A SEPARATE SOLID FUEL BURNING APPLIANCE. GAS CONNECTION WARNING: Masonry chimneys may take various contours which the flexible liner will Only persons licensed to work with accommodate.
  • Page 21: Alternate Approved Caps/Adaptor

    installation VENT RESTRICTOR PLATE INSTALLATION ALTERNATE APPROVED CAPS/ADAPTOR Note: only installed on runs at the minimum 8 feet vent height from above unit. 46DVA-GK 3" Co-linear Adaptor with flashing If longer than 8 feet the restrictor is not required. 46DVA-VC Vertical Termination Cap 1.
  • Page 22: Flue / Vent Installation

    installation FLUE / VENT INSTALLATION NOTE: Flue Plate Connector Gasket must not be damaged or removed. Care must be taken to ensure that this 4. Use the Flue Connector Slide Tool to slowly pull the Flue Connector Plate gasket remains intact to prevent flue forward as you move the Insert rearward into the Fireplace Chase.
  • Page 23: Air Shutter Adjustment

    installation AIR SHUTTER ADJUSTMENT The burner aeration is factory set but may need adjusting due to either the LRI3E- Remove the burner by removing 2 screws in locations shown below. local gas supply or altitude. Slide burner to the left and lift out to remove. Air Shutters are required to increase or decrease the amount of air that is mixed with the fuel before combustion.
  • Page 24: Wiring Diagram With Fan (Lri3E-11 / Hri3E-11)

    installation WIRING DIAGRAM - SYSTEM WITH FAN (LRI3E-11 / HRI3E-11) 911-276 - NG 911-277 - LP 911-266/P 911-179 911-038 911-037 911-027 910-246 911-178 911-084 - NG 911-085 - LP 911-173 911-207/P 911-257 911-010 - NG 911-257 911-011 - LP 911-242 CAUTION: Label all wires prior to disconnection Caution: Ensure that the wires do not touch any when servicing controls.
  • Page 25: System Data

    installation The manifold pressure is controlled by a regulator HIGH ELEVATION HRI3E-NG11 SYSTEM DATA built into the gas control, and should be checked at the pressure test point. Min. Supply Pressure 5" WC (1.25 kpa) This unit is approved for altitude 0 to 4500 ft. (CSA Max.
  • Page 26: Conversion From Ng To Lp

    LRI3E / HRI3E installation CONVERSION FROM NG TO LP CONVERSION FROM NG TO LP LRI3E/HRI3E USING PROFLAME 885 VALVE LRI3E/HRI3E-11 THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! 4. Remove and discard 2 Pressure regulator screws A (T20 or slot), Pres- WARNING sure Regulator B, Spring and Diaphragm C.
  • Page 27 LRI3E / HRI3E installation HRI3E - Remove the burner by removing 5 screws in locations shown below 9. Unscrew the pilot orifice with the Allen key; then replace with the LPG to remove burner cover and 2 screws to remove burner (shown below). pilot orifice and the pilot cap, provided in the kit.
  • Page 28: Media Installation

    installation MEDIA INSTALLATION Spread the Media evenly over the burner. Ensure installed media does not overlap excessively as this will affect the flame pattern. IMPORTANT NOTE: Only the supplied approved Media is to be used with these fireplaces. Use of any other type of media can alter the unit's performance, any damage caused by the use of any unapproved media will not be covered under warranty.
  • Page 29: Hri3E-11 Optional Log Set Installation

    installation HRI3E HRI3E OPTIONAL LOG SET INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty.
  • Page 30 HRI3E installation 7. Place the supplied embers on the glass crystals as shown. Note: do not cover burner ports with embers. This will cause soothing on the logs. Ember install 8. Test fi re to ensure proper light off (make sure fl ame fl ows smoothly from one end of the burner to the other).
  • Page 31: Lri3E-11 Log Set Installation

    LRI3E installation LRI3E LOG SET INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty.
  • Page 32 installation LRI3E 6. Install Log 6 in the indent of the burner as shown below. Log 6 install 7. Install Log 7 on a diagonal, one end will rest in an indent in the burner and the other end will rest at the "Y" on Log 3. Log 7 install 8.
  • Page 33: Brick Panel Installation

    installation LRI3E BRICK PANEL INSTALLATION Important: This appliance cannot be operated without brick (LRI3E-11 only), enamel panels (HRI3E-11/LRI3E-11) or painted panels (HRI3E-11 only) installed. BRICK PANEL INSTALLATION Brick panels are soft and fragile. Use caution when handling the panels, being careful not to jar them or scratch the painted surfaces. 1.
  • Page 34: Painted Black And Enamel Panel Installation

    installation HRI3E PAINTED BLACK AND ENAMEL PANEL INSTALLATION Important: This appliance cannot be operated without brick (LRI3E-11), enamel panels (HRI3E-11/LRI3E-11) installed BLACK PAINTED OR ENAMEL PANEL INSTALLATION or painted panels (HRI3E-11 only) installed. tooltip 4. Loosen bracket screw in firebox in location shown below, slide right panel Before you Start: into position until it contacts the back panel.
  • Page 35: Glass Door Removal / Installation

    installation GLASS DOOR REMOVAL / INSTALLATION WARNING: Do not operate the appliance with the glass 4. Release the side door latch until it reaches its resting point. panels removed, cracked or broken. Replacement of the 5. Support the top of door as it will fall forward after the 2nd door latch is re- glass panels should be done by a licensed or qualified leased.
  • Page 36: Vignette Faceplate With Safety Screen Installation

    installation VIGNETTE FACEPLATE INSTALLATION VIGNETTE FACEPLATE WITH SAFETY SCREEN INSTALLATION 1. Install the back faceplate and secure with 4 screws as shown. Final Install Back Faceplate Install 2. Install the outer (front) faceplate by hooking the flange over the hanger located on the back faceplate (installed in the previous step) as shown.
  • Page 37: Inlay Installation

    installation INLAY INSTALLATION OPTIONAL VIGNETTE INLAY INSTALLATION 1. Remove 5 screws from the backside of the Vignette frame cover 3. Place the Inlay on the Front Trim Assembly. and keep them aside (3 at bottom and 2 at top). Vignette Frame Vignette Frame Cover 2.
  • Page 38 installation 5. With the Inlay in position, place the mesh screen over the inlay. 6. Reverse step1. NOTE: The fl ush side of the mesh screen should face the inlay. 7. Install the Vignette frame with Inlay onto the 2 hooks provided on the unit.
  • Page 39: Backing Plate Installation

    installation BACKING PLATE INSTALLATION BACKING PLATE INSTALLATION 1. Remove Vignette (front) faceplate from unit and lay on a soft \ 3. Attach the backing plate to the back faceplate from the front with 6 surface. screws (4 along the top and 1 on each side). Backing Plate Install 4.
  • Page 40: Optional Arched Vignette Faceplate Installation

    installation HRI3E / LRI3E OPTIONAL ARCHED VIGNETTE FACEPLATE OPTIONAL ARCHED VIGNETTE FACEPLATE INSTALLATION 1. Shut off unit and allow to return to room temperature 5. Install the outer Vignette frame onto the inner Vignette frame by hanging tabs into slots on inner Vignette frame. 2.
  • Page 41: Optional Backing Plate Installation

    installation HRI3E / LRI3E OPTIONAL BACKING PLATE OPTIONAL BACKING PLATE INSTALLATION 1. Shut off unit and allow to return to room temperature 2. Attach the backing plate with 4 screws from the back of the Vignette frame. Install backing plate to inner Vignette frame with 4 screws 3.
  • Page 42: Optional Hearth Trim Installation

    installation LRI3E/HRI3E OPTIONAL HEARTH TRIM INSTALLATION OPTIONAL MANTEL DEFLECTOR INSTALLATION OPTIONAL MANTEL DEFLECTOR OPTIONAL HEARTH TRIM INSTALLATION INSTALLATION Customizing the Hearth Trim A mantel deflector may be installed to reduce the minimum mantel height. Refer to the instruction manual for minimum mantel clearances. The Hearth Trim can be adjusted to custom fit an installation by pulling apart the top piece from the bottom piece.
  • Page 43: Operating Instructions

    operating instructions 8. Remote control requires coding. See remote 4. Install the 3 AAA type batteries in the Transmitter FIRST FIRE coding instructions for details. battery bay, located on the base of the Transmit- ter. With the batteries already installed in the The first fire in your fireplace is part of the paint NOTE: This appliance will operate with 4 AA back-up Transmitter, push the <ON>...
  • Page 44: Maintenance Instructions

    operating instructions 2. Clean glass (never when unit is hot), appliance, NORMAL OPERATING SOUNDS OF CAUTION: ANY SAFETY SCREEN and door with a damp cloth. Never use an GAS APPLIANCES OR GUARD REMOVED FOR SER- abrasive cleaner. VICING AN APPLIANCE MUST BE It is possible that you will hear some sounds from 3.
  • Page 45: Door Glass

    maintenance DOOR GLASS Your Regency insert is supplied with high temperature, Neoceram ceramic glass that will withstand the highest heat that your unit will produce. If your glass requires cleaning, we recommend using an approved glass cleaner available at all authorized dealers.
  • Page 46: Pilot Adjustment

    maintenance GENERAL VENT PILOT ADJUSTMENT BACKUP BATTERY PACK MAINTENANCE Periodically check the pilot flames. Correct flame There is a back up battery pack located on the left pattern has two strong blue flames: 1 flowing side of the unit, used in case of a power outage. Conduct an inspection of the venting system semi- around the flame sensor and 1 flowing across annually.
  • Page 47: Fan Replacement - With Remote Control

    maintenance FAN REPLACEMENT - WITH REMOTE CONTROL t t o o o o l l t t i i p p Note: To access the rear access panel both the gas and venting will need 3. Remove fan from unit by lifting up off pins. to be disconnected (see vent/flue installation in this manual) for proper removal.
  • Page 48: Valve Replacement

    maintenance VALVE REPLACEMENT 5. Remove the burner support by removing 3 screws as shown below. Before you begin: * Shut off the gas supply to the unit. Disconnect all electrical supply to the unit. Always let the appliance cool to room temperature before servic- ing.
  • Page 49 maintenance 8. Lift out panel (part of valve assembly) with valve and pilot assembly. tooltip Diagram 7 9. Replace with new valve assembly, ensuring to use a new gasket before securing new valve access plate to unit. 10. Reassemble unit by reversing Steps 8-1. 11.
  • Page 50: Gas Maintenance

    maintenance Gas Maintenance GAS MAINTENANCE - RECOMMENDED ANNUAL ROUTINE Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter •...
  • Page 51: Lri3E-11 Parts List

    parts list LRI3E-11 PARTS LIST Part # Description Part # Description 717-574/P Valve Assembly - NG 904-629 Fitting Elbow 90 Degree Forged 717-776/P Valve Assembly - LP 904-606 Fitting 90 Street Elbow Extruded 911-084 Novasit 885 Valve - NG IPI 885.001 904-658 Inlet Flex Line Gas SS Steel 24 inch 911-085...
  • Page 52: Lri3E-11 Main Assembly

    parts list LRI3E-11 MAIN ASSEMBLY LRI3E-11 / HRI3E-11 Direct Vent Gas Insert...
  • Page 53: Hri3E-11 Parts List

    maintenance HRI3E-11 PARTS LIST Part # Description Part # Description 717-578/P Valve Assembly - NG 904-629 Fitting Elbow 90 Degree Forged 717-780/P Valve Assembly - LP 904-606 Fitting 90 Street Elbow Extruded 911-084 Novasit 885 Valve - NG IPI 885.001 904-658 Inlet Flex Line Gas SS Steel 24 inch 911-085...
  • Page 54: Hri3E-11 Main Assembly

    maintenance HRI3E-11 MAIN ASSEMBLY LRI3E-11 / HRI3E-11 Direct Vent Gas Insert...
  • Page 55: Accessories

    parts list Part # Part Description ACCESSORIES 716-920 Mantel Deflector 716-919 Hearth Trim Adjustable 716-921 Faceplate Vignette Tuscan Sunset 716-922 Faceplate Vignette Black Chrome 716-923 Faceplate Vignette Metallic Black 716-924 Faceplate Vignette Platinum 716-928 Backing Plate 4-Sided Vignette 716-925 Backing Plate Vignette Small 716-926 Backing Plate Vignette Regular 716-927...
  • Page 56: Warranty

    warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below.
  • Page 57 warranty At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you).
  • Page 58 warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
  • Page 59 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 60 warranty LRI3E-11 / HRI3E-11 Direct Vent Gas Insert...
  • Page 61 notes LRI3E-11 / HRI3E-11 Direct Vent Gas Insert...
  • Page 62 notes LRI3E-11 / HRI3E-11 Direct Vent Gas Insert...
  • Page 63 LRI3E-11 / HRI3E-11 Direct Vent Gas Insert...
  • Page 64 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ Printed in Canada Regency and Regency Horizon, are trademarks of FPI Fireplace Products International Ltd. ® © Copyright 2020, FPI Fireplace Products International Ltd. All rights reserved.
